2.4GHz DIGITAL WIRELESS RECEIVER
WIRELESSLY CONNECT CC056W CAMERA TO ANY MONITOR
IP69
WEATHER
12 24
P R O O F
MULTIVOLT
PROTECTION
2.4GHz WIRELESS
TECHNICAL SPECIFICATIONS
- Compatibility:
- Frequency Range:
- Transition Range:
- Transmission Rate:
- Time Delay:
- Spread Spectrum:
- Receiving Sensitivity:
- Connection Type:
- TV System:
- Decompression Format:
- Output:
- Pairing:
- LED Indicators:
- Operating Temperature:
- Construction:
- Waterproof Rating:
- Power Supply:
WR056
• 120M Wireless Range
• 1 Button Pairing
• Auto PAL/NTSC
IR CAMERA
Pairs to CC056W Camera
2.4-2.483.5GHz Digital
120M Line of Sight
4Mbps
120mS
FHSS
-86dBm
4 Pin Female (30cm)
PAL / NTSC (Auto)
MPEG4
Audio & Video
Easy Button Press to Pair
Power On - Red
Pairing - Flashing Blue
Paired - Blue
-20 to +70°
Metal Housing - Suitable for Outdoor Use
IP69K
12-32V via 4 Pin
The WR065 is an easy to use, digital
wireless receiver that allows you to
wirelessly connect the Axis CC056W
camera to any monitor for a no-fuss
setup. With 1 button pairing and an IP69
weatherproof chassis, enjoy peace of
mind with added convenience.
2
YEAR
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Axis WR056
Summary of Contents for Axis WR056
- Page 1 WIRELESSLY CONNECT CC056W CAMERA TO ANY MONITOR The WR065 is an easy to use, digital wireless receiver that allows you to wirelessly connect the Axis CC056W camera to any monitor for a no-fuss setup. With 1 button pairing and an IP69 weatherproof chassis, enjoy peace of mind with added convenience.
- Page 2 1. PRECAUTIONS Storage and Keeping: 1) Do not expose the device to excessive heat or cold. The storage temperature of this device is -30 to +80°C and the operating temperature -20 to +50ºC. The humidity is Rh90%. 2) Avoid dropping or striking this device. 3) Avoid using this device in areas with excessive vibration or subject to severe impacts.
-
Page 3: Parts Identification
2. PARTS IDENTIFICATION ANTENNA “PAIR” BUTTON 4-PIN Male Connector... - Page 4 4. APPLICATION The WR065 is an easy to use, digital wireless receiver that allows you to wirelessly connect the Axis CC056W camera to any monitor for a no-fuss setup, allowing you to enjoy peace of mind with added convenience. Optional CC056W...
-
Page 5: Operating Instructions
5. WIRING Connecting Monitor to WR056 WR056 Monitor not included 4-Pin Female 4-Pin Male Connector Connector Connecting Vehicle Battery to Optional CC056W Camera DC/12V Battery Automobile Optional CC056W Application (Camera not included) 6. OPERATING INSTRUCTIONS - Connect receiver with monitor. - Page 6 7. NOTES...
- Page 7 NOTES...
- Page 8 WR056...
