ELETA ELE-DP-106A Instruction Manual

INTRODUCTION

ELETA Automatic Aerosol Dispenser is a perfect air freshener dispenser of quality and
cost. It is a smart way to keep your home/office from odor by featuring various programs.
It can be programmed to spray 24/7 with the spray custom interval from1 to 60 minutes. It
could be also limited to spray certain hours or certain days.

BUTTON FUNCTIONS

Push down the grey ball on the top of the dispenser to open the Dispenser's case and you
will see seven buttons as below:
1. RESET (Red)
To reset settings
2. SPRAY (Brown)
By pushing spray button, the Dispenser will spray once. LED light will blink in red and
green color few times to indicate that the Dispenser is working.
3. MODE (Blue)
By pushing MODE button, the LCD will show the following options:
ON, OFF, START, STOP, SPRAY, INTERVAL, WEEK, CLOCK
4. WEEK (Green)
Set weekend working mode.
5. HOUR (Yellow)
Set hourly working mode.
6. MIN (Orange)
Set minutes.
7. ON/OFF (Red)
Power on / off
When you push the ON/OFF Button, LCD screen will displays "ON" and the LED
flashes in green and red color 3 times for each color. Then Dispenser sprays once
and enters into normal working condition.
LED Indicator
Green blinking: Dispenser works normally.
Red blinking: The refill can is running out soon. Please replace the refill can soon.
LCD Display
LCD screen displays time
If LCD screen displays a battery in the bottom left corner, batteries should be
replaced soon.
ELE-DP-106A
(Make sure the spray nozzle is away from your face and eyes)
Instruction Manual
Digital LCD Automatic Aerosol Dispenser
