Edmunds Gages Accu-Setter II User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

How to Use This Manual

Acrobat provides various methods for navigating through a PDF document. The
recommended method of navigating this manual is through the use of the Bookmarks.
To browse using Bookmarks:
Show the Bookmarks list.
By default the manual will open with the Bookmarks list open on the left side of the
document. If you do not see the bookmarks list choose Window > Show Bookmarks to
open the list or click the Bookmarks tab to bring the list to the front of its group.
To expand the bookmark list
Bookmarks can be subordinate to other bookmarks in the list. If a bookmark has
subordinate bookmarks under it then it will have a plus sign next to it. To expand the book
mark list click the plus sign. After the list is expanded a minus sign will be displayed next
to the bookmark. To collapse the list click on the minus sign.
To jump to a topic using its bookmark
Click the bookmark's text in the list and the document will jump to the corresponding page
in the manual.
Additional Navigation Methods:
• To go to the next page, click the Next Page button in the navigation toolbar or status
bar, press the Right Arrow key, press Ctrl (Windows) or Option (Mac OS) and the Down
Arrow key, or choose Document > Next Page.
• To go to the previous page, click the Previous Page button in the navigation toolbar
or status bar, press the Left Arrow key, press Ctrl (Windows) or Option (Mac OS) and the
Up Arrow key, or choose Document > Previous Page.
• To move down one line, press the Down Arrow key.
• To move up one line, press the Up Arrow key.
• To move down one screenful, press Page Down or Return.
• To move up one screenful, press Page Up or Shift+Return.
• To go to the first page, click the First Page button in the navigation toolbar or status
bar, press the Home key, or choose Document > First Page.
• To go to the last page, click the Last Page button in the navigation toolbar or the
status bar, press the End key, or choose Document > Last Page.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Accu-Setter II and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Edmunds Gages Accu-Setter II

  • Page 1: How To Use This Manual

    How to Use This Manual Acrobat provides various methods for navigating through a PDF document. The recommended method of navigating this manual is through the use of the Bookmarks. To browse using Bookmarks: Show the Bookmarks list. By default the manual will open with the Bookmarks list open on the left side of the document.
  • Page 2 ccu-Setter II User’s Manual GAGES Edmunds...

  • Page 3: Table Of Contents

    Table of Contents Preface Manual Revision History Trademark Information Introduction Summary & Features Document Conventions Anti-Static Precautions Glossary of Terms Quick Start Guide Programming Reference Guide System Description Number References Specifications Spare Parts Overall Unit Front Panel Rear Panel Rear Panel Pin Assignments Input/Output Pin Assignments RS-232C 2-10...
  • Page 4 Calibration 3-48 Single Check 3-48 Multiple Check 3-50 Multiple Fixture 3-52 Gage Operation 3-54 Single Check Measurement 3-54 Multiple Check or Multiple Fixture Measurement 3-56 Offloading Gage Results 3-58 Advanced Operation A/E Module Setup Output Jumpers Module Installation A/E Maintenance LVDT Module Setup Jumper Settings Inputs/Outputs...
  • Page 5 Table of Figures Figure 1.1 - Programming Reference Guide Figure 2.1 - Overall Basic unit Figure 2.2 - Front Panel Figure 2.3 - Rear Panel Figure 2.4 - I/O Pins Figure 2.5 - I/O Connections Figure 2.6 - RS232C Pins 2-10 Figure 2.7 - E9310, (2) Ch.

  • Page 6: Manual Revision History I

    Original Issue 6/3/04 Updated I/O cable listed in Advanced Operation section To e #4550200, was #4550203 Update section 4.6, Auto Air Shutoff – 25 pin connector to Port “B” only Trademark Information “Accusetter” is a registered trademark of Edmunds Gages...

  • Page 7: Introduction

    Introduction 1.0 Summary and Features The Edmunds Gages Accusetter II offers many sophisticated features and benefits for durable and robust shop floor operation. The Accusetter II is a microprocessor based gaging column that combines a 101 discrete tri-color LED bargraph display for easy visual monitoring of dimensional measurement characteristics, with an eight digit alpha numeric display for precise size readings and operator prompting messages.

  • Page 8: Document Conventions

    1.1 Document Conventions RUN = Shortcut Programming Key “INCH” = Alphanumeric Display 1.2 Anti-Static Precautions When working inside the Accusetter II cabinet or handling signal conditioning modules use caution to protect against damage from static electricity. Use of an anti-static wrist band or other grounding procedures are recommended.

