Summary of Contents for W&T 57732
- Page 1 Manual Installation, Startup and Application Web-IO Digital 4.0 valid for: #57732 Web-IO Digital, 1x 230V In,1x Relais Out #57832 Web-IO Digital, 230V Relais 1xNO, 1xCO #57838 Web-IO Digital, 230V Relais 4xNO, 4xCO Release 1.33 Juni 2019...
- Page 2 © 02/2017 by Wiesemann und Theis GmbH Microsoft, MS-DOS, Windows, Winsock and Visual Basic are registered trademarks of the Microsoft Corporation. Subject to error and alteration: Since it is posssible that we make mistakes, you mustn’t use any of our statements without verification. Please, inform us of any error or misunderstanding you come about, so we can identify and eliminate it as soon as possible.
-
Page 3: Table Of Contents
General notices................9 Intended use ................9 Electrical safety ................9 EMC ..................11 Batteries ................... 11 3. Installation and Wiring .........14 Installation #57732 ..............14 Wiring #57732 ................14 Installation #57832 ..............18 Wiring #57832 ................18 Installation #57838 ..............22 Wiring #57838 ................22 4. Product Introduction ........25 Hardware Features #57732 .............25... - Page 4 Content SNMP ................30 Modbus-TCP ..............30 In-house applications ............. 30 Actions ..................31 5. Startup ............32 Assigning the IP address ............32 Changing the set IP parameters ..........33 6. Basic Settings ..........34 Configuring Input and Output ..........34 Date / Time ................35 Language / Info ................35 Password ..................35 7 .
- Page 5 Emergency access ..............63 Deleting the password ........... 63 Resetting to factory defaults .......... 64 Warning notices ..............65 12. Technical Data ..........66 Derating ..................66 Technical Data ................67 #57732 ................67 #57832 ................69 #57838 ................71 Subject to error and alteration...
-
Page 6: Legal Notices
Legal notices 1. Legal notices Warning notice system This manual contains notices that must be observed for your personal safety as well as to prevent damage to equipment. The notices are emphasized using a warning sign. Depending on the hazard level the warning notices are shown in decreasing severity as follows. -
Page 7: Qualified Personnel
Legal notices Qualified personnel The product described in this manual may be installed and placed in operation only by personnel who are qualified for the respective task. The documentation associated with the respective task must be followed, especially the safety and warning notices contained therein. -
Page 8: Symbols On The Product
Legal notices Symbols on the product Symbol Erklärung CE Mark The product conforms to the requirements of the relevant EU Directives. WEEE Mark The product may not be disposed of with normal waste, but rather in accordance with local disposal regulations for electri- cal scrap PE marking Terminals with this marking must be... -
Page 9: Safety Notices
Safety notices 2. Safety notices General notices This manual is intended for the installer of the Web-IOs described in the manual and must be read and understood before starting work. The devices are to be installed and put in operation only by qualified personnel. Intended use 1DANGER The Digital Web-IOs manufactured by Wiesemann &... - Page 10 Safety notices The Web-IO may be used only in enclosed and dry rooms. The device should not be subjected to high ambient tempera- tures or direct sunlight, and it should be kept away from heat sources. Please observe the limits with respect to maximum ambient temperature.
-
Page 11: Emc
Safety notices 1NOTE Only shielded network cables may be used for connecting the Web-IOs to the network. In this case the Web-IOs meet the noise immunity limits for industrial applications and the stricter emissions limits for households and small businesses. Therefore there are no EMC-related limitations with respect to the usability of the devices in such environments. - Page 12 Safety notices #57732, 57832 #57838 Press a pointed object against the side latch hook of the housing while pulling the base of the housing out of the top shell. Remove the circuit board stack from the bottom of the housing.
- Page 13 The full Declaration of Conformity for the described device can be found on the Internet data sheet page on the W&T homepage at www.wut.de/57732, www.wut.de/57832 bzw. www.wut. de/57838. Subject to error and alteration...
-
Page 14: Installation And Wiring
Installation and Wiring 3. Installation and Wiring Installation #57732 Installation of the Web-IO 4.0 Digital 1x In, 1xRelay Out must for reasons of contact protection be in an enclosed housing, a sub-distribution unit or a control cabinet. The 45mm (2.5 TE) wide device is then fastened to a 35mm DIN rail. - Page 15 Status Error Reset http:// Web-IO #57732 1x 110-230V~ In, 1x Relais Out The external lead must be connected to the terminal labeled “L1“ , and the neutral conductor to terminal “N“ . WARNING Since the described Web-IO 4.0 is a Protection Class I device, the protection ground must always be connected to “PE”...
