is an analog graphic equalizer unit
that has both memory and recall functions for all
MIDI
possible settings;
This allows the artist to configure the sound
equalization for the preferred sounds via the six
available controls.
is a step up for the analog guitar
effects as it introduces an analog-digital
architecture that works in the analog domain and
that is controlled by a digital processor.
The memorized settings can be recalled via the two
footswitches, CNT1 and CNT2, or via a MIDI
connection.
These 2 important characteristics, digital control,
and remote MIDI control, makes the
one of the most innovative equalizer within the
market.
A patch is composed of the six parameters. Each
patch can be memorized using the
pushbutton.
A maximum of ten (0-9) Patches can be saved which can
be recalled sequentially, using the footswitch CNT2; it's
possible to change this maximum number.
When in "PRE_PATCH MODE", pressing and releasing
CNT2 increase the patch number and put the
in a pre-patch mode, indicated by the
patch number flashing on the green display.
CNT1 will confirm and activate the pre-selection.
Use CNT1 also to toggle Normal and Bypass modes.
interface.
SAVE (ST)
Beyond the ordinary
PARAMETERS
BASSWAVES
has six adjustable parameters:
LEVEL Adjust the output signal level
LOW
Adjust the low frequency level
MIDL
Adjust the low mid frequency level
MID
Adjust the mid frequency level
MIDH
Adjust the high mid frequency level
HIGH
Adjust the high frequency level
All the parameters can be adjusted using the
control knobs; the equalizer frequencies are
calculated for a bass guitar.
BLUEJELLY
EQUALIZER
ACTIVATE PATCH
or BYPASS
1
Advertisement
Summary of Contents for Medea BLUEJELLY
- Page 1 BLUEJELLY Beyond the ordinary EQUALIZER is an analog graphic equalizer unit PARAMETERS that has both memory and recall functions for all MIDI possible settings; interface. BASSWAVES has six adjustable parameters: This allows the artist to configure the sound equalization for the preferred sounds via the six available controls.
- Page 2 Once all the parameters have been reconfigured, OPERATIVE MODES the Save (ST) button can be pressed for at least 3 seconds to memorize the new configuration, the During Power Up, keep pushed the SAVE button, patch. the characters ‘I’ and ‘P’ will appear sequentially The character ‘P’...
- Page 3 The display will show all the 16 available addresses, MIDI - PATCH ASSIGNMENT one every 2-3 seconds To assign a patch to a MIDI program command, simply: ● Send the MIDI program change (Cn) Release the footswitch CNT2 when the selected ●...
- Page 4 SERVICE & WARNING Always refer to a qualified personnel when servicing is required. Don’t expose the effect to moisture or rain and don’t use it near water; the operating ambient temperature must be lower than 50 degrees (Celsius). Avoid to apply power supply voltages higher than 12V, no objects filled with liquids should be placed on the effect.
