Skywalk X-GLOO Setup Manual

SETUP GUIDE
PLEASE NOTE: Before setting up your X-GLOO Inflatable Event
Tent, we strongly recommend first laying down our Protection
Foil to help prevent it from becoming soiled or damaged.

1. LAY OUT THE MATRIX

Lay out the X-GLOO Inflatable Event
Tent Matrix (Roof and inflatable
Tubes) on top of the protection foil.
Arrange the Matrix so the tube ends
are close to where you want them to
be when the Event Tent is inflated.
8x8 ONLY: Zip in the Middle Walls
Due to the height of an inflated 8x8-meter Event Tent, we recommend
zipping in the Middle Walls before inflating the tent.
2. CHECK
VALVES

INFLATION VALVES

Screw the valve housing (2) firmly
onto the socket ring (1). Unscrew
the protective cap (3 & 4).
Repeat on all four tubes.

OVERPRESSURE VALVES (5)

Test each red Overpressure Valve by
unscrewing the housing and making
sure that the spring inside can be
pushed in. Make sure that there
is no sand or dirt inside the valve
which could clog the spring and
prevent the Overpressure Valve from
functioning correctly.

3. INFLATE

First inflate two Tubes opposite one
another to form an arc (6).
Next inflate the Tube at the inside
of this arc (7).
Finally inflate the last tube, making
sure to lift the middle of the Roof
gently to allow the tube to fill
completely (use the Setup Support
Bar when setting up the 8x8) (8).
Close the cover on each inflation
Valve after inflation.
For more information, watch our how-to videos at:
Please see other side for information regarding
takedown and care of your product.
1 2 3
4
5
6
7
8
www.x-gloo.com/en/experience/videos/
4. ATTACH OPTIONAL
SIDEWALLS AND CANOPIES
On the tube ends of the Event
Tent Matrix you will find zippers
to attach optional Side Walls, Roof
Banners or Canopies (9).
To prevent damage to the Event Tent
in the event of high winds, connect
the straps at the base of the wall to
the red webbing loops on the tube
ends (10). Tighten each strap using
the nylon buckle until the tension
on the zipper is relieved.
Optional Wall Ballasts (11) can also
be used to reduce the risk of damage
to the tent Matrix, walls and zippers
through exposure to high winds.
Wall Ballasts are not intended to
replace the Tube Ballasts, Water
Ballast Barrels, or Anchoring Sets as a
means to anchor the Event Tent.

5. ANCHOR

Properly anchor your X-GLOO Inflatable Event Tent according to the
expected wind conditions. Refer to the Wind Resistance Certificate or
to the table below for ballast recommendations. Full details on how
to anchor your tent can be found in your User's Manual.
X-GLOO Ballast(s) Required Per Tube
Matrix 30 km/h
(18.7 mph)
Size wind speed
4x4 1x Tube Ballast
5x5 1x Tube Ballast
6x6 2x Tube Ballasts
8x8 1x Ballast Barrel
Water Ballast Barrel with
digitally-printed Cover
40 km/h 60 km/h
(25 mph) (37.3 mph)
wind speed wind speed
2x Tube Ballasts 1x Ballast Barrel
2x Tube Ballasts 1x Ballast Barrel
1x Ballast Barrel 2x Ballast Barrels
2x Ballast Barrels 3x Ballast Barrels +
No-rub Mat
Tube Ballast
9
10
11