  • Page 9: Glossary Of Terms

    1.3 Glossary of Terms Absolute displays the check size as the actual part size. An A/E (Air to Electric) transducer converts changes in pneumatic pressure into an electrical signal. +APPROACH (or -APPROACH) are optional user defined programmable values approaching the max and min part limits. AVG (Average) is a function that returns the average check reading.
  • Page 10 An LVDT (Linear Variable Differential Transformer) is an electromechanical transducer that converts the linear motion of its contact tip to an AC voltage which can be interpreted by a readout device. Magnification is the enlargement of an input signal to a usable value that can be interpreted by the readout device.
  • Page 11 A Signal Conditioner is a circuit board that modulates and amplifies the LVDT or A/E signal used by the readout device. A Single Check Program allows the user to program the Accusetter II for one dimensional check. In Setup Mode the user can program the required variables for the par checks and transducers.

  • Page 12: Quick Start Guide

    1.4 Quick Start Guide The following steps must be taken to prepare the Accusetter II for operation. 1) Unpack and setup the unit. • Rotate the front foot 90° from its shipping position. • For air gaging applications, rotate the rear foot 180° from its shipping position and install the filter regulator assembly.

  • Page 13: Programming Reference Guide

    Programming Reference Guide The following reference guide briefly outlines the functions of the programming buttons for the Accusetter II. Figure 1.1 Note: RANGE shortcut key is inactive for air applications. NOTE: If the RANGE is changed the master sizes and part limits must also be reprogrammed.

  • Page 14: System Description

    System Description 2.0 Number References Component Edmunds Gages Number Basic Accusetter II Unit E9300 (2) Channel LVDT Signal Conditioning Module E9310 (4) Channel LVDT Signal Conditioning Module E9320 (1) Channel A/E Signal Conditioning Module E9330 (2) Channel A/E Signal Conditioning Module...

  • Page 15: Specifications

    Max Temperature 50°C/120°F 2.2 Recommended Spare Parts Below is a list of recommended spare parts for the Accusetter II. These items may be ordered separately from Edmunds Gages, they are not included with the basic unit. Part Edmunds Gages P/N Qty.
  • Page 16 2.3 Overall E9300Unit Figure 2.1 - Accusetter II Basic Unit - E9300...

  • Page 17: Front Panel

    2.4 Front Panel The Accusetter II front panel consists of the following items: Bargraph display - The 10 inch, 101 point, three color LED bargraph display is the primary readout for the Accusetter II. When over and under limits are programmed, the bargraph will change colors to visually indicate over or under (red), approaching part limits (yellow), or good parts (green).

  • Page 18: Figure 2.2 - Front Panel

    Figure 2.2 - Front Panel...

  • Page 19: Rear Panel

    2.5 Rear Panel The Accusetter II rear panel contains the following items: Serial Number - The Edmunds Gages serial number is listed at the top of the rear panel. Fuse Locator - Contains a 10 Amp fuse. Power Switch - Use to switch the unit on or off.

  • Page 20: Figure 2.3 - Rear Panel

    Figure 2.3 - Rear Panel...

  • Page 21: Figure 2.4 - I/O Pins

    2.6 Pin Assignments for Rear Panel connectors In/Out A, In/Out B (25 Pin Female DSUB) Figure 2.4 - I/O Pins Pin Number IN/OUT A Description IN/OUT B Description Analog Out 1 “ Analog Out 2 “ Analog Out 3 “ Analog Out 4 “...
  • Page 22 Typical IO Connections - I/O Board #5911013 OUTPUT "SINKING" IO A/B IO A/B LOAD +24 VDC (+) LOAD GOOD RELAY CURRENT FLOW 0 VDC (-) 24VDC Power Suppl y OUTPUT "SOURCING" IO A/B IO A/B LOAD +24 VDC (+) GOOD RELAY CURRENT FLOW...

  • Page 23: Rs-232C

    RS232C (9 Pin Female DSUB) Figure 2.6 - RS-232C Pins Accusetter II Cable External Device ß----------------------------à Chassis Ground. Pin 1 = Chassis Ground. ß----------------------------à (TXD) Transmit. Pin 2 = Receive (RXD) ß----------------------------à (RXD) Receive. Pin 3 = Transmit (TXD) ß----------------------------à Signal Ground. Pin 5 = Signal Ground Note: Pin2 and 3 are jumper selectable based upon the application.

  • Page 24: E9310 (2) Channel Lvdt Signal Conditioning Module

    2.7 E9310 (2) Channel LVDT Signal Conditioning Module The E9310 module is a two-channel signal conditioning amplifier for inductive type transducers such as LVDTs that converts the outputs of the transducers into a conditioned signal for the main controller board. The module is mounted in the lower bay of the Accusetter II.

