INSTRUCTION BOOK FOR
IDEA™ Screen
with Touch Interactive Bracket
for Epson BrightLink
A BRAND OF MILESTONE AV TECHNOLOGIES | www.milestone.com
USA P 866.977.3901 E info@da-lite.com
CANADA P 877.345.4329 E canadainfo@milestone.com
In British Columbia, Milestone AV Technologies ULC carries on business as MAVT Milestone AV Technologies ULC.
©2018 Milestone AV Technologies. DL–0724 (Rev. 0) 04.18
Da-Lite is a registered trademarks of Milestone AV Technologies. All other brand names or marks are used for
identification purposes and are trademarks of their respective owners. All patents are protected under existing
12008
designations. Other patents pending.
Advertisement
Table of Contents
Related Manuals for Milestone Da-Lite IDEA Screen
Summary of Contents for Milestone Da-Lite IDEA Screen
- Page 1 ©2018 Milestone AV Technologies. DL–0724 (Rev. 0) 04.18 Da-Lite is a registered trademarks of Milestone AV Technologies. All other brand names or marks are used for identification purposes and are trademarks of their respective owners. All patents are protected under existing 12008 designations.
-
Page 2: Important Safety Instructions
Milestone and its affiliated corporations and subsidiaries (collectively "Milestone"), intend to make this manual accurate and complete. However, Milestone makes no claim that the information contained herein covers all details, conditions or variations, nor does it provide for every possible contingency in connection with the installation or use of this subject to change without notice or obligation of any kind. - Page 3 Cleaning Everyday Cleaning: The supplied foam eraser can be used to clean marks on the screen surface made by everyday dry erase marker usage. Do not use spray cleaner in combination with the foam eraser. Thorough Cleaning: For periodic full screen cleaning or to clean persistent marks from dry erase markers, use the supplied Da-Lite spray cleaner and cleaning cloth.
- Page 4 Assembly Instructions Carefully unpack unit and place assembly on top of the clean Position the touch module bracket along the top of the IDEA work area. The viewing surface must face up. Screen by locating the two notches along the back side of the frame.
- Page 5 Wall Mounting Instructions Determining Screen Placement: When installing the IDEA Screen with BrightLink projectors, you must leave at least 22” (56 cm) of space between the top of the screen and the ceiling to accommodate the projector wall mount. NOTE: Use appropriate mounting hardware for the wall type and 3.
- Page 6 Wall Mounting Instructions (continued) 5. Tap the bottom of the two L-brackets with the rubber mallet until they make contact with the frame. Secure the two L-brackets to the frame with the remaining (4) #8 x 1/2” screws (Figure 3). 6.
- Page 7 Attaching Touch Module Remove the cover from the touch module provided with the interactive projector. Using the provided M4 x 30mm screws and M4 nuts, attach the touch module to the touch interactive bracket as shown (Figure 4). NOTE: The touch module can attach to the bracket with hardware or magnets.
- Page 8 LIMITED FIVE YEAR WARRANTY ON DA-LITE IDEA™ PRODUCTS ONLY Milestone AV Technologies LLC warrants these Da-Lite branded products to the original purchaser only, to be free from defects in materials and workmanship for a period of five (5) years from the date of purchase by the original purchaser; provided they are properly operated according to Da-Lite’s instructions and are not damaged due to improper handling or treatment after shipment from the factory.
