Summary of Contents for Jiso N200414 Jelly XL
- Page 1 Installation Instructions N200414 // Jelly XL 10CM Side View Neon Cuttable waterproof D120mm Beam Angle Min.Bending UVResistant IP67 Diameter Protection www.jisoiluminacion.com...
- Page 2 Installation Instructions N200414 // Jelly XL Product parameters: Parameter Mark Rated Value Unit 24VDC Forward Current mA/M Power 14.4 2700K 320LM Luminous Flux Φ Lm（1M） 3000K 320LM 4000K 360LM Width ≥ Min.Bending Diameter IP67 ( * ):The IP67 will be reach only when connectors are correctly sealed with neutral silicone material. Drawing: 200mm 1000mm...
- Page 3 Installation Instructions N200414 // Jelly XL Installation ①ＨＣＮ０４－Ｆ０１ ① First, fix the clips onto the wall. Second, push the neon light all the Third, check the polarity and connect way down to the clips. the cables to the power supply. Product Features 1.
- Page 4 Installation Instructions N200414 // Jelly XL Neon LED Strip instruction and caution R≥120mm Parallelly R≥120mm Straighten the LED strip Bend the LED Strip inward or Once need a turing, lateral outward around the curve. parallelly during normal service. bending around the curve is (Attention: keep the curved allowed only.
