Summary of Contents for Secced SC-402-6
- Page 1 Thanks for choosing SECCED’s Traveler Crane For your reference Date of purchase Name and address of the distributor...
- Page 2 If it needs to be adjusted, power supply should be switched off. 16. In the interest of safe crane operation, abrupt or sudden movement of the crane should be avoided. 17. Only original accessories manufactured by Secced may be used with the crane.
-
Page 3: Table Of Contents
Content Setup .....................4 1. Dolly ....................4 2. Tripod ....................4 3. Central Pivot Section ................5 4. Arm ....................5 5. Camera and remote head ..............6 6. Balance steel cable ................8 7. Tension steel cable ................8 8. Controlling bar ..................9 9. Counterweight ................10 10. -
Page 4: Setup
Setup Dolly The dolly of the crane system is the foldable dolly in ‘Y’ pattern. Unfold the leg by depressing the leg locking pin (Figure 1), and pull out the folding leg. Revolve 120 degree till the leg locking pin lock the legs in the open position. -
Page 5: Central Pivot Section
Leveling bubble Figure 5 Locking sleeve of tripod Protective sleeve of tripod Figure 6 Central pivot section Central pivot section should be installed on the tripod and allow the crane arm to swivel horizontally. As shown in Figure 7, please put the central pivot section on tripod and tighten it with locking knob (Figure 8). -
Page 6: Camera And Remote Head
Figure 9-2 Figure 9-1 Figure 9-3 Figure 9-3 Attention: The right mount counterweight should be mounted after installation of all arm is completed to avoid any falling down of crane arm. Camera and remote head To install the remote head, simply plug the remote head onto the mounting frame, and turn locking lever to tighten it. - Page 7 E. Locking lever for camera plate B. Tilt gear F. Camera adaptor C. Screws G. Tilt motor D. Camera plate Figure 11-3 Secced SC-3950 Camera adaptor Iris motor Iris gear Figure 12 Motor frame Focus motor Focus gear As shown in figure 12, install the focus and iris control (lens control motor) on the lens.
-
Page 8: Balance Steel Cable
Due to influence of cables on the camera, it may not move when it reaches any positions. Under such a situation, influence of such a force should be minimized. Balance steel cable Front Figure 13-2 Cable pressing plate Cable guide Back Figure 13-1 Turnbuckle... -
Page 9: Controlling Bar
Figure 17 Figure 15 A. Tension cable B. Hook C. Tension cable supporting rod D. Balancing cable E. Turnbuckle Figure 16 Controlling bar As shown in Figure 17, to install the controlling bar on the counterweight rod and tighten the locking knob. -
Page 10: Counterweight
Counterweight Install the counterweight (optional) on counterweight rod as shown in Figure 17, and adjust the weight to enable the crane to keep balance. 10. Power supply box Fixing pin Supporting plate for monitor Power supply box Figure 19 The power supply box is for supplying the power to the camera, remote head, controlling bar and monitor. - Page 11 Controlling bar cable Integrated controlling bar Socket Power supply cable Figure 20 Figure 21 Remote head controlling bar Crane cable Lens control box For ‘IRIS’ control For ‘FOCUS’ control Lens control cable For ‘ZOOM’ control Figure 22...
-
Page 12: Operation
For remote head controlling bar Crane Cable Connected For pan motor For tilt motor For ‘ZOOM’ control Connected Lens control box Figure 23 Lens control cable For ‘FOCUS’ and ‘IRIS’ control Operation The panels of two controlling bars are shown as follows. Control of remote head There is a joystick on the remote head controlling bar to control panning and tilting of remote head, meanwhile there are also some knobs and switches on this controlling bar. - Page 13 switch is used for changing direction of ‘FOCUS’. The knob above the lens control bar is used for adjusting Iris. CON/FUJI switch is for switching the control between Canon lens and Fujinon lens. VCR is to start recording. Figure 24 Remote head controlling bar Camera controlling bar Figure 25...
-
Page 14: Specifications And Technical Data
Specifications and Technical Data Length 1.64m (including dolly) Height of central axis 1.45m (excluding dolly) 60°(including dolly) Elevation angle 50°(excluding dolly) Rotation radius of pan & tilt head 4.34m Highest point of pan & tilt head 5.6m Payload of pan & tilt head 10kg Horizontal: Unlimited Rotation angle of pan &... -
Page 15: Packing List
Packing List No.1 Case Number Name Quantity Remark Remote head With pan and tilt motors Remote head controlling bar Camera controlling bar Crane Cable Power cable for controlling bar Controlling bar cable Video cable Power cable for camera Power cable for power supply box Power cable for monitor Bounding strap for monitor Lens control cable... -
Page 16: Appendix
Appendix Crane Cable Lens control cable... - Page 17 Controlling bar cable Video Cable...
