Summary of Contents for Superfly SUPERX8
- Page 1 Trampolines User Manual...
- Page 2 Trampolines This manual covers the assembly, maintenance and recommended use of the following Superfly X models. [SUPERX8] Superfly X Trampoline 8ft [SUPERX10] Superfly X Trampoline 10ft [SUPERX12] Superfly X Trampoline 12ft [SUPERX14] Superfly X Trampoline 14ft [SUPERX15] Superfly X Trampoline 15ft...
-
Page 3: Table Of Contents
Contents Contents Contents Warranty Safety and Usage Trampoline Location Trampoline Parts List Trampoline Assembly Accessory Assembly Trampoline Maintenance... -
Page 5: Warranty
JUMP MAT & SPRINGS: 5 YEARS WARRANTY SAFETY PAD & SAFETY NET: 3 YEAR WARRANTY SUPERFLY ACCESSORY RANGE: 1 YEAR WARRANTY The warranty in respect of the mat and the enclosure net does not cover normal wear and tear (e.g. -
Page 6: Safety And Usage
Trampoline Safety & Usage Specific Use Limitations Do not use trampoline without mature and knowledgable supervision. Do not allow more than one person on the trampoline at any time. Do not use the trampoline if it’s raining. Do not jump onto or o of the trampoline. Do not use a trampoline while under the influence of drugs or alcohol. -
Page 7: Trampoline Location
Trampoline Location Trampoline location is vital to the safety of the jumpers here are our safety recommendations. Make sure you have 8m from the ground of overhead space clear of trees, powerlines or other obstacles. Always have 1m of clear space on all sides of your trampoline and ensure that your ground anchors are securely in the ground to prevent movement. -
Page 8: Trampoline Parts List
Trampoline Parts List Part No. Part Name 10ft 12ft 14ft 15 ft Safety Pad Jump Mat Safety Net Top Rail Feet Lower Net Pole Upper Net Pole Nuts & Bolts Net Pole Spacer Spring Pull Tool Spring Net Pole Screw Bungee Cable Ground Stake... -
Page 9: Trampoline Assembly
Trampoline Assembly Congratulations on your Superfly purchase! Please follow these assembly instructions carefully and you’ll be up and bouncing in no time! 1HR 30MIN 2 ADULTS 2 ADULTS Slot together all Top Rails into pairs and arrange together as shown. 8ft = 3 pairs (6 Top Rails) 10ft = 4 pairs (8 Top Rails) 12ft = 5pairs (10Top Rails) - Page 10 Spread out the jump mat on a flat surface and then place the safety net on top. Go around the net inserting the mats D-rings through the underside of the safety net. After you have done this drag the mat to your desired final location for the trampoline.
- Page 11 Once each of the top rail joins has had springs attached to either side continue adding to the right of each spring pair, continuing until all springs are attached. Nudge the sides of the top rail inward once all springs are attached, this will help the springs to pull the top rails into place.
- Page 12 Insert 2 long screws into the bottom of the lower net pole . Slide spacers onto each of the long screws with the large opening of the leg spacers facing the legs. Finish by inserting the screws through the leg and then securing with a washer and hex nut. Tighten hex nuts until the end of the screw is flush with the top of the nut, do not over tighten.
-
Page 13: Accessory Assembly
Position the trampoline where you would like it to be secured. Note the ground stake is only suitable for areas that have su ciently deep soil. To install the ground stake wrap the tie down around the trampoline leg base and push the stake through the loops. Push the end of the stake into the ground you may need to use a hammer or a mallet to fully insert the stake into the ground. -
Page 15: Trampoline Maintenance
Trampoline Maintenance Your trampoline is a substantial investment for the enjoyment of your family, and it must be noted that improper use or lack of care can lead to early deterioration. Please follow all of the points below to ensure your product lasts as long as possible. - Page 16 For Assistance Contact our exclusive New Zealand retailer Trade Tested 0800 800 880 support@tradetested.co.nz www.tradetested.co.nz...
