Holars AVH8516 Quick Start Manual

Hide thumbs

Advertisement

Table of Contents

Please read instructions thoroughly before operation and retain it for future
reference. For the actual display & operation, please refer to your device in hand.
To check the complete user manual, scan the QR code on the right,
or go to the site:
www.surveillance-download.com/user/h517.swf
To get the free PC CMS software (CMS Lite), check the supplied CD
or go to the site:
www.surveillance-download.com/user/h517.swf
H.265 5MP NVR

QUICK START

SERIES

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AVH8516 and is the answer not in the manual?

Questions and answers

Related Manuals for Holars AVH8516

Summary of Contents for Holars AVH8516

  • Page 1: Quick Start

    H.265 5MP NVR SERIES QUICK START Please read instructions thoroughly before operation and retain it for future reference. For the actual display & operation, please refer to your device in hand. To check the complete user manual, scan the QR code on the right, or go to the site: www.surveillance-download.com/user/h517.swf To get the free PC CMS software (CMS Lite), check the supplied CD...

  • Page 2: Hard Disk Installation

    042Z CONNECTION Hard Disk Installation Note: It’s necessary to install a hard disk first before firmware upgrade to ensure the upgrade process works properly. Type 1  Step1: Remove the top cover, and find the hard disk connector and bracket in the device. CR2032 Hard Disk Connector...
  • Page 3 Additional Brackets for Two More Hard Disks Step1: For the 16CH model which supports five hard disks, find two pairs of HDD trays, SATA cables and power cables in the sales package. Step2: Find HDD brackets, power board connectors (white) and Sata board connectors (black) on the main board. To install a hard disk, three brackets, one power board connector (while) and one Sata board connector (black) are needed.
  • Page 4 Type 2  Step1: Find the HDD tray and its accessories in the sales package, and place the rubber to the HDD tray as shown below. Step2: Get a compatible hard disk. With the PCB side facing down and the hard disk‘s connector facing the outside. Then, place the hard disk in the HDD tray and insert the latches.
  • Page 5 Connection Connect a monitor, IP cameras, adapters, a mouse, and other devices necessary to this recorder as illustrated below. Type 1  Type 2  Then, power on the whole system and wait till the system initialization is done.

  • Page 6: Camera Ip Configurations By Lan

    Camera IP Configurations by LAN The auto mode is used to simplify the complicated network settings within three minutes. The connection mode of the LAN port is AUTO by default. This mode is suitable when the LAN port of the device is connected to a hub / switch.
  • Page 7 (EDIT), and change the network type from STATIC to DHCP. b) Select APPLY Then, Click to save your changes. SETUP NETWORK TYPE DHCP 10.1.1.14 PORT USER NAME Admin PASSWORD ***** NETMASK 255.255.255.0 GATEWAY 10.1.1.10 PRIMARY DNS 8.8.8.8 CANCEL APPLY Check  to assign the camera to a specific channel automatically, and choose IP SEARCH ASSIGN EDIT...
  • Page 8 CHANGE USER NAME AND PASSWORD It’s highly recommended to change the user name and password of this device to keep your account safe. Otherwise, any person could access this device if he knows the default user name and password. If you didn’t go through the setting wizard at the first place, you’ll be prompted to change the user name and password: WARNING PLEASE BE ADVISED TO MODIFY THE DEFAULT ACCOUNT TO ENSURE YOUR INFORMATION SECUIRTY.