- Page 16 Error Reset http:// Web-IO #57732 1x 110-230V~ In, 1x Relais Out Voltages above approx. 80Veff referenced to the “N” terminal are recognized as an “ON” signal and indicated by the green “IN” LED. A switching state must be present for at least 50ms to be reliably detected.
- Page 17 Status Error Reset http:// Web-IO #57732 1x 110-230V~ In, 1x Relais Out The “OUT” LED comes on when the contact is closed. Details about the load capacity of the relay contact can be found in the technical data for the Web-IO.
-
Page 18: Installation #57832
Installation and Wiring Installation #57832 Installation of the Web-IO 4.0 Digital 230V Relais 1xNO, 1xCO, must for reasons of contact protection be in an enclosed housing, a sub-distribution unit or a control cabinet. The 45mm (2.5 TE) wide device is then fastened to a 35mm DIN rail. Wiring #57832 The power and I/O cables are connected to the Web-IO using an 8-pin screw terminal strip with 5mm spacing. - Page 19 Reset Error Error Reset http:// Web-IO 4.0 #57832 Web-IO #57732 230V Relais, 1xNO, 1xCO 1x 110-230V~ In, 1x Relais The external lead must be connected to the terminal labeled “L1“ , and the neutral conductor to terminal “N“ . WARNING Since the described Web-IO 4.0 is a Protection Class I device,...
- Page 20 Reset Error Error Reset http:// Web-IO 4.0 #57832 Web-IO #57732 230V Relais, 1xNO, 1xCO 1x 110-230V~ In, 1x Relais DANGER Switching voltage and supply voltage must be supplied from the same phase or outer conductor. The “OUT” LEDs indicate whether and how a contact is closed.
- Page 21 Installation and Wiring Network connection A normal Ethernet patch cable (min. CAT5) with RJ45 plugs can be used for the network connection. Tx+ Tx- Rx+ 1 2 3 4 5 6 7 8 RJ45 Speed Link Installation and wiring of the Web-IO should be performed by qualified specialists.
-
Page 22: Installation #57838
42279 Wuppertal Warning www.WuT.de Status Error http:// ____ . ____ . ____ . ____ Error Reset Reset http:// #57838 Web-IO 4.0 Web-IO #57732 230V Relais, 4xNO, 4xCO Out 0 Out 1 Out 2 Out 3 1x 110-230V~ In, 1x Relais... - Page 23 Status http:// ____ . ____ . ____ . ____ Error Error Reset Reset #57838 http:// Web-IO 4.0 Web-IO #57732 230V Relais, 4xNO, 4xCO Out 0 Out 1 Out 2 Out 3 1x 110-230V~ In, 1x Relais Last Load Subject to error and alteration...
- Page 24 Installation and Wiring DANGER Switching voltage and supply voltage must be supplied from the same phase or outer conductor. The “OUT” LEDs indicate whether and how a contact is closed. For details on the load capacity of the relay contacts, please refer to the technical data for Web-IO 4.0.
-
Page 25: Product Introduction
Product Introduction 4. Product Introduction Hardware Features #57732 The Web-IO 4.0 Digital 1x110-230V In, 1xRelay Out (herein- after referred to simply as Web-IO) is powered with 230V, can monitor a 230V signal and switch a 230V load. Connections are made via screw terminals. -
Page 26: Hardware Features #57832
Product Introduction Hardware Features #57832 The Web-IO 4.0 230V Relais 1xNO, 1xCO (hereinafter referred to simply as Web-IO) is powered with 230V, can monitor a 230V signal and switch a 230V load. Connections are made via screw terminals. For communication the Web-IO has an RJ45 female for connecting to TCP/IP Ethernet networks. -
Page 27: Hardware Features #57838
Product Introduction Hardware Features #57838 Das Web-IO 4.0 230V Relais 4xNO, 4xCO (hereinafter referred to simply as Web-IO) is powered with 230V, can monitor a 230V signal and switch a 230V load. Connections are made via screw terminals. For communication the Web-IO has an RJ45 female for connecting to TCP/IP Ethernet networks. -
Page 28: Network Security
Product Introduction Network security The Web-IO has an internal firewall. All available network accesses are configurable and must first be enabled by the administrator. By default only browser access, inventorying via Wutility, and the port for initializing firmware updates are enabled. -
Page 29: Application And Access Possibilities
Product Introduction For all other descriptions affecting the configuration, access with Administrator login is required. Application and access possibilities Browser access With password protected access the status of Input, Counter and Output can be monitored in the browser. You can also switch the output with the required access rights. -
Page 30: Rest
Product Introduction REST REST (Representational State Transfer) is another Web-based protocol that can be used to integrate the Web-IO into the environment of Industry 4.0 and the Internet of Things. Web-API - HTTP-Requests/AJAX The status of Input, Counter and Output can be queried using HTTP requests. -
