Installation
& Operation Instructions
Deluxe Stainless Steel LED Light
Model 23050A/23051A
23150A/23151A
To avoid the risk of accidents or
damage to this product, it is essential
to read these instructions thoroughly
EN Edition
before this product is installed and used.
Jul 2017
Arrow.com.
Downloaded from

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 23050A and is the answer not in the manual?

Questions and answers

Summary of Contents for marinco 23050A

  • Page 1: Operation Instructions

    Installation & Operation Instructions Deluxe Stainless Steel LED Light Model 23050A/23051A 23150A/23151A To avoid the risk of accidents or damage to this product, it is essential to read these instructions thoroughly EN Edition before this product is installed and used.
  • Page 2: Table Of Contents

    Contents Product Highlights ....................2 Specifications ......................2 Installation ......................... 2 Spot Light Installation ..................2 Remote Control Bracket Installation ..............4 Mounted Remote Control Installation ..............4 Electrical Wiring ....................5 Operation ........................6 Caution ........................6 Maintenance ......................6 Troubleshooting .......................
  • Page 3: Product Highlights

    Product Highlights  Certified in compliance with IEC 60598-2-5:1998 (safety), EN 55015 + EN 61547 (CE), EN 301 489-1/-3 + EN 300 440-2 (RF), FCC Part 15B/15C (FCC), EN 60945 (marine), IP67.  350° two speed horizontal rotation, 60° vertical range. Digital remote control signal reliable and resistant to interference.
  • Page 4 ! Do not mount on metal surface; remote control will not work. ! Provide at least 1-1/4 inch (32 mm) clearance underneath the mounting surface to allow reception of remote signal. Remote control may not work if clearance is insufficient. Arrow.com.
  • Page 5: Remote Control Bracket Installation

    Remote Control Bracket Installation (Optional) 1. Take off mounting plate from the back of bracket. Secure mounting plate on selected location with the two (2) self-tapping screws that come with the product. 2. Fit bracket to mounting plate as shown in below. !...
  • Page 6: Electrical Wiring

    Electrical Wiring 1. Provide DC 12 Volt input power for 23050A / 23051A (Provide DC24 Volt input power for / A) 2. Protect input power positive (+) terminal with 10 A fuse or circuit breaker. 3. Use 12-gauge power cable for wiring distance not more than 30 ft (9 m), and use 10-gauge power cable for longer wiring distance.
  • Page 7: Operation

    Operation Remote Control 1. Press arrow key to control rotation of the spot light. 2. The speed switch (see picture below) is for horizontal rotation only. 3. Same operation for mounted remote control. Caution ! The LED spotlight has over-heating protection when left running for too long. Upon the activation of the over-heating protection system, the product will turn off 6 or all 12 LED bulbs.
  • Page 8: Troubleshooting

    5. Push any button to check if the LED indicator illuminate. Which are replaceable parts … 1. Controls: Troubleshooting Installation work and repairs to electrical components of this product must only be carried out by a suitably qualified and competent person in accordance with current local and national safety regulations.
  • Page 9: Limited Warranty

    Limited Warranty For one (3) years from the date of original purchase, Marinco will, at its discretion, repair or replace for the original consumer, free of charge, any parts found defective in material or workmanship. All transportation charges under this warranty must be borne by the consumer.
  • Page 10 All rights reserved / EN- Feb-2017 Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from...