  • Page 25: E9320 (4) Channel Lvdt Signal Conditioning Module

    2.8 E9320 (4) Channel LVDT Signal Conditioning Module The E9320 module is a four-channel signal conditioning amplifier for inductive type transducers such as LVDTs that converts the outputs of the transducers into a conditioned signal for the main controller board. The module is mounted in the lower bay of the Accusetter II.

  • Page 26: E9330 (1) Channel A/E Signal Conditioning Module

    2.9 E9330 (1) Channel A/E Signal Conditioning Module The E9330 module is a single channel air/electric amplifier which processes pneumatic information from the air tooling and delivers a conditioned signal to the controller board of the Accusetter II. The module is mounted in the lower bay of the Accusetter II. The A/E module also contains a ZERO adjustment knob and a MAG adjustment knob for initial input setup to accommodate the air tooling used..

  • Page 27: E9340 (2) Channel A/E Signal Conditioning Module

    2.10 E9340 (2) Channel A/E Signal Conditioning Module The E9340 module is a two channel air/electric amplifier which processes pneumatic information from the air tooling and delivers a conditioned signal to the controller board of the Accusetter II. The module is mounted in the lower bay of the Accusetter II The A/E module also contains a ZERO adjustment knob and a MAG adjustment knob for each input for initial input setup to accommodate the air tooling used..

  • Page 28: Filter Regulator Assembly

    2.11 Supply Air Filter/Regulator Assembly Any unit supplied with an A/E signal conditioning module will also be supplied with a filter/regulator assembly. The assembly is mounted to the rear foot of the Accusetter II. The regulator is factory preset to 44psi and requires a clean, dry air supply at 60psi min. The regulator output is connected to a fitting on the A/E module that extends out of the 44psi inlet port on the rear panel of the Accusetter II.

  • Page 29: Basic Operation

    Basic Operation 3.0 Set up and Operation Summary The following steps must be taken to prepare the Accusetter II for operation. 1) Unpack and setup the unit. See "Unpacking & Setup " below. 2) Setup signal conditioning module jumpers and install module. See the "Advanced Operation"...

  • Page 30: Unpacking & Setting Up

    3.1 Unpacking & Setting Up Unpacking Ensure that the following items are received when the unit is unpacked: • Basic Accusetter II unit (E9300) • Signal Conditioning Module (E9310 or E9320 air module or E9330 or E9340 electronic module) • Power Cable #4550111 •...

  • Page 31: Figure 3.1 - Base Feet

    Front Mounting Foot Rear Mounting Bracket Figure 3.1 - Base Feet Figure 3.2 - Filter/Regulator Mounting...

  • Page 32: Figure 3.3 - Air Connections

    Figure 3.3 - Air Connections For Air Gaging Application Only...
  • Page 33 Multiple Accusetter II Setup 1) Turn the Accusetter II units upside down and remove the front foot mounting screws. 2) Rotate the front foot 90° from its shipping position so that it is perpendicular to the column and remount as shown above. Up to three columns can be mounted on the same front foot.

  • Page 34: Signal Conditioning Module Setup

    3.2 Signal Conditioning Module Setup For LVDT modules E9310 & E9320 attenuation jumpers must be set to either 1x for standard transducers or 10x for long range transducers. Refer to the "Advanced Operations" section for additional information. For either an LVDT or A/E signal conditioning module a jumper matrix on the board allows it to accept signals in or send signals out to the analog output connector.

  • Page 35: Programming

    3.3 Programming Choose The Proper Program For Your Application: 1) Single-check — One feature is to be measured. 2) Multiple check — Up to four features are to be measured using one gage or fixture. 3) Multiple fixture — Up to four different gages may be used. How To Select The Type Program The First Time: 1) Turn power on with toggle power switch in rear of unit, after the power cord has been hooked-up.
  • Page 36 How To Select A Stored Program From Part Database Memory If a program has already been stored in the memory, and you wish to use it: 1) From Run mode, press the ENTER button and then rotate the ENTER button to display "PART DB".

  • Page 37: Programming Guide

    Accusetter II Programming Guide The Accusetter II system programming guide provides a convenient table for recording programming information. A brief explanation of the program guide follows: The top section of the programming guide lists the program type, signal conditioning information, scale, and input magnification and polarity. Any signals bussed in or out are also listed.

