- Page 1 HEAT – TRANSFER PRESS FOR FABRICS AND OTHER MATERIALS MA PREGI 35N1 operating and maintenance instructions SHOCK LINE S.R.L. Head office and plant: via dei Gelsi, 65b – 86039 Termoli (CB) - ITALY...
- Page 2 ..HOCK LINE S HOCK LINE S HOCK LINE S HOCK LINE S R R R R L L L L SHOCK LINE S.R.L. Head office and plant: via dei Gelsi, 65b – 86039 Termoli (CB) - ITALY...
-
Page 3: Table Of Contents
I N D E X GENERAL INFORMATION IDENTIFICATION OF THE HEAT-TRANSFER PRESS Legal references and laws Uses Company data Customer service Assistance notices DESCRIPTION OF THE HEAT PRESS AND COMPONENTS Metal frame Lower platen Heat platen Electrical parts box TECHNICAL DETAILS IMPORTANT SAFETY NOTICES Safety rules and symbols Rules for using the machine... -
Page 4: General Information
This manual refers to the Heat-transfer press for fabrics and other materials. Shock Line s.r.l. Company Name of product Heat-transfer press for fabrics and other materials Model MA PREGI 35N1 Serial number Date of construction Test certificate Legal references and laws UNI EN 292-2... -
Page 5: Customer Service
G E N E R A L I N F O R M A T I O N Customer service Whenever you need to communicate with our company about any technical problem you must always refer to: Customer ID • Model and serial number of the machine •... -
Page 6: Technical Details
G E N E R A L I N F O R M A T I O N Electric parts box Heat platen Steel frame Lower platen Figure 1 – parts of the heat-transfer press TECHNICAL DETAILS Voltage: 220 V 1800 W Power consumption: Input frequency:... -
Page 7: Important Safety Notices
G E N E R A L I N F O R M A T I O N IMPORTANT SAFETY NOTICES Safety rules and symbols This booklet is not only an operating instructions manual but a very important guide for installing and maintenance personnel and contains notices on risks that may derive from improper use. -
Page 8: Maintenance Organization
G E N E R A L I N F O R M A T I O N Maintenance organization Maintenance personnel must read these instructions and rules before beginning to work on the press and should pay most attention to the safety section of the manual. warning! Always keep this booklet on hand near the machine. -
Page 9: Danger From Electricity
G E N E R A L I N F O R M A T I O N Danger from electricity Make sure that the machine is connected to a valid ground rod. The grounded electrical line must be controlled by trained personnel before connecting the heat-transfer press. All operations concerning electric wiring must be carried out by trained personnel. -
Page 10: Shifting, Carrying And Shipping
S H I F T I N G , C A R R Y I N G A N D S H I P P I N G SHIFTING, CARRYING AND SHIPPING This part of the manual contains information on shifting, carrying and transporting the press. These manoeuvres can be dangerous and may expose users to extremely serious injuries. - Page 11 S H I F T I N G , C A R R Y I N G A N D S H I P P I N G Make sure that the cases are fixed to the vehicle so they won’t move during warning! transportation.
-
Page 12: What Must Not Be Done With A Heat-Transfer Press
U S E The heat-transfer press is to be used for decorating fabrics and other materials by means of heat-transferable films as reported in the APPLICATION GUIDE in APPENDIX A. Always read the film’s instructions on it’s packet. warning! Always be careful when using a heat-transfer press. Even if equipped with safety warning! devices a careless mistake could be very dangerous. - Page 13 U S E Control lever Flywheel On/off switch Fuse socket Temperature adjustment panel And electronic timer Fig.2 – control devices Pag. 13 di 13...
-
Page 14: How To Use The Press
U S E HOW TO USE THE PRESS Please keep to the instructions. Different manoeuvres will not simplify or reduce warning! working time in any way. For decorating objects proceed as follows: 1. Make sure that the power chord and socket and the heat-press are in good conditions. 2. -
Page 15: Trouble Shooting And Maintenance
(point 4) and check if the timer works. If it works correctly fold the tab so that it starts when the lever is pulled down. If the switch doesn’t work send the box back (to Shock Line -Termoli). -
Page 16: Dismantling
D I S M A N T L I N G DISMANTLING When dismantling the heat-press turn to specialised personnel . No particular dismantling procedure is necessary for the materials used in building the press. Do not use parts of a dismantled heat-press for other uses because they may be warning! harmful when used for other purposes. -
Page 17: Appendix A - Application Guide
A P P E N D I X APPENDIX A – APPLICATION GUIDE Temperature Press. Time Transfer Notices (°C) (sec) FC Morbi White / light coloured FC Trans Consider the kind of fabric fabrics FC Super Coloured fabrics FC Blanc Consider the kind of fabric Wood, canvas, cork, Consider the kind of material and...