Page 31: Actions
Product Introduction Actions Depending on predefined events on the IOs, the Web-IO can initiate actions such as sending an email message. Other actions include sensing syslog messages or SNMP traps, writing to a file via FTP , sending data via TCP or UDP , or switching its own output. -
Page 32: Startup
Startup 5. Startup Once the Web-IO has been properly installed and wired, the power can be turned on. All three status LEDs should come on briefly. After approx. 5 seconds only the Power LED should remain on. The Status LED may flash. If a valid signal is detected on one of the inputs, the corresponding LED will come on. -
Page 33: Changing The Set Ip Parameters
Startup Netzwerke ohne DHCP Install the Wutility Windows PC program (download at http:// www.WuT.de). If no Windows PC is available, see the Appendix, sub-section Alternatives to IP Address Assignment. When Wutility is started the local subnet is searched and all found W&T network components are listed. -
Page 34: Basic Settings
Basic Settings 6. Basic Settings The rest of the Web-IO configuration is done in the browser. As an address enter the IP address of the Web-IO. Click on Login in the navigation tree and select Administrator as the user. By default no password is assigned, you need only click on the Login button to configure the Web-IO with Administrator rights. -
Page 35: Date / Time
Basic Settings Pulse mode By enabling Pulse mode, when the Output is switched to the ON state it reverts automatically back to the OFF state after the set pulse duration. When turned on again during the pulse, the pulse duration begins to count over again. Reset allowed means the Output may also be switched to the OFF state during a pulse. -
Page 36: Basic Applications
Basic Applications 7 . Basic Applications The Web-IO features a variety of different communication options supports various standard protocols. We recommend enabling only the communication paths actually required in your application. This limits the possibility of unauthorized access and manipulation. First we will introduce the most commonly used communi- cation methods: Browser access... -
Page 37: Io Access
Basic Applications the menu tree and then permanently turn it off a gain using the option above. IO access The Web-IO provides two pre-prepared Web pages for access to Input, Counter and Output: Home The Home page provides an overview of Input, Output and the configured actions. -
Page 38: Sending Email
Basic Applications Direct opening of your own Web page without displaying the navigation tree at: http://<URL/IP of the Web-IO>/user More details on programming your own Web pages can be found in the programming manual for the Web-IO. (Download at: http://www.WuT.de – simply enter the article number of your Web-IO in the search field and select Manual.) Sending email A few basic settings are necessary in order to send email... - Page 39 Basic Applications status, counter values etc. for sending the email. Placeholder Description <ix> State of the inputs No. x (ON/OFF) <ox> State of the outputs No. x (ON/OFF) <cx> Counter state No. x <i> State of all inputs as hex. bit pattern <o>...
-
Page 40: Box-To-Box
Basic Applications Box-to-Box Box-to-Box mode links two Web-IOs to each other over the same network so that the output of the one Web-IO follows the input of the other Web-IO (ON on the input of Web-IO A switches the output of Web-IO B to ON). Box-to-Box mode the idea is to configure one Web-IO as the master and the other as a slave. -
Page 41: Integration Into Existing Systems
Integration Into Existing Systems 8. Integration Into Existing Systems The Web-IO supports several common standards and protocols and can therefore be integrated easily into many existing systems. MQTT After enabling MQTT and configuring in the menu branch Communication paths >> MQTT the Web-IO supports two basic possibilities: 1. -
Page 42: Switching Outputs Using Subscribe
Integration Into Existing Systems Switching outputs using Subscribe Here again you must add a new action. As initiator select MQTT-Subscribe. Then enter the path over which the Topic is send which contains the keyword for switching. For action use Switch output >> Switch this Web-IO output. Then specify to what state the output should be switches and if the state should change. - Page 43 Integration Into Existing Systems istrator password or as “operator” using the user password. Here you can also specify whether REST is permitted to switch the output. Read access For read access REST uses the HTTP command GET. The Web-IO supports three formats for replies to REST requests: •...
