Summary of Contents for Arkiplot JDC R490
- Page 1 JDC R490 Electric programing paper cuter USER GUIDE...
- Page 2 Thank you for your choice of our Electric Programing Paper Cutter series.We will provide good quality and reliable after-sale service on the basis of original products. Our research and development engineers combined advantages of products at homeand abroad ,and finally developed new model machines with new advantages. It owns high technology,precise construction foydesighation designation designation,and elegant appearance with the security control part and improved cutting precision to promote efficiency.It can be broadly used in printing shop and official usage.
- Page 3 According to the relevant standards,to avoid accident and and accidental injury,only professional operators are allowed to use this machine (children or non-professional operators are forbidden to operate) to use or maintainthese machines.please pay high attention to safety cautions below: The weight of this machine is about 75-95kgs. Please put it in balance in a clean place.
- Page 4 Children or non-professional people are not allowed to operate this machine. Do not reach the beneath of the blade. Do not reach cut. Do not cut hard materials or other splinters. Must use socket with gropmd wire connected . Air safety switch ,non-professional people are not allowed to open.It is extremely dangerous.
- Page 5 1. Open the box and check 2. Installation of the machine 3.Environmental Conditions 4. Special hints 5. Operating figure 1. Parts description 2. Principal techninal parameter 3. Display and functions introduction . Basic operation 2. Basic adjustment 1. Lubrication 2. Maintenance 3.
- Page 6 When you open the package of the machine,firstly you should check the machine and relevant accessories.Please contact the seller or company if there are any damages or shortages. Open the wooden crate ,take out the machine casing and discharge the fixed screws on the base plate of the main machine;...
- Page 7 The machine should be placed in clean working environment,keep away form direct sunlight and wind. Temperature of operating environment :10-30 ,should not exceed 32 Humidity level of the operating environment: 50-80% Working power source of cutting line:DC3V. Remember only one prfessional operator is allowed to operate the machine;...
- Page 8 Infrared Model AE460R AE490R Specification Max.Cutting Size mm Min.Cutting Size mm Cutting thickness Size Paper -clamping mode Automatic Automatic Paper-pressing mode Program-control Program-control Display mode Infrared Infrared Safety Protection 1230W/220V/50HZ 1280KW/220V/50HZ Power 848*674*1215mm 910*762*1227mm Machine Measurement 130KG 150KG Net weight...
- Page 9 Model Specification Max.Cutting Size mm Min.Cutting Size mm Cutting thickness Size Automatic Automatic Paper -clamping mode Program-control Program-control Paper-pressing mode Display mode Infrared Infrared Safety Protection Power Machine Measurement Net weight...
- Page 10 124 0 M 23 AUTO Confirm entering , Eject mode and reet Out storage data saving and backgauge moving Forward&Back/Select key Mode for switching Modify and clear data Function key Number key Getting into screen of fine adjustment for cutting blade Press M key and dosplay stored data,and getting into automatic mode.
- Page 11 Count the times of cuttibg General cuts Manual state Automatic state Display the current data of pushs Divide state Display the number for reference Data for each program Current mode Relative distance for preaent data of pushs...
- Page 12 Before operating the machine,plaese review contents described before carefully.then remove the things on the machine and clean the machie Insert the power plug into AC220V.50HZ/60HZ.4KW socket. Turn the protective switch to ON position.Screen display will be light and the lindicative line light on the machine will be bright.The machine can be operated after backgauge is cailbrated automatically.
- Page 13 1)There are three pushing modes in programming paper guillotine.Now we take 285mm for example to push paper. Manual mode is with priority.As long as rotating the knob with hand,the mode will be swiched into msnual state anddisplay whatever mode it is in before.When in divide and automatic mode state,only press to switch into manual mode...
- Page 14 1)Press to get into divide mode.Press button to clear and set overall size285mm. Press to clear and set divide size 50mm Then press ENTER to make backgauge move to overall size 285mm position. 2)Put the books or paper right to cut,then make the books or paper lean to the left...
- Page 15 3)Start to cut after the size is confirmed. then pressing two CUT buttons at the same time. After that,the paper presser and blade come down,if you finding the paper is not straight,Please stop pressing two CUT buttons,and press to make paperpresser and blade return. After you confirmed the RESET paper put right,then press two CUT button to finish cuting completely.Start to cut after the size is entered.
- Page 16 Cut the electricity power Unload the back cover plate and check whether there is any other matter on the guiaing rod; Pull out the front covering strip and cheak stepping motor,to see whether the synchronous pulley and synchronous belt are fixed normally； Adjust the support chip on the screw,and you can move it back and forth until dimension,then lock the retaining screw firmly.
- Page 17 Cutting Cut the electricity power； First of all,fine adjust the cutter blade depth(adjust depth range about 2-3 mm) or exchange the cutting side of stick. Disassemle retaining screws on both sides of the upper cover,and then take the upper cover away； Loosen seven M6 fasten screws on the blade which is on blade carrier,and adjust the screws on blade carrier,until the blade cuts into the shim about 0.3-0.5mm；...
- Page 18 Open the upper cover; Loosen the festen screws on the blade carrier,revolve the two screwstems screwstems clockwise,and then fix up firmly; Take away other fasten screws on the blade carrier; Revolve the two screw stems anticlockwise 180 , then take out the blade. Please wear gloves or use cotton cloth to wrap the blade to avoid being scratched;...
- Page 19 Blade sharpening needs to be done in a professional factory to ensure the quality. Note Dull blade can’t cut paper correctly Blade also will become dull if it always cuts thick paper or pasteboard,If cutting quality and accuracy can’t meet required standard,the blade needs be changed.Your work will go smoothly if you always have one replacement standly.When you need to change blade, you must operate according to the steps of blade change instruction.
- Page 20 The machine should be lubricated every one month.Check and clean,tight accessary parts and add lubricated oil to transmission parts.Be careful to add oil in case of dropping in the electic circuit boards and electic component. 1) When the machine is working,other objects are forbidden to put on the machine. Because the blade will be danaged as it cutting hard objects.There should be on staple pin in the book,which will damage the blade when cutting.
- Page 22 Error Phenomena Solution Remove the backguage position Paper cutting is not The cutting paper is unperallel offset and loosen the fastening screw even or the cuting deviation to agjust the angle of pushing board. size is not accurate 1. The sensory position moves or was The blade can not All the buttons are invalid and damaged.
- Page 23 1. The guarantee period of paper-cutting machine is one year. You should register in maintenance station within one month after you buy the machine, in order to establish maintenance file; 2. Maintenance service scope : Supply the service of installation ,adjustment,operation,training, periodic maintenance, elimination of error in normal operation and repair.
- Page 24 4.We won’t undertaken the maintenance and accessories diversion fees caused by conditions below: Damage caused by accident,wrong operation or intent disasse- mbling. Repaired by stations not authorized by our company,or use dependable materials and accessories not required by our company. The customer doesn’t register in the maintenance station within one month after buying the machine.