  • Page 38: Gaging Formulas

    Gaging Formulas The gaging formula under FUNCTION on the Accusetter II allows the user to add, subtract, multiply, or divide inputs from transducers A, B, C, and D. The Accusetter II requires a gaging formula for all applications programmed in the Multiple Check Multiple Fixture programs.
  • Page 39 An example of various multipliers as related to diameter measurement follows: 3-11...
  • Page 40 The last consideration to complete the formula is the gaging function. See examples below: 3-12...
  • Page 41 Multiple Check Formulas If the Accusetter is programmed for multiple check operation then the results of checks 1, 2, and/or 3 can be combine algebraically. For an example of a multiple check application consider and air plug that measures a part ID at two elevations. The large diameter is measured with input A and displays the large diameter size as check #1.
  • Page 42 Selecting Full Scale Value All Edmunds air tooling is marked with the full scale range it was intended to work with. Since overall range of air tooling is limited, our tooling is designed to operate on one scale only. Random switching of ranges may affect the performance and linearity of the tooling. Using tooling manufactured for a type of system other than Edmunds’...
  • Page 43 PROGRAMMING - SINGLE CHECK MEASUREMENT 3-15...
  • Page 44 PROGRAMMING - SINGLE CHECK MEASUREMENT 3-16...
  • Page 45 PROGRAMMING - SINGLE CHECK MEASUREMENT Programming SETUP Options 1) With the column in RUN mode, Press the ENTER button and then rotate the ENTER button until "SETUP" is displayed. 2) Press the ENTER button. 3) Rotate the ENTER button to select "XDUCER", "DEFINE" or "PART NAME" and then press the ENTER button.
  • Page 46 PROGRAMMING - SINGLE CHECK MEASUREMENT Pol/Mag 1) Rotate the ENTER button until "POL/MAG" is displayed and then press the ENTER button. 2) Rotate the ENTER button to select "INPUT A" or "INPUT B" and then press the ENTER button. A numerical value with a polarity (+ or -)sign will be displayed.
  • Page 47 PROGRAMMING - SINGLE CHECK MEASUREMENT Range 1) Rotate the ENTER button until "RANGE" is displayed and then press ENTER. 2) Rotate the ENTER button until the desired full scale value is displayed and then press enter. Refer to the Accusetter program guide for the correct range for a given application.
  • Page 48 PROGRAMMING - SINGLE CHECK MEASUREMENT Master This menu allows the operator to select which masters will be used to calibrate the gage and to program the correct master values. For example a two master system uses a MAX and MIN master while a single master system would use only the ZERO master.
  • Page 49 PROGRAMMING - SINGLE CHECK MEASUREMENT Saving the Program 1) Press the RUN button. "CANCEL" will display. 2) Rotate the ENTER button to display "SAVE" and then press the ENTER button to save the setup. 3-21...
  • Page 50 PROGRAMMING - MULTIPLE CHECK MEASUREMENT 3-22...
  • Page 51 PROGRAMMING - MULTIPLE CHECK MEASUREMENT 3-23...

  • Page 52: Multiple Check Programming

    PROGRAMMING - MULTIPLE CHECK MEASUREMENT Multiple Check Programming Programming SETUP Options 1) With the column in RUN mode, Press the ENTER button and then rotate the ENTER button until "SETUP" is displayed. 2) Press the ENTER button. 3) Rotate the ENTER button to select "XDUCER", "DEFINE" or "PART NAME" and then press the ENTER button.
  • Page 53 PROGRAMMING - MULTIPLE CHECK MEASUREMENT Pol/Mag 1) Rotate the ENTER button until "POL/MAG" is displayed and then press the ENTER button. 2) Rotate the ENTER button to select "INPUT A", "INPUT B", "INPUT C", or "INPUT D" and then press the ENTER button. A numerical value with a polarity (+ or -) sign will be displayed.
  • Page 54 PROGRAMMING - MULTIPLE CHECK MEASUREMENT CHK 1, CHK 2, CHK 3, CHK 4 Select the check that is to be set up by: 1) Rotate the ENTER button until the desired check number is displayed and then press ENTER. 2) For each check in the gage setup the FUNCTION, RANGE, LIMITS, MASTERS, and CHECK NAME per the following instructions.
  • Page 55 PROGRAMMING - MULTIPLE CHECK MEASUREMENT MPL CHK 1) Rotate the ENTER button to select "CHK 1", "CHK 2", or "CHK 3" and then press ENTER. 2) A numerical value with a polarity sign (+ or -) will display. Enter the correct magnification numeral. If this check is not being used, change number to 0.
  • Page 56 PROGRAMMING - MULTIPLE CHECK MEASUREMENT Limits MAX, MIN, +APPR, -APPR 1) Rotate the ENTER button until "LIMITS" is displayed and then press the ENTER button. 2) Rotate the ENTER button until "MAX", "MIN", "+APPR", or" - APPR" is displayed and then press the ENTER button. 3) Rotate the ENTER button to select whether the limit will be "ON"...
  • Page 57 PROGRAMMING - MULTIPLE CHECK MEASUREMENT Master This menu allows the operator to select which masters will be used to calibrate the gage and to program the correct master values. For example a two master system uses a MAX and MIN master while a single master system would use only the ZERO master.
  • Page 58 PROGRAMMING - MULTIPLE CHECK MEASUREMENT Saving the Program 1) Press the RUN button. "CANCEL" will display. 2) Rotate the ENTER button to display "SAVE" and then press the ENTER button to save the setup. 3-30...
  • Page 59 PROGRAMMING - MULTIPLE FIXTURE MEASUREMENT 3-31...
  • Page 60 PROGRAMMING - MULTIPLE FIXTURE MEASUREMENT 3-32...

