Summary of Contents for Techno Signz Digi Pilot Sign

Page 1 DIGI PILOT SIGN...
Page 2: Table Of Contents
Thank you for purchasing the Digi Pilot Sign. This document explains how to troubleshoot the Digi Pilot Sign. For information about how to use the Digi Pilot Sign, please refer to the Digi Pilot Sign User Manual supplied with your unit. TechnoSignz.ca...
Page 3: Digi Pilot Sign Part Names
Digi Pilot Sign Part Names Bus Lights Strobe Lights Message Board Screens Actuators TechnoSignz.ca...
Page 4: Initial Troubleshooting Steps
Initial Troubleshooting Steps Your first attempt at fixing any issues pertaining to your sign or app should be switching it off and then turning it back on, or deleting the app and then re-downloading it. If that doesn’t work, continue on reading.
Page 5: Power Issues
Power Issues Ensure vehicle is turned on & power cable is correctly attached. Ensure app is connected to the sign. Reset the sign’s power breaker. TechnoSignz.ca...
Page 6: Screen Issues
Screen Issues May be a Replace module failure. module. Usually it’s a loose Check connection or a wires. short in the input/output connections. Check if other May be a functions power failure. work, like lights or Power supply problem, actuators. may need replacing.
Page 7: App Issues
App Issues May be a communication failure. Distance between transmitter & receiver may be too far or there may be obstructions. Move closer to the sign & try to reconnect. TechnoSignz.ca...
Page 8: Light Issues
Light Issues Press strobe light app button & listen closely if controller is beeping. If yes, strobe lights’ wiring may be faulty, fuse may be burnt or lights need replacing. If no, there is a controller issue, so controller needs fixing or to be replaced.
Page 9: Actuator Issues
Spray lubricant onto actuator to facilitate actuator movement. If noise continues, actuator may be bent or faulty and need replacing. PLEASE NOTIFY TECHNO SIGNZ IMMEDIATELY IF PROBLEM PERSISTS AS FAULTY ACTUATORS MAY LEAD TO CRACKING OF FRAME, AND MAY VOID WARRANTY.
Page 10: Digi Pilot Sign Wiring
Digi Pilot Sign Wiring Located inside Located inside sign frame. vehicle trunk. Solenoid Breaker Power Converter Modules (12V to 5V) Bus Lights (Front) Actuators Controller Bus Lights (Rear) Board 12V Battery Strobe Lights TechnoSignz.ca...