- Page 44 Integration Into Existing Systems “system” : “time” : “time” : “2016 - 09 - 09, 09 : 42 : 54” “diagnosis” : [ “time” : “06.09.2016 09 : 42 : 54”, “msg” : “Gerätestatus : OK” “diagarchive” : [ “time” : “06.09.2016 09 : 42 : 54”, “msg”...
- Page 45 Integration Into Existing Systems http://<ip-adresse>/rest/json/iostate/output/0 To remain compatible with the Web-IO products which have more than one output, Index 0 must be specified for Output 0. The following parameters are sent: Set=ON The Web-IO replies with “iostate” : “output” : [ “number”...
- Page 46 Integration Into Existing Systems To receive the replies in one of the other formats, simply replace the keyword json with xml or text. A detailed description of the supported REST requests and the structure of the replies can be found in the Web-IO Programming Manual (download at http://WuT.de.).
-
Page 47: Opc
Integration Into Existing Systems By default the Web-IO is set for OPC mode. To use OPC, you must simply enable OPC access under Communication paths >> OPC and as needed enable switching of the output. For your OPC client to communicate with the Web-IO the W&T OPC server must be installed. -
Page 48: Access To Input And Output
Integration Into Existing Systems wtWebioEA….SessCntrl » wtWebioEA….SessCntrlPassword Whether there is a valid session open can be queried using a GET request to the OID wtWebioEA….SessCntrl » wtWebioEA….SessCntrlConfigMode. (Return 1 = valid session 0 = no session.) A session can be ended using SET to the OID wtWebioEA….SessCntrl »... -
Page 49: Modbus-Tcp
Integration Into Existing Systems Switching the outputs requires a valid session. There is also a corresponding table for the outputs: wtWebioEA….InOut » wtWebioEA….OutputTable » wtWebioEA….OutputEntry » wtWebioEA….OutputState Indexing works just like for the outputs. If a 1 is sent via SNMP-SET, the output switches to ON –... -
Page 50: Modbus-Memory
Integration Into Existing Systems Modbus-Memory Bit range: addresse description memory length read bits read reg. Write bits write reg. (hexadec.) type (byte) with FC with FC with FC with FC 1000 Input 0 0x01, 0x02 1001 Input 1 0x01, 0x02 1002 Input 2 0x01, 0x02... - Page 51 Integration Into Existing Systems 16- and 32-bit range: addresse description memory length read bits read reg. Write bits write reg. (hexadec.) type (byte) with FC with FC with FC with FC 2000 Inputs 0 - 11 16-bit 0x03, 0x04 2002 Outputs 0 - 11 16-bit 0x03, 0x04...
-
Page 52: Actions
Actions 9. Actions The Action principle allows the Web-IO to issue individual alarms and messages – but also to switch the output. This is done based on defined IO states or other events. Up to 12 actions can be stored and managed, where an individual name can be specified for each action. -
Page 53: Interval Timer
Actions Interval Timer The Web-IO can be configured to perform actions at specified times. The times are entered in Cron format. Valid characters: Stands for all valid values in the respective entry field (e.g. all minutes or all hours) Specifies a range of from…to (e.g. weekday “2-4” stands for Tuesday to Thursday, whereas entering “*”... -
Page 54: Mqtt Subscribe
Actions from Port 8888 and using the system password will also cause a reset if the reset port is enabled. MQTT Subscribe If the Web-IO receives the keyword configured as a Topic on the path entered as Topic path, the action is carried. Out. -
Page 55: Email Message
Actions For text messages not only the actual message sent when initiating, but also a Clear message can be stored. The Clear message is sent when the initiator for the action is no longer active – i.e. the normal state is resumed. Sending of messages takes different amounts of time depending on the protocol. -
Page 56: Http Request
Actions HTTP request Another possible action is sending of an HTTP request, such as required by devices like cameras, in order to trigger certain functions. As the HTTP request enter the complete URL with all param- eters expected by the receiving device. Format: http://<Ip/Hostname>/<request>?Parameter1&Parameter2&ParameterN For devices which require authentication with user name and... -
Page 57: Ftp Messages
Actions under Communication paths >> Syslog. All other parameters set4table there are not relevant to sending of syslog messages. FTP messages The Web-IO can save message texts per FTP to a file. To do this FTP support must first be enabled under Commu- nication paths >>... - Page 58 Actions outputs for switching from the browser and HTTP must be enabled. The outputs on older model Web-IOs (#57630, #57631, #57634 und #57637) can also be switched. In this case the HTTP port of the Web-IO must be specified as the TCP port. The outputs must be set in Output Mode Menu.