  • Page 61: Multiple Fixture Programming

    PROGRAMMING - MULTIPLE FIXTURE MEASUREMENT Multiple Fixture Programming Programming SETUP Options 1) With the column in RUN mode, Press the ENTER button and then rotate the ENTER button until "SETUP" is displayed. 2) Press the ENTER button. 3) Rotate the ENTER button to select "XDUCER", "DEFINE" or "PART NAME" and then press the ENTER button.
  • Page 62 PROGRAMMING - MULTIPLE FIXTURE MEASUREMENT Pol/Mag 1) Rotate the ENTER button until "POL/MAG" is displayed and then press the ENTER button. 2) Rotate the ENTER button to select INPUT A, INPUT B, INPUT C, or INPUT D and then press the ENTER button. A numerical value with a polarity (+ or -)sign will be displayed.
  • Page 63 PROGRAMMING - MULTIPLE FIXTURE MEASUREMENT 6) Enter the correct polarity by pressing the enter button to move to the + or - position and rotate ENTER button to select your choice. (As standard, it should be + polarity). 7) Press RST button to display "INPUT A". 8) If not using any other inputs, set numerical values for those not in use to 0 by using the same procedure described in steps 4.
  • Page 64 PROGRAMMING - MULTIPLE FIXTURE MEASUREMENT Select Limits 1) Rotate the ENTER button to display LIMITS. 2) Press the ENTER button. MAX/MIN 1) "MAX" will display. 2) Press the ENTER button. "ON" or "OFF" will display. 3) Rotate the ENTER button to display ON and then press the ENTER button. 4) Rotate the ENTER button until the maximum size or deviation is displayed.
  • Page 65 PROGRAMMING - MULTIPLE FIXTURE MEASUREMENT Class (Optional) 1) Rotate the ENTER button to display "CLASS" and press the ENTER button. "EQUAL" or "SELECT" will display. 2) Rotate the ENTER button to display your choice and press the ENTER button to select. "QTY"...
  • Page 66 PROGRAMMING - MULTIPLE FIXTURE MEASUREMENT Fixture Names 1) Rotate the ENTER button to display check name. 2) Press ENTER button. "FXT 1" will display. 3) Press enter button. The first character will flash. To change, rotate ENTER button left or right until desired character displays. 4) Press ENTER button to move to next character.
  • Page 67 PROGRAMMING - SYSTEM OPTIONS Programming SYSTEM Options This area of programming allows you to conduct Accu-Setter system tests, program information downloading (communication), passwords, check names, the auto reset timer, and part databases. If you will not be using any of these features, proceed to the Calibration section of this manual.
  • Page 68 PROGRAMMING - SYSTEM OPTIONS COMM Menu The communications menu allows the operator to program the Accusetter to download data to, or receive communications from, an external device and ,with multiple check or multiple fixture programs, to setup signals to buss to other columns. NOTE: See section 4.4, Communication in the Advanced Operation section of the manual for additional technical specification.
  • Page 69 PROGRAMMING - SYSTEM OPTIONS Buss In/Buss Out Setup Note: For multiple check and multiple fixture programs BUSS IN and BUSS OUT options are available, for column to column communications. These signal are used with the I/O "A" and "B" 25 pin connections. 1) From the COMM menu rotate the enter button to display "BUS OUT"...
  • Page 70 PROGRAMMING - SYSTEM OPTIONS SECURITY Menu 1) Rotate the enter button to display "SECURITY" and then press the ENTER button. 2) "MAST" with a numerical value will display. Note: Master password must be entered now to allow programming your own password. Contact Edmunds Gages if master password is unknown.
  • Page 71 PROGRAMMING - SYSTEM OPTIONS AUTO AIR Menu (Optional) If the optional automatic air shutoff is installed then this menu is available to program the time delay before air shutoff or to disable the auto air shutoff. See the Auto Air Shutoff in the Advanced Operation section 4.6 for more information.

