F -8080
WIRELESS STEREO HI-FI HEADPHONE SYSTEM IN 2.4 GHZ
DESCRIPTION
Wireless stereo Hi-Fi headphone system in 2.4 GHz. Connection to PC through USB, with headphone and microphone transmission, PC
playback and volume control. Line input accepting output signal from an MP3 player, TV, etc.
Compatible with headphones and headphones with microphone.
CONTROLS AND FUNCTIONS
TRANSMITTER
1.-
SIGNAL: LED signal reception. It lights up green when a connection is
established between the transmitter and the receiver.
2.-
POWER: LED power indicator. It will light up red when it is being powered.
3.-
USB: audio and power supply USB input for connecting to PC or just power
supply if connected to an audio source or an MP3 payer, TV, etc. Mini female
USB B connector.
4.-
OFF/USB/LINE selector: for selecting from the following options: OFF, USB
input or line input.
5.-
LINE INPUT: audio input for connecting to an audio source or MP3 player.
TV, etc. 3.5 mm stereo jack connector.
6.-
TUNE: tuner button. Press this button to establish the connection between
the transmitter and the receiver.
RECEIVER
1.-
MUTE: LED mute indicator. It lights up green when you press the MUTE button on
the receiver (deactivated mic. input).
2.-
SIGNAL/POWER: LED signal reception and power indicator. When the receiver is
switched on, this LED indicator flashes 3 times consecutively. When the connection
between the transmitter and the receiver is established, this indicator will stay
alight.
3.-
TUNE/13: tuner button. In USB mode, starts or stops audio file playback.
4.-
MUTE: activates/deactivates the mic. input.
5.-
One short press turns the audio output volume up. Besides, in USB mode, holding
the button down fast forwards to the following audio track.
6.-
One short press turns the audio output volume down. Besides, in USB mode,
holding the button down rewinds to the previous audio track.
q: receiver on/off button.
7.-
8.-
Headphone output, 4-contact 3.5 mm jack connector for headphones with
microphone, compatible with stereo headphones. Use the microphone for voice
reordings in your PC.
9.-
LED recharge indicator. It lights up green while the battery is recharging. When
charging has finished, it lights up red.
10.- Recharge input, female mini USB B connector.