-
Page 59: Access From Your Own Applications
Access from your own applications 10. Access from your own applications In addition to the numerous standardized access possibilities, the Web-IO also offers the option of accessing from your own application. This can be done either using TCP/IP sockets from the common high-level languages –... -
Page 60: Binary Structures Binary
Access from your own applications If the Web-IO receives no valid command within 30 seconds, it closes the connection and is then free again to open a new connection. The Web-IO behaves the same way when a defective or unknown command is received. Reading the input is generally done by polling. -
Page 61: Http Request
Access from your own applications A detailed description of the supported HTTP binary structures and more details about access using BINARY sockets can be found in the Web-IO programming manual (download at http://www.WuT. de). Follow the Manual link on the data sheet page of your Web-IO. HTTP request In addition to traditional socket accesses the Web-IO can also be addressed directly via HTTP using HTTP requests. -
Page 62: Appendix
Actions 11. Appendix Alternatives for IP address assignment For cases where IP address assignment cannot be done via DHCP using the Wutility tool the Web-IO offers another possi- bility. Assigning the IP address using the ARP command This method can be used when the Web-IO does not yet have an IP address and the entry is 0.0.0.0. -
Page 63: Firmware Update
Appendix sent to its Ethernet address as its own and saves it in non-vol- atile memory. The Web page of the Web-IO is then loaded and all other settings can now be made conveniently using Web-based Management. Firmware update The Web-IO firmware is continually improved to meet the new requirements of ever growing networks. -
Page 64: Resetting To Factory Defaults
Appendix By entering the IP address of the Web-IO as the URL in the browser you are taken to an emergency access Web page where you are offered the option of resetting the passwords. Resetting to factory defaults Use a pointed object to press the reset button recessed in the housing front. -
Page 65: Warning Notices
Appendix Warning notices This manual contains notices that must be observed for your personal safety and for preventing equipment damage. The warning notices are listed below in decreasing level of hazard. DANGER Means that death or severe injury will result if the precau- tionary measure is ignored. -
Page 66: Technical Data
Derating At elevated temperatures the Web-IO is subject to a reduction in the permissible switching current #57732, #57832 At a temperature of up to 42°C a maximum of 16A can be switched. Above this temperature the maximum switching current is reduced according to the curve shown (assuming non-adjacent installation). -
Page 67: Technical Data
(assuming non-adjacent installation). 0°C 10°C 20°C 30°C 40°C 50°C 60°C Umgebungstemperatur Technical Data #57732 General data Housing: Plastic enclosure 90 x 45 x 56 mm (LxWxH) Weight: approx. 140g IP enclosure rating: IP 20 Installation orientation: Fastening / mounting:... - Page 68 Technical Data Working temperature range: 0°C - 52°C above an ambient temperature of 42°C the permis- sible switching current is reduced (see Derating) Storage temperature range: -25°C - 70°C Relative humidity: 5..95% rH (non-condensing) Pollution degree: Operating altitude: 0 .. 2000m above sea level Ventilation: No external ventilation required Electrical data...
- Page 69 Technical Data Protocols: TCP- and UDP- Sockets, Client and Server SNMP incl. traps SMTP email sending OPC server Modbus-TCP Inventorying, group management Response times: Data and switching: typ. 40ms #57832 General data Housing: Plastic enclosure 90 x 45 x 56 mm (LxWxH) Weight: approx.
- Page 70 Technical Data Digital outputs: One relay potential-free change over contact One relay potential-free normaly open contact AC1: 16 A / 250 V AC AC15: 3 A / 120 V 1.5 A / 240 V AC3: 750 W DC1: 16 A / 24 V DC DC13: 0.22 A / 120 V 0.1 A / 250 V max.
- Page 71 Technical Data #57838 General data Housing: Plastic enclosure 90 x 116 x 56 mm (LxWxH) Weight: approx. 330g IP enclosure rating: IP 20 Installation orientation: Fastening / mounting: DIN rail 35mm Battery: CR 1632 Battery life: min. 10 years Ambient conditions Working temperature range: 0°C - 57°C above an ambient temperature of 47°C the permis-...
- Page 72 Technical Data IO and power: one 3x screw terminal, 5mm spacing (Power) two 11x screw terminal, 7,5mm spacing (IOs) Connectable wires: Solid conductor: 0.2 – 2,5 mm2 Stranded: 0.2 – 2.5 mm2 Lead with end ferrule: 0.25 – 2.5 mm2 Only one conductor per clamp! Screw tightening torque: 0,5 ..
