MOOSE 4501-0761 Instruction Sheet

Universal heavy duty utv push tube
Hide thumbs
1
2
3

Advertisement

Quick Links

Download this manual
MOOSE UNIVERSAL HEAVY DUTY
UTV PUSH TUBE
BLADE HARDWARE MOUNTING INSTRUCTIONS
PART# 4501-0761
CUSTOMER MUST RECEIVE A COPY OF THIS
INSTRUCTION SHEET AT TIME OF PURCHASE.
Shaded items are pre-assembled with the
snowplow blade.
9
8
7
4
5
6
12
11
INST2709PF
2
15
16
10
9
13
18
24
14
ITEM
PART#
QTY.
1
1
2
1
4
1
5
HDW2064
9
6
HDW7056
9
7
HDW2069
9
8
HDW9003
9
9
HDW7058
11
10
HDW2161
2
11
HDW9005
12
12
HDW2356
2
13
HDW2315
2
14
2550
2
15
HDW7061
5
16
HDW2117
2
17
HDW2369
2
18
KD60
1
19
HDW2160
1
20
HDW9025
2
21
HDW2323
2
22
KD64
1
23
2709-100
1
24
HDW93303
2
1
17
19
23
DESCRIPTION
Blade 66", 72"
Rubber Flap 66", 72"
Wear Bar 66", 72"
5/16 x 1 Carriage Bolt
5/16 Serrated Flange Nut
5/16 x 3/4 Carriage Bolt
5/16 Flat Washer
5/16 Nylock Nut
3/8 x 3/4 Shoulder Bolt
5/8 Flat Washer
3/4 Rubber Spacer
3/16 x 1-1/4 Lynch Pin
Blade Skid
3/8 Nylock Nut
3/8 x 6 Eye Bolts
Blade Spring
Blade Swivel
1/2 x 1 Shoulder Bolt
1/2 Flat Washer
3/8 x 1-1/2 Wire Loop Pin
Blade Position Pin Assembly
Push Tube Weldment
3/8 x 3/4 Socket Head Bolt
22
15
20
21

Advertisement

loading
Need help?

Need help?

Do you have a question about the 4501-0761 and is the answer not in the manual?

Questions and answers

Summary of Contents for MOOSE 4501-0761

  • Page 1 5/16 x 1 Carriage Bolt HDW7056 5/16 Serrated Flange Nut HDW2069 5/16 x 3/4 Carriage Bolt HDW9003 5/16 Flat Washer MOOSE UNIVERSAL HEAVY DUTY HDW7058 5/16 Nylock Nut HDW2161 3/8 x 3/4 Shoulder Bolt UTV PUSH TUBE HDW9005 5/8 Flat Washer...
  • Page 2 Install the blade swivel to the front of the push tubes using the ½”x 1” shoulder bolt, two ½” washers and one 3/8” nylock nut. Make sure swivel still turns after tightening (you may only need one washer). Install the KD64 blade position pin assembly to push tube by removing the nuts from the bottom and placing on top of push tube with pin going through the swivel and push tube bracket.

  • Page 3: Operating Instructions

    OPERATING INSTRUCTIONS* READ BEFORE OPERATING Customer must receive a copy of these instructions at time of purchase. *DANGER* Remove bottom mount and/or front mount before doing any trail riding. To avoid serious injury and/or death: 1. Always use extreme caution while operating the plow on slopes, grades or slippery surfaces. 2.
