- Page 1 Refrigerated serve-over counter SAMOS DEEP LINE ASSEMBLY INSTRUCTIONS 21.05.2019 Adres: Tel.: +48 14/662 19 10 e-mail: info@igloo.pl Stary Wiśnicz 289 fax: +48 14/662 19 12 www.igloo.pl 32-720 Nowy Wiśnicz, Poland...
-
Page 2: Table Of Contents
KEY: First issue A, B, ... Rev. index No. of section corresponding to documentation No. IGLOO Stary Wiśnicz 289, 32-720 Nowy Wiśnicz, Tel. 14 662 19 10 / Fax: 14 662 19 12 info@igloo.pl / www.igloo.pl... -
Page 3: Unpack 2
2x flat spanner No. 13 Hex key No. 4 Star screwdriver 2 spirit levels: 2 m long and 0.5 m long IGLOO Stary Wiśnicz 289, 32-720 Nowy Wiśnicz, Tel. 14 662 19 10 / Fax: 14 662 19 12 info@igloo.pl / www.igloo.pl... -
Page 4: Prepare For Line Assembly 3
Remove the rear base board in the same way. Unpack the shelves, screens and worktops Remove the louvre Remove the fans Remove the ventilation grilles IGLOO Stary Wiśnicz 289, 32-720 Nowy Wiśnicz, Tel. 14 662 19 10 / Fax: 14 662 19 12 info@igloo.pl / www.igloo.pl... -
Page 5: Apply The Sealant Mastic 4
Apply the sealant mastic Remove the socket head cap screw near Place the modules (single counters) the top lamp in line IGLOO Stary Wiśnicz 289, 32-720 Nowy Wiśnicz, Tel. 14 662 19 10 / Fax: 14 662 19 12 info@igloo.pl / www.igloo.pl... -
Page 6: Align All Installation Holes 5
• Level each module placing the spirit level as shown on the photo. IGLOO Stary Wiśnicz 289, 32-720 Nowy Wiśnicz, Tel. 14 662 19 10 / Fax: 14 662 19 12 info@igloo.pl / www.igloo.pl... -
Page 7: Install The Fans 6
Install granite worktops It is not necessary to install metal worktops Place the worktops on the set Glue the worktops IGLOO Stary Wiśnicz 289, 32-720 Nowy Wiśnicz, Tel. 14 662 19 10 / Fax: 14 662 19 12 info@igloo.pl / www.igloo.pl... -
Page 8: Seal The Worktops 7
Remove the film from the two-sided profile of night covers Apply adhesive on the profile Install the profile on the granite worktop IGLOO Stary Wiśnicz 289, 32-720 Nowy Wiśnicz, Tel. 14 662 19 10 / Fax: 14 662 19 12 info@igloo.pl / www.igloo.pl... -
Page 9: Adjust Front Glass Panels 8
• Place the connector [detail 28] under the fit part of the previous module [detail 29] and shelf 305 of the next module [detail 30] Place the shelves IGLOO Stary Wiśnicz 289, 32-720 Nowy Wiśnicz, Tel. 14 662 19 10 / Fax: 14 662 19 12 info@igloo.pl / www.igloo.pl... -
Page 10: Place The Screens 9
Install the night covers 1. First install the bottom 2. Then, install the top cover (the shortger cover (the longer one) one) IGLOO Stary Wiśnicz 289, 32-720 Nowy Wiśnicz, Tel. 14 662 19 10 / Fax: 14 662 19 12 info@igloo.pl / www.igloo.pl... -
Page 11: After The Line Assembly And Before The Start-Up, Connect All Plugs Between
IGLOO Stary Wiśnicz 289, 32-720 Nowy Wiśnicz, Tel. 14 662 19 10 / Fax: 14 662 19 12 info@igloo.pl / www.igloo.pl... - Page 12 Issue - May 2019 Address: Tel.: +48 14/662 19 10 e-mail: info@igloo.pl Stary Wiśnicz 289 fax: +48 14/662 19 12 www.igloo.pl 32-720 Nowy Wiśnicz, Poland...
