MFG FUN WORLD-EP Instruction Manual

4-channel radio w/ 4 micro servos, outrunner motor km0283010 w/ propeller adaptor hw2340100 20a brushless esc, 3 cells 11.1v 2100 mah li - po battery & charger

Advertisement

Quick Links

Requires: 4-channel radio w/ 4 micro servos,
Wing Span
Wing Area
Flying Weight
Fuselage Length
Warning! This model is not a toy.
It is designed for maximum performance. Please seek advice if one is not familiar with this kind
of electric powered precision model. Operating this model without prior preparation may cause
injuries. Remember, safety is the most important thing. Always keep this instruction manual at
hand for quick reference.
The World Models
Manufacturing Co
www.theworldmodels.com
E228SXMPO25581107
Outrunner Motor KM0283010
w/ Propeller Adaptor HW2340100
20A brushless ESC, 3 cells 11.1V
2100 mAh Li - Po battery & charger.
Specifications
*Specifications are subject to change without notice.*
., Ltd .
INSTRUCTION MANUAL
39.5 in / 1000 mm
421 sq in / 27.2 sq dm
25.4 oz / 720 g
39.5 in / 1000 mm
FACTORY PRE-FABRICATED
ALMOST-READY-TO-FLY(ARF) SERIES
MADE IN CHINA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FUN WORLD-EP and is the answer not in the manual?

Questions and answers

Summary of Contents for MFG FUN WORLD-EP

  • Page 1 INSTRUCTION MANUAL Requires: 4-channel radio w/ 4 micro servos, Outrunner Motor KM0283010 w/ Propeller Adaptor HW2340100 20A brushless ESC, 3 cells 11.1V 2100 mAh Li - Po battery & charger. Specifications Wing Span 39.5 in / 1000 mm Wing Area 421 sq in / 27.2 sq dm Flying Weight 25.4 oz / 720 g...
  • Page 2: Before You Begin

    I N D E X BEFORE YOU BEGIN P. 1 PARTS LIST P. 2 ASSEMBLY P. 3 -10 SAFETY PRECAUTIONS P.10 BEFORE YOU BEGIN Read through the manual before you begin, so you will have an overall idea of what to do. Check all parts.
  • Page 3 Parts List 1. MAIN WING -- 1 pair 10. PUSHROD Ø1.4x40mm (For Elevator) -- 1 pc. PUSHROD CONNECTOR PL4410020 -- 1 set FUEL TUBE d2xD4x4mm -- 2 pcs 2. PUSHROD Ø1.4x90mm w/ Threads (For Aileron) -- 2 pcs STRAPER PL4112106 -- 2 pcs STRAPER PL4112106 -- 2 pcs SPONGE 10x50x150mm -- 2 pcs CLEVIS PL4112105 -- 2 pcs...
  • Page 4: Aileron Servo

    Main Wing Aileron Servo lead Apply instant type CA glue to both sides of each hinge. Bottom View Ø1mm pilot holes for World Models control horn are pre-drilled. Aileron Servo Please look for pin-hole marks at under side of control surfaces. Screw PB2x10mm TWM PL8210010...
  • Page 5: Tail Landing Gear

    Vertical Fin & Rudder Apply instant type CA glue to both sides of each hinge. Completed Tail Landing Gear Screw PB2x8mm 1.5mm PA2X8mm Wheel Ø23mm Plastic Collar PM2X8mm M2 Nut Bottom View E228SXMPO25581107...
  • Page 6: Main Landing Gear

    Main Landing Gear Screw PA2 .3x10mm PA2 .3x10mm Front Collar 2.6mm 1.5mm 2.6mm Collar Landing wire straps M3x3mm Set Screw Bottom View Ø1mm pilot holes for World Models horn are pre-drilled. Elevator Pushrod Please look for pin-hole marks at under side of control surfaces. Screw PB2x10mm TWM PL8210010...
  • Page 7: Optional Parts

    Outrunner Motor & Cowling M3x6mm Socket Head Screw Optional Parts M3x6mm d3xD7mm PM2x12mm Screw Washer Outrunner Motor 28/ 30 PWA2x8mm Screw KM0283010 d3xD7mm Washer Propeller Adaptor (d3xD5) HW2340100 Don't over-tighten the PM3 screws, too much KP0011310 stress on the screws Solder Solder could split the firewall.
  • Page 8: Radio Equipment

    Radio Equipment Install and arrange the servos as shown in the diagram. Screw PM2 x10mm J1(Pushrod Ø1.4x40mm) Elevator Servo Nylon Insert Lock Nut J2(Pushrod Ø1.4x443mm) Pushrod Washer d2 x D5mm Connector Battery Tie Battery Double-Sided Tape Pushrod Connector Elevator Servo Brushless ESC Straper Rudder Servo...
  • Page 9 Main Wing Bottom 90° Eye Screw PA2.5x10x23mm Bottom View Wing Tube Ø9.6x240mm Lead to Aileron Servo Bottom View Rubber Band Bottom View E228SXMPO25581107...
  • Page 10 Wing Setting Adjust the wing fuselage configuration as shown in the diagrams. A=A' B=B' C=C' E228SXMPO25581107...
  • Page 11: Control Throws

    Adjust the control throws as shown in the diagram. Control Throws These throws are good for general flying. You can adjust according to your personal preference. Elevator 20mm 20mm Rudder 45mm 45mm Ailerons 15mm 15mm The ideal C.G. position is 90mm (3.54 in.) behind the C.G.
  • Page 12 Product Registration Form (US Customers) We would like to share with you any relevant information regarding your model, including product news and free upgrade parts when applicable. Please fill in the following and send to AirBorne Models, 4749-K, Bennett Drive, Livermore, CA 94551 USA. 1.
  • Page 13 Pl8210010 Large Clevis Small Clevis E228SXMPO25581107...
  • Page 14 The World Models Manufacturing Co www .thew orldm odels .com E228SXMPO25581107...
