PD9501
Multi-Function Calibrator
FEATURES
•
Measure and Source T/Cs, RTDs, Ohms, Current, Voltage
•
Compact & Lightweight
•
Battery or USB Powered
•
Descriptive LCD Display
•
24 V Power to Drive the Transmitter
•
Auto Stepping & Auto Ramping
•
Selective Auto Off Mode
•
LCD includes an LED backlight
PRECISION DIGITAL CORPORATION
www.predig.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Precision Digital Corporation PD9501
- Page 1 Compact & Lightweight • Battery or USB Powered • Descriptive LCD Display • 24 V Power to Drive the Transmitter • Auto Stepping & Auto Ramping • Selective Auto Off Mode • LCD includes an LED backlight PRECISION DIGITAL CORPORATION www.predig.com...
-
Page 2: Accuracy Specifications
PD9501 Multi-Function Calibrator OVERVIEW This PD9501 Multi-Function Calibrator has a variety of signal measurement and output functions, including voltage, current, thermocouple, and RTD. Main Function Voltage Signal: 0-30 V, 0-25 mV, 0-100 mV output and measurement. Current Signal: Active and passive 0-25 mA, 4-20 mA output and measurement. -
Page 3: Lcd Display
PD9501 Multi-Function Calibrator FUNCTIONS ⑥ Cold Junction and Programming Function Keys [Cold End]: display/modify cold end [Program]: turn on the programming function [Waveform]: change programmable output waveform ⑦ [Power]: turn power on/off ⑧ Output Function Keys (Yellow) [Signal]: toggle output signal type... -
Page 4: Signal Output
PD9501 Multi-Function Calibrator SIGNAL OUTPUT 24V Power The calibrator can output voltage, active current, passive current, thermocouple, and RTD signals. Voltage, Active Current Output PLC or Other Instrument ① Connect the black wire to the common terminal, connect the yellow wire to the output terminal ②... -
Page 5: Signal Measurement
PD9501 Multi-Function Calibrator SIGNAL MEASUREMENT To view or adjust cold junction temperature for thermocouple: The calibrator can measure voltage, active current, ① Press [Cold End] to display cold end temperature passive current, thermocouple signal, and RTD. ② If the LCD displays “RJA” the cold end is collected When measure function is not in use press [Measure] by the internal sensor and cannot be modified. -
Page 6: Specifications
Digital Corporation makes no representations or warranties with respect to the contents hereof, and specifically disclaims any implied warranties of merchantability or fitness for a particular purpose. ©2019 Precision Digital Corporation. All rights reserved. WARNING Cancer and Reproductive Harm - www.P65Warnings.ca.gov...