  • Page 72: Inputs Setup

    3.4 Input Setup Setting A/E Mag and Zero for Air Gage NOTE: Inputs MUST be setup from the Calibration, Inputs menu not in RUN mode. In Run mode the master corrections are applied. In Calibration mode the raw input readings are displayed. If the gage tooling is an airplug or air ring using an (1) channel or (2) channel A/E module use the following procedure to set zero and magnification for each input(s) using a set of max and min masters.
  • Page 73 For example, for the above example after turning the mag knob the displayed reading may be (+.0005) + (.0012) = +.0017 or it could read (+.0005) - (.0012) = -.0007. This depends on the polarity of the check. 10) After adjusting the mag knob, turn the zero knob in the same direction as the mag knob to adjust the displayed reading to equal the deviation of the MIN master value on the calibration sheet.
  • Page 74 Setting up LVDT Inputs Prior to calibrating the gage the LVDT inputs must be properly positioned in the tooling. Use the following procedure to setup each LVDT input. 1) Press the CAL button. 2) Rotate the ENTER button until "INPUTS" is displayed and then press ENTER. 3) Rotate the ENTER button to select the desired full scale value to use for input setup and then press ENTER.
  • Page 75 3.5 Calibration NOTE: Prior to performing the automatic calibration procedure, the Air to Electric or LVDT inputs need to be properly setup, see Input Setup. Single Check Application Two Master System 1) Press the CAL button. 2) Rotate the ENTER button until "MASTER" is displayed and then press ENTER. The check name will be displayed.
  • Page 76 Auxiliary Master Systems 1) Press the CAL button. 2) Rotate the ENTER button until "MASTER" is displayed and then press ENTER. The check name will be displayed. 3) Press the ENTER button. "INS AUX" will be displayed. 4) Place the Auxiliary master into gage position and press ENTER. "GAGE AUX" will be displayed.
  • Page 77 Multiple Check Applications In a multiple check program the Accusetter II will automatically turn mastering "ON" for all checks with masters programmed when calibration mode is activated. During the calibration procedure the Accusetter will automatically detect which checks are returning valid results, that is the inputs are not off scale and a different max and min reading is detected, and will record the calibration results for those checks.
  • Page 78 Zero Master Calibration 1) From RUN mode, press the CAL button. 2) Rotate the ENTER button until "ZERO" is displayed and then press ENTER. "INS ZERO" will be displayed. NOTE: All checks that are programmed with a ZERO master will be turned "ON" by default and will therefore be gaged at the same time.
  • Page 79 Multiple Fixture Application In a multiple fixture program the Accusetter II will automatically turn mastering "ON" for all checks with masters programmed when calibration mode is activated. During the calibration procedure the Accusetter will automatically detect which checks are returning valid results, that is the inputs are not off scale and a different max and min reading is detected, and will record the calibration results for those checks.
  • Page 80 Zero Master Calibration 1) From RUN mode, press the CAL button. 2) Rotate the ENTER button until "ZERO" is displayed and then press ENTER. "INS ZERO" will be displayed. NOTE: All checks that are programmed with a ZERO master will be turned "ON" by default and will therefore be gaged at the same time.

  • Page 81: System Programming

    3.6 Operation Single Check Operation To place the Accusetter in Run mode for normal gaging operation press the RUN button. The operation of the Accusetter in Run mode is dependant on the function that is selected in the define, function menu. For a single check measurement the function options are Bypass, +Peak, -Peak, or TIR.
  • Page 82 -PEAK 1) Place the part to be checked in gage position. 2) Press RST. 3) Rotate the part or reposition the gage depending on the particular application. The bargraph and alphanumeric displays will show the minimum reading since the RST button was pressed.
  • Page 83 Multiple Check or Multiple Fixture Operations To place the Accusetter in Run mode for normal gaging operation press the RUN button. The operation of the Accusetter in Run mode is dependant on the function that is selected in the define, function menu. For a multiple check or multiple fixture measurement the function options are Bypass, Avg, +Peak, -Peak, TOL Check, or TIR.
  • Page 84 -PEAK 1) Place the part to be checked in gage position. 2) Press RST. 3) Rotate the part or reposition the gage depending on the particular application. The bargraph and alphanumeric displays will show the minimum reading since the RST button was pressed.
  • Page 85 Offloading Gage Results You may opt to offload the readings to a data collector, personal computer, or printer. NOTE: Prior to offloading data, the external device variables under the Communication section of the system programming menu must be setup. See System Programming, External Device.

  • Page 86: Advanced Operation

    Advanced Operation 4.0 A/E Signal Conditioning Module Setup The E9330 (1) channel and E9340 (2) channel Air/Electronic modules convert pneumatic pressure from air gage tooling into a calibrated electrical signal. The module contains an air/electronic transducer assembly for each input and an output pin selection jumper. Figure 4.1 - A/E Module E9330 or E9340 Power to the column must be turned off prior to installing or removing a signal conditioning module.

