Summary of Contents for Phoenix VIVID SLIMLINE VS745 CHR
- Page 1 VIVID SLIMLINE FLOOR MOUNTED BATH MIXER PRODUCT CODE: VS745 CHR FINISH: CHROME STYLISH CONTEMPORARY DESIGN PREMIUM FINISH PHOENIX WARRANTY MATCH WITH..
-
Page 2: Technical Specifications
TECHNICAL SPECIFICATIONS CONSUMER INFORMATION RANGE: VIVID SLIMLINE PRODUCT: FLOOR MOUNTED BATH MIXER PRODUCT CODE: VS745 CHR WATERMARK LICENCE: WM21009 REVISION DATE: DEC 2013 CONNECTION TYPE: MATERIAL: BRASS AVAILABLE FINISHES: CHROME, MATTE BLACK WELS RATING: FLOW RATE: MAX FLOW TEMPERATURE RATING: MIN 1°... -
Page 3: Exploded View
EXPLODED VIEW PARTS LIST 1. UPPER TUBE ADAPTER 2. FLOOR MIXER TUBE 3. MOUNTING PLATE 4. M15 FLEXIBLE HOSE 5. FLOOR INLET BODY 6. THREADED INSERT 7. FLOOR MIXER COVER 130MM 8. HEX BOLT M8X25 9. O-RING 10. SCREW 11. HOSE EXTENSION 12. -
Page 4: Installation Instructions
INSTALLATION INSTRUCTIONS FLOOR MOUNTED BATH MIXER Installation Instructions VIVID SLIMLINE FLOOR MOUNTED BATH MIXER www.phoenixtapware.com.au Option A Connect hot and cold Recommended pit to be cast in concrete. REMOVE PROTECTIVE For minor adjustment, rotate and adjust Dress Cover hoses to the Inlet Body COVER FROM TILED the Mixer Assembly to desired position. -
Page 5: Warranty Information
* Note: These warranty periods apply to Phoenix will not be liable for any claims for labour, - Isolation stop taps are not tted as stated on products purchased after 10th April 2011. - Page 6 Phoenix is responsible, Phoenix has the right to charge a service fee for each service sta attending the Owner’s premise where goods have been installed.
