Summary of Contents for Arbor Technology AES-5204
- Page 1 AES-5204 Industrial Ethernet Switch with 4x IEEE 802.3at PoE User’s Manual Version 1.0 2016.07 P/N: 4016520400100P...
-
Page 2: Revision History
Revision History Version Release Time Description July 2016 Initial release... -
Page 3: Table Of Contents
Contents Preface.................... ii Copyright Notice ..................ii Declaration of Conformity ................ii CE .......................ii FCC Class A ..................ii RoHS ....................iii SVHC / REACH .................iii Important Safety Instructions ..............iv Warning ....................iv Technical Support ..................v Warranty ....................vi Chapter 1 - Introduction ..............1 1.1. -
Page 4: Preface
Preface Preface Copyright Notice All Rights Reserved. The information in this document is subject to change without prior notice in order to improve the reliability, design and function. It does not represent a commitment on the part of the manufacturer. Under no circumstances will the manufacturer be liable for any direct, indirect, special, incidental, or consequential damages arising from the use or inability to use the product or documentation, even if advised of the possibility of such damages. -
Page 5: Rohs
RoHS ARBOR Technology Corp. certifies that all components in its products are in compliance and conform to the European Union’s Restriction of Use of Hazardous Substances in Electrical and Electronic Equipment (RoHS) Directive 2002/95/EC. -
Page 6: Important Safety Instructions
Preface Important Safety Instructions Read these safety instructions carefully Read all cautions and warnings on the equipment. Place this equipment on a reliable surface when installing. Dropping it or letting it fall may cause damage Make sure the correct voltage is connected to the equipment. For pluggable equipment, the socket outlet should be near the equipment and should be easily accessible. -
Page 7: Technical Support
Preface The Box PC and its components contain very delicately Integrated Circuits (IC). To protect the Box PC and its components against damage caused by static electricity, you should always follow the precautions below when handling it: Disconnect your Box PC from the power source when you want to work on the inside. Use a grounded wrist strap when handling computer components. -
Page 8: Warranty
Preface Warranty This product is warranted to be in good working order for a period of one year from the date of purchase. Should this product fail to be in good working order at any time during this period, we will, at our option, replace or repair it at no additional charge except as set forth in the following terms. -
Page 9: Chapter 1 - Introduction
Chapter 1 Introduction Chapter 1 - Introduction - 1 -... -
Page 10: Product Highlights
Introduction 1.1. Product Highlights • RJ-45 & SFP Upstream supported • 1 x GbE LAN, 1 x SFP and 4 x 802.3at PoE ports protection • Up to 25.5 watts per PoE port • 1 x RS-485 Camera Console Port •... - Page 11 Introduction Operating 10 ~ 95% @ 75°C (non-condensing) Humidity Vibration IEC 60068-2-6 Shock IEC 60068-2-27 Qualification Certification CE, FCC Class A Power Requirement Power Input DC 9~36V input (w/ 3-pin DC input terminal block) Power Max. 120W Consumption Vehicle ACC power ignition control Power Reversed power input protection Management...
-
Page 12: Inside The Package
Upon opening the package, carefully inspect the contents. If any of the items is missing or appears damaged, contact your local dealer or distributor. The package should contain the following items: 1 x AES-5204 Industrial Ethernet Switch 1 x User’s Manual 1.5. Ordering Information AES-5204 6-port Industrial Ethernet Switch with 4x IEEE 802.3at PoE ports... -
Page 13: Chapter 2 - Getting Started
Chapter 2 Getting Started Chapter 2 - Getting Started - 5 -... -
Page 14: Dimensions
Getting Started 2.1. Dimensions The following illustration shows the dimensions of the computer, with the measurements in width, depth, and height called out. 155.00 Unit:mm - 6 -... -
Page 15: Take A Tour
Getting Started 2.2. Take A Tour Front View Rear View ① SFP LED ② SFP Port ③ WAN Port ⑤ Power Terminal ④ PoE LAN Ports ⑥ RS-485 Terminal ⑦ Power Switch ⑨ DIN Rail Mounting Holes ⑧ Power LED Item Descriptions ①... -
Page 16: Led Indicators
Getting Started 2.3. LED Indicators There are few LEDs on the front panel of the switch to display the power status and network status as described in the table below: Color State Descriptions SFP module is connected. Green SFP LED No SFP module is connected. -
Page 17: Chapter 3 - Installation And Maintenance
Chapter 3 Installation and Maintenance Chapter 3 - Installation and Maintenance - 9 -... -
Page 18: Disassemble The Computer
Installation & Maintenance 3.1. Disassemble the Computer If you need to configure the power detection mode, you will need to disassemble the computer to access the system power DIP switch. The following section will guide you to disassemble the computer. Power off your computer and unplug the power cord and any peripherals. -
Page 19: Wire Dc-In Power Source
Installation & Maintenance Then you will see the DIP switch (SW1) on the main board. For more information on DIP Switch settings, refer to 3.3. Configuring Power Mode After making required settings, follow the disassembly instructions in reverse order to assembly the computer. 3.2. -
Page 20: Configuring Power Mode
Installation & Maintenance should extend from the terminal block plugs. Note that the polarities between the wires and the terminal block plugs must be positive to positive and negative to negative. Use a slotted screwdriver to tighten the captive screws. Plug the terminal block firmly, which wired, into the receptacle on the rear panel. -
Page 21: Din-Rail Mount
Installation & Maintenance 3.4. DIN-rail Mount Integrate the computer to where it works by mounting it to a DIN-rail in the surroundings. Such integration relies on the DIN-rail clip on the rear side of the computer. Follow through the guide below to mount/dismount the computer to/from a DIN-rail. 3.4.1. -
Page 22: Dismount The Computer
Installation & Maintenance 3.4.2. Dismount the Computer Power off the computer and disconnect all cables before proceeding to dismount the computer off the DIN-rail. Push the top side of the computer down, with both hands. Try to release the clip from the DIN-rail.