  • Page 87: Figure 4.2 - Output Pin Jumpers

    Output Pin Selection Jumper The electronic signal from the A/E transducer may be output to another Accusetter II or to an external device connected to the analog buss. The pin on which the signal is output, from 1 to 6, can be selected using the "A OUT" jumper. The "B OUT" jumper is not used on the E9330 module.
  • Page 88 A/E Module Installation 1) Turn off the main power switch on the rear of the Accusetter II and unplug the power cord. Power to the column must be turned off prior to installing or removing a signal conditioning module. 2) Ensure all jumpers are properly set for the application to be run. The A & B Out jumper only needs to be set if the signal is to be used on another column or external device.
  • Page 89 4.1 Air/Electronic Maintenance Maintenance of the A/E transducer may be required if there is extreme difficulty in setup or erratic readings on the Accusetter II. Power to the column must be turned off prior to installing or removing a signal conditioning module.

  • Page 90: Figure 4.3 - A/E Block

    Figure 4.3 - A/E Block...
  • Page 91 4.2 LVDT Signal Conditioning Module Setup The E9310 (2) channel and E9320 (4) channel LVDT signal conditioning modules are signal conditioning amplifiers. The module plugs into the lower bay of the Accusetter II and converts the outputs of the transducers into a useable format for the main controller board.

  • Page 92: Output Jumpers

    LVDT Jumper Settings The following may be set on the signal conditioning module by means of jumpers: Buss out pin assignments, buss in pin assignments, bussed in signal sum and difference, and input amplification. Input/Output Jumpers To buss a signal from one Accusetter II to another connect an interface cable, Edmunds #4550200, from the Input/Output "A"...
  • Page 93 Figure 4.5 - Input/Output Jumpers...

  • Page 94: Figure 4.6 - Attenuation Jumpers

    Attenuation Jumpers Jumpers J3, J4, and J10 allow the input attenuation to be set to 10x or 1x. For standard transducers the jumpers should be set to 1x. If long range transducers are to be used the jumpers should be set to 10x. When an E9310 or E9320 module is used on an Accusetter II the column will automatically recognize the setting of the 1X/10X jumper and program the column accordingly.

  • Page 95: Calibration

    LVDT Module Installation 1) Turn off the main power switch on the rear of the Accusetter II and unplug the power cord. Power to the column must be turned off prior to installing or removing a signal conditioning module. 2) Ensure all jumpers and switches are properly set for the application to be run. 3) Slide the LVDT module into the lower bay and secure it in position with the two thumb screws on the front panel.

  • Page 96: Obsolete Signal Conditioning Modules

    A new Accusetter II will be supplied with an E9310, E9320, E9330, or E9340 signal conditioning module, however the Accusetter II is compatible with the obsolete signal conditioning modules listed below: Obsolete Signal Conditioning Modules Edmunds Gages Number (2) Channel LVDT Signal Conditioning Module E9010 (4) Channel LVDT Signal Conditioning Module...

  • Page 97: Rs232

    4.4 Communications RS232 Communications Figure 4.7- RS-232C The Accusetter II's RS232C serial port provides a path to communicate to external devices such as a Data Collector, Personal Computer (PC), or serial printer. The RS232C connector is a standard 9-pin “D” style and is located on the back of the Accusetter II. The following pins on the connector are utilized for communications: Accusetter II Cable...
  • Page 98 Offloading Data Current measurement results can be offload through the RS232C connection. The offloaded data consist of the check name, measured numeric value, scale (inch or metric), status (good, over or under), and class. There are three ways of initiating data offload from the Accusetter II. They are as follows: The operator can initiate offload by pressing the “ENTER”...
  • Page 99 RS-232 Data Collector Offloading The operator can initiate the data offload to a Data Collector, or data can be solicited by a data collector automatically. This is performed by *pressing the enter button twice while the Accu-Setter is in the RUN mode. For the data collector to automatically solicit data, an “EEH”...
  • Page 100 RS-232 Personal Computer The PC Data protocol allows someone with knowledge of RS-232 communications to write a software program to communicate to the Accu-Setter. The PC Data protocol consists of two main categories: 1. Uploading measurement data 2. Downloading command codes The PC is considered the Master in the system.
  • Page 101 (RS-232 Personal Computer, continued) The PC can request two types of numeric measurement data from the AccuSetter: 1. Current Data — Current measurement readings being displayed on the Accu-Setter. 2. Saved Data — Measurement readings stored in the Accu-Setter’s memory. The Accu- Setter can store the active reading.
  • Page 102 (RS-232 Personal Computer, continued) If the Accu-Setter is executing the MPF FXT program, then the response packet will just contain the displayed fixture. The response packet will contain five fields for each feature being measured. Each field will be separated by a semicolon (;) delimiter. If their is no data for a particular field, the delimiter will still be included in the response packet.
  • Page 103 (RS-232 Personal Computer, continued) The PC can also simulate the push-button panel on the Accu-Setter through command codes. Command codes consist of a single byte which is not station dependent. The Accu-Setter does not transmit a response packet on receipt of a command code. Command codes transmitted from the PC will affect all of the Accu-Setters connected to the daisy chain serial link.
  • Page 104 RS-232 Upload/Download The format for a parameter upload response will consist of 192 bytes plus the bcc and eot characters: <192 bytes><bcc><eot> (Mark Parity) The bcc is calculated by performing the XOR function on the 192 bytes of packet data. A complete parameter upload will consist of the PC requesting four parameter packets (30h - 33h) from the Accu-Setter.
  • Page 105 The format for a parameter download packet will consist of 192 bytes including the bcc and the eot characters: <d><station#<packet#> (Mark Parity) <192 bytes><bcc><eot> (Space Parity) The bcc is calculated by performing the XOR function on the 192 bytes of packet data. The format for a parameter download response packet will consist of a single byte: <ack>...
  • Page 106 Accu- Setter. The Accu-Setter will communicate to any generic serial printer by transmitting an “ACSII” data string. Print Format: • at the top of each new page: EDMUNDS GAGES <cr><lf> ACCU-SETTER II<cr><lf> • for each initiated PRINT: <cr><lf> <check 1 name> <check value> mm GOOD CLASS 01 <cr><lf>...

