Description
The PSBC12XX charger is a power supply unit installed in outdoor/indoor
cabinets or standard 19" racks, which is used for charging batteries and powering
equipment directly . Overcurrent and overvoltage protection is provided to prevent
damage that might be caused by a faulty battery and/or external load. Temperature
compensation is employed to enhance battery life.
The PSBC12XX charger supports battery sets, which are charged as long as AC
power is on. When AC power is off, the batteries supply current directly to the
load.
If alarm monitoring, event logs or detailed PSBC12XX charger parameters are
Required, the PSM1006 GUI software supplied with the PSBC12XX charger can
be installed on a PC which connects to the PSBC12XX charger controller. For
more information, refer to the BroadAccess PSBC 12XX-X Charger Management
Software User Guide.
Table 1. PSBC12XX Charger - Features
Power
Supply
VDC)
(
48
Compatibility
The PSBC12XX charger is suitable for use with BroadAccess systems Ver 40
Release 3.0 and higher, or cabinets adapted for this charger.
Charger Controls and Indicators
PSBC12XX charger front panel controls and indicators are shown in Figure 1 and
described in Table 2.
Table 2. Front Panel Components
Designation
Mounting
Brackets
Rectifier
Modules
P/N 760-0000331 Rev C
000331c.doc 18-Dec-05 2:30 PM
I n s t a l l a t i o n I n s t r u c t i o n s
Max No. of
Battery Sets
Rectifiers
Supported
5
2
Description
-
Enables mounting of chargers in cabinets and racks
1 to 5
Convert AC power to DC power. The modules operate in
rectifiers
parallel in "N+1" configuration. Each rectifier supplies
12A/600W. The rectifiers are capable of load sharing.
December 2005
PSBC12XX Charger
Input
Output
Current Output Per
Voltage
Voltage
(VAC)
(VDC)
85-275
54
12A at 230 Vac input
Function
Rectifier Module
Page 1
Advertisement
Table of Contents
Summary of Contents for BroadAccess PSBC12 Series
- Page 1 85-275 12A at 230 Vac input Compatibility The PSBC12XX charger is suitable for use with BroadAccess systems Ver 40 Release 3.0 and higher, or cabinets adapted for this charger. Charger Controls and Indicators PSBC12XX charger front panel controls and indicators are shown in Figure 1 and described in Table 2.
- Page 2 Charger Controls and Indicators Designation Description Function Controller Measures and monitors voltages, currents, power, Module temperature, battery parameters and other data. Enables remote monitoring through a RJ-45 connector. Load Contains the following circuit breakers: Distribution No. 1 - two outputs in parallel Module No.
- Page 3 BroadAccess PSBC12XX Charger - Installation Instructions Items on the rear panel are shown in Figure 2 and described in Table 3. Table 3. Rear Panel Components Designation Description Function Temperature 2 temperature sensors Sense external temperature sensors Load connectors 6 load terminals...
-
Page 4: Parts Required
Parts Required Parts Required Warning: The AC line must be protected by a 32A “D” type circuit breaker. Warning: Each battery set must be protected by a 50A “C” type circuit breaker. Before commencing installation, unpack and identify all parts listed in Table 4. Table 4. - Page 5 BroadAccess PSBC12XX Charger - Installation Instructions . Connect the ground cable from the outdoor cabinet to the PSBC12XX charger ground terminal. . Place temperature sensors near the batteries in the battery compartment. Route the sensor cable to the PSBC12XX charger and connect sensor cable connector to the PSBC12XX charger rear panel temperature sensor connectors.
- Page 6 . Connect the communication cable (RS-232 or Ethernet as required) RJ-45 connector to the PSBC12XX charger controller module RJ-45 connector and route cable to the side so that is is ready for connection to a BroadAccess cage (Ethernet), PC COM port (RS-232) or modem as required.
