Summary of Contents for Deditec USB-RS485-STICK
- Page 1 USB-RS485-STICK Hardware-Description 2012 November...
-
Page 2: Table Of Contents
INDEX 1. Introduction 1.1. General remarks 1.2. Customer satisfaction 1.3. Customer response 2. Hardware description 2.1. Technical data 2.2. Pin assignment connector 2.2.1. 9pol. D-SUB male 2.3. LED's 3. Software 3.1. "VCP driver (Virtual COM-Port)" installation 4. Appendix 4.1. Product information 4.2. -
Page 3: Introduction
Introduction Introduction | Seite... -
Page 4: General Remarks
1.1. General remarks First of all, we would like to congratulate you to the purchase of a high quality DEDITEC product. Our products are being developed by our engineers according to quality requirements of high standard. Already during design and development we take care that our products have -besides quality- a long availability and an optimal flexibility. -
Page 5: Hardware Description
Hardware description Hardware description | Seite... - Page 6 2. Hardware description With this handy stick your are able to connect your PC/Notebook to the world of RS-485 devices. The galvanical isolation electrically separates the PC from the RS-485 interface. Disruptive impulses from the RS-485 side, that destroy such converters, are now things of the past.
-
Page 7: Technical Data
2.1. Technical data +5V power supply USB to RS-485 converter galvanically isolated 50 Baud ..115200 Baud (per Software adjustable) Windows VCP (Virtuel COM Port) Linux drivers included Dimensions: 84,5 x 21 x 12,5/9,5 mm (without cable) Hardware description | Seite... -
Page 8: Pin Assignment Connector
2.2. Pin assignment connector 2.2.1. 9pol. D-SUB male The connection to the stick on the RS-485 side is made by a 9pol. D-Sub male. RS-485 pin assignment RS-485 B RS-485 A Hardware description | Seite... -
Page 9: Led's
2.3. LED's Two LED signalize send and receive events. 1*TX (transmit) 1*RX (receive) Hardware description | Seite... -
Page 10: Software
Software Software | Seite... -
Page 11: Vcp Driver (Virtual Com-Port)" Installation
3. Software 3.1. "VCP driver (Virtual COM-Port)" installation Insert the DEDITEC driver CD in your drive and start “vcp_driver_install.exe”. The “VCP driver (Virtual COM-Port)” software is also available at http://www. deditec.de/en/entwicklungstools/download.html. Software | Seite... - Page 12 Press “Install”. The driver will be installed. Software | Seite...
- Page 13 The “VCP Driver (Virtual COM-Port)” Software has been installed now. Press “Close” to finish installation. Software | Seite...
-
Page 14: Appendix
Appendix Appendix | Seite... -
Page 15: Product Information
4. Appendix 4.1. Product information Ord.no.: USB-RS485-STICK Product: USB-RS-485-converter with galvanic isolation Productlink: http://www.deditec.de/en/entwicklungstools/prod/usb-rs485-stick.html Appendix | Seite... -
Page 16: Revisions
4.2. Revisions Rev 1.00 First issue Rev 2.00 Design change Rev 2.01 Index added Appendix | Seite... -
Page 17: Copyrights And Trademarks
4.3. Copyrights and trademarks Linux is registered trade-mark of Linus Torvalds. Windows CE is registered trade-mark of Microsoft Corporation. USB is registered trade-mark of USB Implementers Forum Inc. LabVIEW is registered trade-mark of National Instruments. Intel is registered trade-mark of Intel Corporation AMD is registered trade-mark of Advanced Micro Devices, Inc.
