National Office Furniture 2513735 Assembly Instruction

After all ganging is complete and Epicenters have been installed,

align the mounting brackets on the back of the Full Height insert with

the upper Epicenter U-channel and lower Epicenter U-channel

(Figures A & B).

Proper product installation, in accordance with these instructions, is the responsibility of the installing agent.

If you have any questions concerning these instructions, please call National Customer Service

Figure A

Figure B

Assembly Instruc on

Epicenter Full Height

Inserts—Veneer/

Laminate

Recommend Tools

• Drill

Package Contents

• Insert

• Brackets

•

• #6 x ¾" Screws

• #8 x ½" Screws

Telephone 800.482.1717

Fax 812.482.8800

www.NationalOfficeFurniture.com

Part # 2513735

Rev, -

Printed in U.S.A

800.482.1717

Qty.

" Diam. Washer Per Order

Per Order