  • Page 107: Input/Output Board

    4.5 Input/Output Board Accusetter I/O Board (P/N 5911013) Functions The Accusetter I/O board provide the user with various I/O functions. All I/O functions are optically isolated from the rest of the Accusetter electronics and are available at the rear panel I/O A and B connectors. Summary of I/O signals Inputs •...

  • Page 108: Typical I/O Connections

    Typical IO Connections - I/O Board #5911013 OUTPUT "SINKING" IO A/B IO A/B LOAD +24 VDC (+) LOAD GOOD RELAY CURRENT FLOW 0 VDC (-) 24VDC Power Supply OUTPUT "SOURCING" IO A/B IO A/B LOAD +24 VDC (+) GOOD RELAY CURRENT FLOW 0 VDC (-)
  • Page 109 E8204 Connections The Accusetter Relay Interface board (5911013) board contains a programmable jumper (J2) that connects the Relay Output Common P19 to the Isolated Common P24. This option allows the relay interface board (5911013) to connect to legacy relay interface boxes (E8204, etc.). This jumper should be placed in the idle position during all other times.
  • Page 110 4.6 Automatic Air Shutoff (Optional) The optional automatic air shutoff can be used with any air gaging application. The automatic air shutoff will shut the air flow to the tooling to a minimal level when the tooling is not being used to measure a part and return the air flow to the normal operating level when the tooling is place in gage position in a part.
  • Page 111 Auto Air Setup NOTE: The air check(s) mag and zero must be properly setup and the gage calibrated before setting up the auto air shutoff. 1) From Run mode press the ENTER button and then rotate the ENTER button until "SYSTEM"...
  • Page 112 Selecting Time Delay for Auto Air Shutoff 1) With the column in RUN mode press the ENTER button. 2) Rotate the ENTER button until the display reads "SYSTEM" and then press the ENTER button. 3) Rotate the ENTER button until the display reads "AUTO AIR" and then press the ENTER button.

  • Page 113: Troubleshooting

    Perform A/E maintenance procedures Damaged air tooling/ Inspect air tooling for damage or wear on nozzles. If repair required contact Edmunds Gages. Incorrect Air Supply Pressure/ Check air supply to filter/regulator assembly is 60 psi min. Check Accusetter II regulator set to 44 psi.
  • Page 114 Damaged air tooling/ Check the air tooling for damaged or plug nozzles. If repair is required contact Edmunds Gages. Improper connection to signal conditioning module/ Ensure the air line from the tooling is securely connected to the correct signal conditioning port and that there are no air leaks in the line.
  • Page 115 the results in real time. Input/Output signal not Interface cable not connected properly/ reading properly Ensure the interface cable is securely connected form the "Output" plug on the first column to the "Input" plug of the second column. Incorrect Input/Output jumper settings/ Ensure the Input and Output jumpers on the signal conditioning modules are set properly 4-30...
  • Page 116 Gage Calibration Errors Cause/ Error Solution SAT HEAD Cause: Reading from gage is too far beyond full scale display of column. This can occur either during adjustment or calibration. Solution: Readjust air inputs or position of LVDT gage head. MAX = MIN Cause: The gaged value of MAX equaled the gaged value of the MIN during the mastering routine.

  • Page 117: Single Check
