Summary of Contents for Seada SD-MV-0401
- Page 1 SD-MV-0401 4K HDMI 4×1 Quad Multi-viewer VER 1.0...
-
Page 2: Table Of Contents
Thank you for purchasing this product For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Surge protection device recommended This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lighting strikes, etc. -
Page 3: Introduction
☆ Control is via on-panel button and remote control. 3. Package Contents ① 1× 4K HDMI 4×1 Quad Multi-Viewer ② 1× 12V/1A DC Power Adapter ③ 1× Remote Control ④ 2× Mounting Ears ⑤ 1× User Manual Website: www.seada.co.uk E-mail: sales@seada.co.uk... -
Page 4: Specifications
Input: AC100~240V 50/60Hz, Output: DC12V/1A Power Supply (US/EU standards, CE/FCC/UL certified) Power Consumption 7.68W (max) Operating 0°C ~ 40°C / 32°F ~ 104°F Temperature Storage Temperature -20°C ~ 60°C / -4°F ~ 140°F Relative Humidity 20~90% RH (non-condensing) Website: www.seada.co.uk E-mail: sales@seada.co.uk... -
Page 5: Operation Controls And Functions
Name Function description Connect to HDMI source device such as DVD HDMI INPUT player or PS4 with a HDMI cable. Connect to HDMI display device such as TV or HDMI OUTPUT projector with a HDMI cable. Website: www.seada.co.uk E-mail: sales@seada.co.uk... -
Page 6: Display Modes
The rest can be done in the same manner. MODE 3: The quad multi-viewer divides four HD inputs and display on a screen. The on-panel four lights is on. Operation method is the same as MODE 2. Website: www.seada.co.uk E-mail: sales@seada.co.uk... -
Page 7: Remote Control
1/2/3/4: Press these buttons to selecting input Audio source. HDMI 4X2 :Press this button to cyclical selection input source (This button can be used only at the MODE 1). Audio: : Mute button. :Press this button to cyclical selection audio output. Website: www.seada.co.uk E-mail: sales@seada.co.uk... -
Page 8: Application Example
8. Application Example TV or Monitor Power Supply INPUT OUTPUT IN 1 IN 2 IN 3 IN 4 HDMI AUDIO DC 12V DVD or Blu-ray Player DVD or Blu-ray Player UHDTV 2.0 Speakers Website: www.seada.co.uk E-mail: sales@seada.co.uk...
