Summary of Contents for Telexper nVS-32
- Page 1 Quick Installation Guide Network Video Server...
- Page 2 32CH/48CH/64CH Network Video Server Model No: nVS-32 / 48 / 64 - Product Front View nVS-32 nVS-48 nVS-64 - Product Rear View...
- Page 3 Product Front and Rear Description: Product Pin or Switch Front or Description Rear When the green light is on, it means that the None Front machine has been connected and RS485 function is on Please connect the RS485 controller DT+ 1: D- (RS485) (D+) pin to the D+ pin of the machine, and 2: D+ (RS485)
- Page 4 IP CCTV Solution Configuration Connect Cameras by using the 75 Ω Ω Ω Ω coaxial video cable to nVS Connect the nVS by using the CAT-6 RJ-45 cable to PoE Hub Power Cord Uplink to network...
