AV Link InSound 100.580UK User Manual

True wireless earphones and power-case

Advertisement

Discover true wireless freedom and immersive sound within a stylish, compact design. Lightweight earbuds offer the perfect, secure fit and comfort for long periods of use.
Features include dynamic drivers, Bluetooth 5.0 for seamless connection to smart devices and intuitive touch controls to handle your music and hands-free calls with ease.
The portable power-case stores and charges your earphones which provides up to 12 hours additional play time, keeping your earphones ready to use when you're on-the-
go.

Features

Sleek and attractive, satin black design
Intuitive touch controls handle your music with ease
Compact power-case provides up to 12 hours additional play time
Lightweight earbuds with silica gel inserts provide ultimate comfort even
when used over prolonged periods
Dynamic 6mm drivers deliver a deep and immersive audio experience
Bluetooth 5.0 connectivity for optimum transmission speed
Built-in omnidirectional microphone for hands-free calls
Compatible with iOS and Android devices

Technical Specifications

Speaker Driver
Frequency Response
Sensitivity
Impedance
Power: Battery
Battery Life (hours)
Standby Time
Charge Time
Bluetooth Version
Bluetooth Range
Dimensions
Weight:

Overview

LED
indicators

Before first use

Even though your InSound earphones will come with some battery charge, it's advisable to fully charge them before first use. Connect the power-case and earbuds to a
suitable USB power source and leave for around 2 hours to ensure they are ready for first use. When charging, the power-case charge indicators will flash white in sequence
to show how much charge is in the case. The more LED's lit means the more the case is charged. When fully charged, all 4 indicators will be lit.
www.avsl.com
6mmØ
20Hz -20kHz
Earphones: ≥96dB, Microphone:-42dB
16 Ohms
Earphones: 2x internal 50mAh, Power-case: 500mAh
Earphones: 4 hours max, Power-case: Up to 12 additional hours playback
100 days (approx.)
Earphones: 1 hour (approx), Power-case: 2 hours (approx)
V5.0
Up to 15m (clear line of sight)
Earphones: 38 x 25 x 15mm , Power-case: 75 x 35 x 30mm
Earphones: 2 x 4g, Power-case: 38g (including headphones)
MF
touch
buttons
True Wireless Earphones and
In the Box
2pcs True wireless earbuds
Power-case
USB charging cable
User guide
Charge
indicators
Power-Case
InSound
Item ref: 100.580UK

User Manual

100.580UK

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the InSound 100.580UK and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for AV Link InSound 100.580UK

  • Page 1: User Manual

    True Wireless Earphones and Power-Case InSound Item ref: 100.580UK User Manual Discover true wireless freedom and immersive sound within a stylish, compact design. Lightweight earbuds offer the perfect, secure fit and comfort for long periods of use. Features include dynamic drivers, Bluetooth 5.0 for seamless connection to smart devices and intuitive touch controls to handle your music and hands-free calls with ease. The portable power-case stores and charges your earphones which provides up to 12 hours additional play time, keeping your earphones ready to use when you’re on-the- Features In the Box...
  • Page 2 Pairing in True Wireless mode On first use, you need to pair the earbuds to each other and then your device, this procedure will need to be repeated every time you pair them with a new device. Simply remove the earbuds from the power-case and they will automatically enter pairing mode and the LED indicator will flash red and white on both earbuds. Once they have paired with each other, only the right (master) earbud’s LED indicator will flash red and white and you will hear a voice message saying “pairing mode”, to indicate they ready to connect to your device.
