Installation instruction
KIX HP 1 PIN 3011
6 232 111 21 831
= A / N
KIX HP 1 PIN 3030
6 232 111 21 832
= A / N
KIX HP 1 PIN 3055
6 232 111 21 833
= A / N
122mm
4"-25/32
180°
HEADQUARTERS - www.deltalight.com - USA - www.deltalight.us - CANADA - www.deltalight.ca
Application
Floor surface mounted
For exterior and interior use
Color Finish
A - Alu gray
N - Dark gray
Light source
1 x POWERLED WHITE 18W
Ø105mm
Ø4"-1/8
Product description
Surface treated aluminum construction
remote 48Vdc, Class 2 power supply required
Suitable for dry, damp locations or wet locations
600mm
Dust-tight - Protected against water jets
23"-19/32
Weight: 2,2lbs 0,99kg
Options not supplied (not supplied)
6 216 12 00
6 232 10 03
Accessories not supplied (not supplied)
6 232 10 00
6 232 10 03
NORTH AMERICAN EDITION
IP65
JUNCTION BOX
IP67 CONNECTOR
KAP KIX
HONEYCOMB KIX
KIX HP 1 PIN
Conforms to ANSI/UL Std. 2108
Cert. to CAN/CSA Std. 22.2 No. 250.0
Last Update ALLU 16/09/2015
1
Advertisement
Related Manuals for Delta Light KIX HP 1 PIN 3011
Summary of Contents for Delta Light KIX HP 1 PIN 3011
- Page 1 KIX HP 1 PIN Installation instruction KIX HP 1 PIN 3011 6 232 111 21 831 = A / N KIX HP 1 PIN 3030 6 232 111 21 832 = A / N KIX HP 1 PIN 3055 6 232 111 21 833...
- Page 2 KIX HP 1 PIN Installation instruction INSTALLATION LUMINAIRE Accessories SAVE! Use 1/2” conduit or any other local code compliant method! EXAMPLE: KIX PIN HP 6 232 111 21 831 180° OPTION JUNCTION BOX 6 216 12 00 CAUTION! THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE APPLICABLE LOCAL INSTALLATION CODE.
