NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!
Definitions: Safety Alert Symbols and Words
This instruction manual uses the following safety alert symbols and words to alert you to hazardous situations and your risk of personal injury or property
damage.
DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.
WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.
CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.
(Used without word) Indictaes a safety related message.
NOTICE: Indicates a practice not related to personal injury which, if not avoided, may result in property damage.
WARNING:
YOUR SAFETY IS IMPORTANT TO YOU AND TO
OTHERS, SO PLEASE READ THESE INSTRUCTIONS BEFORE YOU OPERATE
THIS HEATER. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
GENERAL HAZARD WARNING:
PRECAUTIONS AND INSTRUCTIONS PROVIDED WITH THIS HEATER, CAN
RESULT IN DEATH, SERIOUS BODILY INJURY AND PROPERTY LOSS OR
DAMAGE FROM HAZARDS OF FIRE, EXPLOSION, BURN, ASPHYXIATION,
CARBON MONOXIDE POISONING, AND/OR ELECTRICAL SHOCK. ONLY
PERSONS WHO CAN UNDERSTAND AND FOLLOW THE INSTRUCTIONS
SHOULD USE OR SERVICE THIS HEATER. IF YOU NEED ASSISTANCE OR
HEATER INFORMATION SUCH AS AN INSTRUCTIONS MANUAL, LABELS,
ETC. CONTACT THE MANUFACTURER.
WARNING:
NOT FOR HOME OR RECREATIONAL VEHICLE USE
WARNING:
FIRE, BURN, INHALATION, AND EXPLOSION HAZARD.
KEEP SOLID COMBUSTIBLES, SUCH AS BUILDING MATERIALS, PAPER
OR CARDBOARD, A SAFE DISTANCE AWAY FROM THE HEATER AS
RECOMMENDED BY THE INSTRUCTIONS. NEVER USE THE HEATER
IN SPACES WHICH DO OR MAY CONTAIN VOLATILE OR AIRBORNE
COMBUSTIBLES, OR PRODUCTS SUCH AS GASOLINE, SOLVENTS, PAINT
THINNER, DUST PARTICLES OR UNKNOWN CHEMICALS.
WARNING:
This product can expose you to chemicals including
lead and lead compounds, which are known to the State of California to
cause cancer and birth defects or other reproductive harm. Wash your
hands after handling this product. For more information visit www.
P65Warnings.ca.gov.
WARNING:
Fuels used in liquefied propane gas appliances, and
the products of combustion of such fuel, can expose you to chemicals
including benzene, which is known to the State of California to cause
cancer and cause birth defects or other reproductive harm. For more
information visit www.P65Warnings.ca.gov.
SPECIFICATIONS
Model
:
Rating
Fuel Consumption
Heated Air Output
Average Air Temp. Rise
Product Dimensions 18.50" x 7.25" x 14.50" (470 mm x 184 mm x 368 mm)
Product Weight
Minimum tank size
Hose Length
CRAFTSMAN, Inc. | Forced Air Propane Construction Heater
FAILURE TO COMPLY WITH THE
CMXEHAO60FAV
30,000 - 60,000 Btu/Hr
(8.8 - 17.6 kW)
1.4 - 2.8 #/hr
(0.64 - 1.28 kg/hr)
183 cfm
(5.2 cmm)
200°F (111°C)
14.20 LBS (6.44 kg)
20 LB (9.07 kg)
10' (3.05 M)
GENERAL INFORMATION
RETAIN THIS MANUAL FOR FUTURE REFERENCE. FOR QUESTIONS, PROB-
LEMS, MISSING PARTS BEFORE RETURNING TO RETAILER PLEASE CALL
WITH MODEL NUMBER AND SERIAL NUMBER OF HEATER: 1-888-331-4569
MONDAY-FRIDAY 8-5 PM EASTERN TIME OR E-MAIL USING THE CRAFTSMAN
WEBSITE: WWW.CRAFTSMAN.COM
CONTENTS
WARNINGS .........................................................................................................................2
HEATER SPECIFICATIONS ..............................................................................................2
OPERATING PRECAUTIONS ..........................................................................................3
SAFETY PRECAUTIONS ..................................................................................................3
CLEARANCE TO COMBUSTIBLES.................................................................................3
ODOR FADE WARNING ...................................................................................................4
OPERATING INSTRUCTIONS .........................................................................................4
SERVICING ..........................................................................................................................5
SIZE AND CAPACITY OF PROPANE CYLINDERS REQUIRED ...............................5
WIRING DIAGRAMS .........................................................................................................6
CMXEHAO60FAV PARTS.................................................................................................7
CMXEHAO125FAV PARTS...............................................................................................7
WARRANTY ........................................................................................................................9
25.25" x 9.00" x 15.50" (641 mm x 229 mm x 394 mm)
2
Operator's Manual
CMXEHAO125FAV
75,000-125,000 Btu/Hr
(21.9 - 36.6 kW)
3.5 - 5.8 #/hr
(1.59 - 2.63 kg/hr)
185 cfm
(5.3 cmm)
400°F (232°C)
18.05 LBS (8.19 kg)
40 LB (18.14 kg)
10' (3.05 M)
