Dacor Modernist Microwave In-A-Drawer DMR24M977WM Installation Instructions Manual
Hide thumbs
Also See for Modernist Microwave In-A-Drawer DMR24M977WM:
- Flush mount installation instructions (16 pages) ,
- Installation instructions manual (15 pages) ,
- User manual (46 pages)
Related Manuals for Dacor Modernist Microwave In-A-Drawer DMR24M977WM
Summary of Contents for Dacor Modernist Microwave In-A-Drawer DMR24M977WM
-
Page 1: Installation Instructions
Installation Instructions Modernist Microwave In-A-Drawer ™ DMR24M977WM, DMR24M977WM DMR30M977WM, DMR30M977WM Part No. 112242 Rev B... -
Page 2: Table Of Contents
Contents Before You Begin… Important Customer-Service Information If You Need Help… Model and Serial Numbers Before You Call for Service… Important Safety Precautions Related Equipment Safety Grounding the Microwave In-A-Drawer™ Installation Requirements Checklist Design Specifications Clearances and Dimensions Installation Preparing to Install the Microwave In-A-Drawer™ Provided Material Unpacking the Microwave In-A-Drawer™... -
Page 3: Before You Begin
Before You Begin… Important Installer • For safety and to minimize problems, read this manual thoroughly before starting the instal- lation. • The installer shall ensure proper installation; the warranty does NOT cover product failure due to improper installation. • Remove all packing material before connecting the electrical supply. •... -
Page 4: Customer-Service Information
The list includes common issues that are not caused by defective work- manship or material. See the warranty information in your Use Manual for Dacor’s toll-free service number and ad- dress. Use the contact information if need to speak to a Dacor representative about warranty... -
Page 5: Important Safety Precautions
Important Safety Precautions Related Equipment Safety Remove all tape and packaging before using the microwave. Dispose of the packaging after unpacking the oven. Do not let children play with the packing material. Do not modify the oven (e.g., remove panels, wire covers, screws). DANGER—ELECTRIC-SHOCK HAZARD •... - Page 6 Important Safety Precautions Follow these precautions with exactness to avoid fire or electrical shock that may cause property damage, personal injury, or death. WARNING • Follow the information in this manual exactly to avoid fire or electrical shock that may cause property damage, personal injury, or death.
-
Page 7: Installation Requirements
Installation Requirements Checklist Use this checklist to ensure you complete the installation process properly and verify the oven’s proper function: • Before installing the oven, verify the cabinet dimensions are correct and the required electri- cal connections are present. • See this manual’s content regarding Safety, Cabinet Dimensions, Removing Packaging, Elec- trical Installation, Testing the Installation and Customer Service. -
Page 8: Design Specifications
Design Specifications Clearances and Dimensions • The dimensions shown in Figures 2, 4, and 5 are minimums and must be used. • The contact surface must be of solid, level, plywood construction strong enough to support the oven’s weight (about 100 lbs). •... - Page 9 24” Drawer Dimensions, cont. Dim. Inches Description Anti-tip block length — Electrical outlet location — Anti-tip block Outlet location height 3 1/2 Anti-tip block width Outlet location width 22 1/8 Cutout width 14 13/16 Cutout floor to block bottom Minimum overlap allowance (sides) 23 1/2 Minimum cutout depth 3/16...
- Page 10 30” Drawer Dimensions, cont. Dim. Inches Description Anti-tip block length — Electrical outlet location — Anti-tip block Outlet location height 3 1/2 Anti-tip block width Outlet location width 22 1/8 min. Cutout-opening width range 28 7/16 max. 14 13/16 Cutout floor to block bottom 23/32 Minimum overlap allowance (sides) 23 1/2...
