English
SUPPLIED ACCESSORIES
– AC mains lead
– Remote control
TOP AND FRONT PANELS (See 1)
1 p – 3.5 mm stereo headphone socket
Helpful hints: The speakers will be muted when
headphones are connected to the set.
2 AUX – 3.5 mm line-injack for external audio
appliance
3 STANDBYy – power on/ off switch
4 Source selector – selects CD(MP3-CD)/ TUNER/
AUX/ TAPE function
5 IR Sensor – infrared sensor for remote control
6 Cassette recorder keys
RECORD 0 – starts recording
PLAY 1 – starts playback
SEARCH 5/6 – fast winds/rewinds tape
STOP•OPEN 9/
– opens the cassette compartment
– stops the tape
PAUSE ; – pauses playback or recording
7
OPEN•CLOSE - press to open/close CD door
8 DBB – switches the bass enhancement on (DBB1
or DBB2) / off
9 VOLUME – adjusts volume level
0 FM•MW
TUNER: selects wavebands
MP3: display MP3-CD information
! Navigation controls
PRESET (ALB/ PRE) -, + (down, up) –
MP3 only : selects previous / next album.
TUNER : selects a preset station.
9 – stops CD playback;
– erases a CD programme
SEARCH ∞, § –
CD/MP3: – searches backwards and forwards
within a track;
– skips to the beginning of a current/
previous/ later track
TUNER: tunes to radio stations (down, up).
MODE – selects different play modes:
e.g.
or
(random order)
REPEAT
SHUFFLE
2; – starts or pauses disc playback
CONTROL
@ PROGRAM
CD/MP3: programs tracks and reviews the
program;
Tuner: programs preset radio stations
# Display – shows the status of the set
BACK PANEL
$ Telescopic aerial – improves FM reception
% AC MAINS – inlet for mains lead
^ Battery compartment – for 6 batteries, type
R-20, UM1 or D-cells
REMOTE CONTROL (See 1)
1 CD – switches the set on and selects CD/MP3
sound source
2 y – switches the set to standby / on if
AC powered power. (Switches set off if battery
powered)
3 VOLUME +, - (up, down) – adjusts volume level
4 SHUFFLE – selects shuffle modes
5 DBB – switches the bass enhancement on
(DBB1or DBB2)/ off
6 2; – starts/ pauses disc playback
7 SEARCH 5, 6 – searches backwards/ forwards
within a disc track
8 BAND – selects wavebands
9 PRESET (ALB/ PRE) 3,4 –
MP3 only : select next/ previous album.
TUNER : select a preset station.
0 TUNING -, + – tunes to tuner stations
! TUNER – switches the set on and selects tuner
source
@ 9 – stops disc playback;
– erases a disc program
# ¡, ™ – skips to the beginning of a current/
previous/ subsequent disc track
$ MUTE – interrupts/ resumes sound
% REPEAT – select repeat modes
CAUTION
Use of controls or adjustments or
performance of procedures other than
herein may result in hazardous
radiation exposure or other unsafe
operation
.
POWER SUPPLY
MAINS SUPPLY
Whenever convenient, use the mains supply to
conserve battery life. Make sure you remove the
power plug from the set and wall socket before insert-
ing batteries.
Batteries (not included)
• Insert 6 batteries, type R-20, UM-1 or D-cells,
(preferably alkaline) with the correct polarity.
(See A)
Remote control
• Insert 2 batteries, type AAA, R03 or UM4
(preferably alkaline).(See A)
Incorrect use of batteries can cause electrolyte leak-
age and will corrode the compartment or cause the
batteries to burst.
• Do not mix battery types: e.g. alkaline with carbon
zinc. Only use batteries of the same type for the
set.
• When inserting new batteries, do not try to mix old
batteries with the new ones.
• Batteries contain chemical substances, so
they should be disposed of properly.
Using AC Mains
1 Check if the mains supply, as shown on the type
plate located on the bottom of the set, corre-
sponds to your local mains supply. If it does not,
consult your dealer or service centre.
2 If your set is equipped with a voltage selector,
adjust the selector so that it matches with the local
mains.
3 Connect the mains lead to the wall socket.
4 To disconnect the mains supply, unplug the set from
the wall socket.
Auto-Standby mode
When a CD has reached the end of playback and
remains in the stop position for more than
15 minutes, the set will switch off automatically to
save mains.
The type plate is located on the bottom of the
set.
BASIC FUNCTIONS
BASIC FUNCTIONS
Switching on and off and selecting function
1 Press STANDBY y to switch on.
2 Press Source selector once or more to select: CD
(MP3-CD), TUNER, AUX or TAPE
function.
3 Press y to switch off the set.
Helpful hints:
– To change from TAPE to CD, TUNER or AUX
function, or when you are switching off the set:
first, make sure you press the tape STOP 9 key to
end playback and all the cassette keys are
released.
– The tone, sound settings, tuner presets and the
volume level (up to a maximum volume level of 20)
will be retained in the set's memory.
ADJUSTING VOLUME AND SOUND
• Adjust the volume with the VOLUME control.
= Display shows the volume level
and a
number from 0-32. (See 2)
Bass adjustment
There are three DBB (Dynamic Bass Boost) options:
– Off: no bass enhancement
– DBB1: moderate bass enhancement
– DBB2: strong bass enhancement
• Press DBB once or more to select your option.
™DBB1,2 appears if DBB is activated.
How to MUTE the sound
1. Press MUTE on the remote control to interrupt
sound reproduction instantly.
= Playback continues without sound and in the
display flashes
.
2. To reactivate sound reproduction you can:
– press MUTE again;
– adjust the volume controls;
– change to another source.
