Thank you for your purchase! We hope
your family Enjoys our products as much as
we do!
Our Patented Ground Level Trampoline
Products have been engineered with safety,
durability, and performance in mind. Please
Read this information thoroughly before
installation, and be sure to visit us online for
more installation tips and videos.
VPS TRAMPOLINE PARTS LIST
• Top Rail Frame Pieces 8
• 1 Vented Safety Pad
• 1 Jumping mat
• 104 springs
• 8 Leg extensions
• 4 V-shaped Leg Bases
• Leg Screws and Washers (8 each)
• Frame Nuts, bolts, and washers (8 each)
• Spring Tool, screw driver, and wrench
OPTIONAL PARTS LIST:
**if you purchased a TDU Bundle system- you
will also have a lower frame support box with the
following parts included:
• Lower Frame Support Brace (8)
• Nuts, bolts, and washers (16 each)
WARNING: Two adults in good physical condition
are required for the following assembly. For your
safety, you should wear gloves. Failure to follow
these instructions and warnings could result in an
injury.
Installation Instructions
1. Lay out all of the Trampoline parts in
groups, as shown below on a clean, level
installation surface. Please Ensure you have
all necessary components by checking the
parts list.
Connect the 8 Top rail frame pieces
2.
together, and secure them with the provided
frame nuts, bolts, and washers
. (See figure 3)
1 |
P a g e
Advertisement
Summary of Contents for TDU VPS TRAMPOLINE
- Page 1 OPTIONAL PARTS LIST: **if you purchased a TDU Bundle system- you will also have a lower frame support box with the following parts included: • Lower Frame Support Brace (8) • Nuts, bolts, and washers (16 each) WARNING: Two adults in good physical condition are required for the following assembly.
- Page 2 3. Once the Top Rail Frame Pieces are secured, insert the Leg Extension Pieces into the top rail frame neck joints. **If you purchased the VPS Trampoline to use above ground – skip to step 9. If you purchased the in-ground bundle- proceed to step 5 once all v-shaped leg bases are secured.
- Page 3 Trampoline by installing 1 spring every down through the place buckle. hole until you have completed the circle. 7. At this point refer to the TDU retaining wall instructions to attach the retaining wall of the complete bundle system. P a g e...
- Page 4 10. Once you have secured the jumping mat Trampoline. Line up the receiving with a spring spaced out every 5 hole, buckle on the pad with the previously start again by placing a spring to the installed buckle clip on the frame (from right of each of the 1 round of springs.
- Page 5 ©2017 Trampolines Down Under VPS TRAMPOLINE INSTRUCTIONS 1584S. 580 E. American Fork, UT 84003 www.trampolinesdownunder.com info@tdu1.com P a g e...
