Q-Light STA35SL Series Operating Manual

STA35
OPERATING MANUAL
LED Steady Tower Lamp
Thank you for purchasing Q.Light product. Please read this manual
carefully before installing this product for safe and long use.
▪ High visibility by employing special dispersing lens.
▪ Convenient installation by adopting screw type structure at
bottom side of body.
▪ LED Steady type (supporting flashing type by external control)
▪ Protection Class : IP44
1) STA35SL

▪ General Specification

Model Layer
Voltage
AC/DC12V
AC/DC24V
1
AC110V
AC220V
AC/DC12V
AC/DC24V
2
AC110V
AC220V
AC/DC12V
AC/DC24V
STA35SL
3
AC110V
AC220V
AC/DC12V
AC/DC24V
4
AC110V
AC220V
AC/DC12V
AC/DC24V
5
AC110V
AC220V
SL
SERIES
Current Weight Color
0.16A 0.35Kg
0.08A 0.35Kg
Red-R
0.02A 0.35Kg
0.02A 0.35Kg
0.32A 0.35Kg
0.16A 0.35Kg
Red-R
Green-G
0.04A 0.35Kg
0.04A 0.35Kg
0.48A 0.41Kg
0.24A 0.41Kg Red-R
Amber-A
0.06A 0.41Kg Green-G
0.06A 0.41Kg
0.64A 0.47Kg
Red-R
0.32A 0.47Kg
Amber-A
Green-G
0.08A 0.47Kg
Blue-B
0.08A 0.47Kg
0.8A 0.53Kg
Red-R
0.4A 0.53Kg Amber-A
Green-G
0.1A 0.53Kg Blue-B
White-w
0.1A 0.53Kg
* Current and contact capacity (by 1 layer)
Current
VLOTAGE Inrush current
(Signal)
AC/DC12V 0.16A Abt.4.8A
AC/DC24V 0.08A Abt.2.4A
AC110V 0.2A Abt.0.6A
AC220V 0.2A Abt.0.4A
Outline drawing of
■ STA35SL Series

Cable connection

This product has separate power and signal cable. Please make
sure to connect each cable in accordance with below connection
diagram.
■ DC, AC Steady type (involving built-in buzzer type)
▪ Signal cable(Power cable) : UL1007-NO.22(0.3sq) 400mm
▸ AC / DC Steady type
External Current
contact (Buzzer)
Over 5A 0.015A
Over 3A 0.028A
Over 1A 0.021A
Over 1A 0.038A
