Vocollect SRX Manual

Wireless headset with bluetooth wireless technology
Hide thumbs

Advertisement

Quick Links

Download this manual
SRx Wireless Headset
Vocollect® ® ® ® SRX Wireless Headset
Vocollect
Vocollect
Vocollect
with Bluetooth® ® ® ® Wireless
with Bluetooth
with Bluetooth
with Bluetooth
Technology
Technology
Technology
Technology
Click here
for more information about Bluetooth® wireless technology.
Product notes
Procedures
Vocollect part numbers
Product notes
This headset contains a bidirectional noise canceling microphone for optimal noise cancellation.
Click here to view microphone information for SR - Series headsets.
Headset components are sealed to prevent corrosion.
Dual strap, padded, stainless steel headbands increase comfort and stability.
The ear cup, designed to pivot vertically and horizontally, can be worn on either ear.
Foam ear pads are designed for quick replacement.
A padded Velcro® strap fits across the back of the user's head to provide extra stability.
A rotating lever on the outside of the earpiece allows the user to move the microphone up and down
without causing stress on microphone or boom.
Microphone position is repeatable. A groove catches the boom, placing it in the proper position when
the boom is swiveled down for operation.
Use the flexible end of the boom to make fine adjustments to microphone itself.
Do not swivel the boom by the flexible end. Use the rotating lever on the outside of the earpiece.
Each headset and microphone unit comes with a windscreen. The microphone has a retention
feature that holds the windscreen in place.
SRX Wireless Headset
SRX Wireless Headset
SRX Wireless Headset
Wireless
Wireless
Wireless

29/8/2007

Advertisement

loading
Need help?

Need help?

Do you have a question about the SRX and is the answer not in the manual?

Questions and answers

Summary of Contents for Vocollect SRX

  • Page 1 SRx Wireless Headset Vocollect Vocollect Vocollect Vocollect® ® ® ® SRX Wireless Headset SRX Wireless Headset SRX Wireless Headset SRX Wireless Headset with Bluetooth with Bluetooth with Bluetooth with Bluetooth® ® ® ® Wireless Wireless Wireless Wireless Technology Technology Technology Technology  ...

  • Page 2: Specifications

    The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Vocollect is under license. Other trademarks and trade names are those of their respective owners. Approved for use in the following countries: U.S.A., Canada, and all EU and EFTA member states.
  • Page 3 SRx Wireless Headset “Este equipamento opera em caráter secundário, isto é, não tem direito a proteção contra interferência prejudicial, mesmo de estações do mesmo tipo, e não pode causar interferência a mesmo tipo, e não pode causar interferência a sistemas operando em caráter primário.”...
  • Page 4 Headsets Headsets Headsets SR - 10, 20, 30, and 40 - Series Headsets SRX Wireless Headset Removing a Headset Wearing an SR-10, 20, 30, and 40-Series Headset To wear a headset: 1. Put the headset on and adjust the ear pad to fit snugly over your ear. (For the Hard Hat Headset, first insert the headset bracket into the left or right slot on the hardhat, then put on the hardhat.)
  • Page 5   Wearing an SRX Wireless Headset To wear an SRX wireless headset: 1. Loosen the Velcro® strap. 2. Put the headset on and adjust the ear pad to fit snugly over your ear. Be sure to position the battery compartment directly above your other ear.
  • Page 6 Wearing and Removing SR-Series Headsets Page 3 of 4 4. Swing the microphone into position with the rotating lever at the earpiece. 5. Make final adjustments with the flexible boom so that the microphone is positioned at the corner of your mouth, about 1/4"...
  • Page 7 Wearing and Removing SR-Series Headsets Page 4 of 4 Press the release clip to remove the headset unit from the hardhat bracket.)     Approved for use in the following countries: U.S.A., Canada, and all EU and EFTA member states. 29/8/2007...
  • Page 8 Technology Technology Notes: A wireless connection must be made between the SRX headset and a device that uses Bluetooth wireless technology. This wireless connection allows the SRX headset to communicate with only one T5 wearable computer or handheld device. Once a connection has been established, the headset and device operate as if there is a wire connecting them.
  • Page 9 To pair an SRX headset with a Symbol® handheld device, perform the following steps: 1. Make sure the Symbol device is powered on and there is not a wired headset already connected to it.
  • Page 10 Select. The device may require you to enter the headset's passkey. The passkey for all SRX headsets is 4444. 6. Put on the headset. After pairing, the headset repeatedly says the serial number of the device to which it is paired.

  • Page 11: Volume Control

    Disconnecting a Pairing If you need to switch to a different SRX headset or device during your shift, disconnect the current pairing by powering off the headset. Perform the pairing process again with the new equipment to create a new pairing.
  • Page 12 SRX Proc Using the SRX Headset Page 5 of 5   Approved for use in the following countries: U.S.A., Canada, and all EU and EFTA member states. 29/8/2007...