-
Page 11: Installation
• Remove the “features” sticker. • Check for damage (e.g., loose/bent/mis- aligned components, damaged drawer seal, dented surfaces). • Report damage to your dealer or a Dacor Authorized Servicer. Do not install/operate a damaged appliance. -
Page 12: About The Electrical Outlet
Installation About the Electrical Outlet A 120 volt 60 Hz, AC only, 15 amp. or more pro- tected electrical supply is required. It is prefer- able that the oven be on its own circuit. The drawer has a 3-prong grounding plug that must be plugged into a properly installed and grounded outlet. - Page 13 Instructions D’installation Modernist Micro-Onde Tiroir ™ DMR24M977WM, DMR24M977WM DMR30M977WM, DMR30M977WM...
- Page 14 Table des Matières Avant de Commencer… Important Information Pour le Service à la Clientèle Pour Obtener de L’aide… Nombre de modèles et de séries Before You Call for Service… Important Précautions de Sécurité Related Equipment Safety Grounding the Microwave In-A-Drawer™ Conditions D’installation Liste de Contrôle Les Spécifications de Conception...
-
Page 15: Important
Before You Begin… Important Installer • For safety and to minimize problems, read this manual thoroughly before starting the instal- lation. • The installer shall ensure proper installation; the warranty does NOT cover product failure due to improper installation. • Remove all packing material before connecting the electrical supply. •... -
Page 16: Before You Call For Service
The list includes common issues that are not caused by defective work- manship or material. See the warranty information in your Use Manual for Dacor’s toll-free service number and ad- dress. Use the contact information if need to speak to a Dacor representative about warranty... -
Page 17: Related Equipment Safety
Important Safety Precautions Related Equipment Safety Remove all tape and packaging before using the microwave. Dispose of the packaging after unpacking the oven. Do not let children play with the packing material. Do not modify the oven (e.g., remove panels, wire covers, screws). DANGER—ELECTRIC-SHOCK HAZARD •... - Page 18 Important Safety Precautions Follow these precautions with exactness to avoid fire or electrical shock that may cause property damage, personal injury, or death. WARNING • Follow the information in this manual exactly to avoid fire or electrical shock that may cause property damage, personal injury, or death.
- Page 19 Installation Requirements Checklist Use this checklist to ensure you complete the installation process properly and verify the oven’s proper function: • Before installing the oven, verify the cabinet dimensions are correct and the required electri- cal connections are present. • See this manual’s content regarding Safety, Cabinet Dimensions, Removing Packaging, Elec- trical Installation, Testing the Installation and Customer Service.
-
Page 20: Clearances And Dimensions
Design Specifications Clearances and Dimensions • The dimensions shown in Figures 2, 4, and 5 are minimums and must be used. • The contact surface must be of solid, level, plywood construction strong enough to support the oven’s weight (about 100 lbs). •... - Page 21 24” Drawer Dimensions, cont. Dim. Inches Description Anti-tip block length — Electrical outlet location — Anti-tip block Outlet location height 3 1/2 Anti-tip block width Outlet location width 22 1/8 Cutout width 14 13/16 Cutout floor to block bottom Minimum overlap allowance (sides) 23 1/2 Minimum cutout depth 3/16...
- Page 22 30” Drawer Dimensions, cont. Anti-tip block length — Electrical outlet location — Anti-tip block Outlet location height 3 1/2 Anti-tip block width Outlet location width 22 1/8 min. Cutout-opening width range 28 7/16 max. 14 13/16 Cutout floor to block bottom 23/32 Minimum overlap allowance (sides) 23 1/2...
-
Page 23: Installation
• Remove the “features” sticker. • Check for damage (e.g., loose/bent/mis- aligned components, damaged drawer seal, dented surfaces). • Report damage to your dealer or a Dacor Authorized Servicer. Do not install/operate a damaged appliance. -
Page 24: About The Electrical Outlet
Installation About the Electrical Outlet A 120 volt 60 Hz, AC only, 15 amp. or more pro- tected electrical supply is required. It is prefer- able that the oven be on its own circuit. The drawer has a 3-prong grounding plug that must be plugged into a properly installed and grounded outlet. - Page 28 Dacor ∙ 14425 Clark Avenue, City of Industry, CA 91745 ∙ Phone: (800) 793-0093 ∙ Fax: (626) 403-3130 ∙ www.dacor.com...
