Swivel seat for toyota corolla hatch back 2004 model year

Advertisement

Quick Links

Corolla Hatch Back
Swivel seat
Installation Instructions
Model Year:
Body type
Part Number:
Weight:
Installation Time:
Manual reference number
PICTURE HERE
2004
Hatch back 3 door and 5 door
LHD 3 door
LHD 5 door
RHD 3 door
RHD 5 door
44 kg
60 minutes
AIM 000721-01
08926-21810
08926-21802
08926-21812
08926-21804

Advertisement

loading
Need help?

Need help?

Do you have a question about the 08926-21810 and is the answer not in the manual?

Questions and answers

Summary of Contents for Toyota 08926-21810

  • Page 1 Swivel seat Installation Instructions PICTURE HERE Model Year: 2004 Body type Hatch back 3 door and 5 door Part Number: LHD 3 door 08926-21810 LHD 5 door 08926-21802 RHD 3 door 08926-21812 RHD 5 door 08926-21804 Weight: 44 kg Installation Time:...
  • Page 2 Take off the Box CAUTION!! Do not move on the floor Do not put on the floor directly Note: No side airbag systems on Corolla H/B Mobility seat ※ All pictures mentioned on this I/M are for LHD vehicle. 1 of 10...
  • Page 3 ※ Check all parts before installation. Parts List for Corolla H/B(LHD) France Only Part Number Parts Part Number Parts 1× 1× C7002-D1320 (5DR) 74552-D1060-00 C7002-D1370 (3DR) 1× 1× 58551-D1050-B0 74553-D1050-00 1× 1× French 82711-1E360-00 01999-D1084-00 10× 1× S14×L27.5 English 90119-10578-00 01999-D1085-00 14 15 2×...
  • Page 4 ※ Check all parts before installation. Parts List for Corolla H/B(RHD) UK Only Part Number Parts Part Number Parts 1× 1× C7002-D1310 (5DR) 74552-D1050-00 C7002-D1360 (3DR) 1× 1× 58561-D1380-B0 74553-D1020-00 1× 1× 82711-1E360-00 01999-D1086-00 10× 2× S14×L27.5 90119-10578-00 74551-D1010 3× 21 22 23 74596-D1010 S14×L55 1×...
  • Page 5 Tool * Torque Wrench is also required PROTECT COVER 2 1 CAUTION!! 3 4 of 10...
  • Page 6 Remove the OE Seat Seat Bolt Removal Remove the Headrest 4 Bolts 4 5 6 7 Bolt Bolt Bolt 8 9 Bolt Keep Seat 5 of 10...
  • Page 7 Install the Mobility Seat 2 Bolts Unit Installation 4 Bolts * Two technitian is required to put into the vehicle. Handling Wire-harness (Under panel of swivel unit) ① Joint this socket ① to base vehicle's Air Bag Harness. ② Joint this socket ② to base vehicle's buckle switch ①...
  • Page 8 Tighten the 5 bolts Long bolt 2 Bolts 7 of 10...
  • Page 9 ① Stick PART ① (Carpet, front floor side) on the side wall of Console Box. Before sticking the carpet, remove oil from the surface of Console Box and clean passenger door. ② Stick the Caution Label on the door trim. (passenger side) ③...
  • Page 10 Label putting position (CRS or SRS) France Only Put CRS M and SRS N staickers as below. ・Put on Side of Instrument Panel Two places ○ Put the label on O/M of base Vehicle. ・Put on B-Pillar Dispositif de retenue des occupants Siege enfants  Two places ○Put the label on O/M of base Vehicle. Dispositif de retenue des occupants SRS Airbag lateraux ...
  • Page 11 Label putting position (CRS or SRS) UK Only Put CRS O and SRS P staickers as below. ・Put on Side of Instrument Panel Two places ○ Put the label on O/M of base Vehicle. Chapter : Occupant restraint systems Paragraph : Child restraint  ・Put on B-Pillar Three places 30mm ○ Put the label on O/M of base 20mm ・Put on Front Glass...
  • Page 12 Toyota Motor Europe NV/SA Version date: 15/09/2006 Installation checksheet Bourgetlaan 60 B-1140 Brussels Corolla Hatch back E12 Mobility project : swivel seats Operator: Date: VIN: Supervisor check: Before installation Box content OK Serial number Lift Up seat During installation VSC ECU and sensor do not interfer with swivel seat...
