I
ImproX (SKA) 125 kHz SupaGate Keypad Antenna Reader
SPECIFICATIONS
Working Environment .................
Buzzer ...........................................
Keypad ..........................................
Status Indicators
Status LED .............................
INSTALLATION INFORMATION
Accessories
Find the following when unpacking the Antenna Reader:
An ImproX SKA Antenna Reader housed in a Black tinted, Polycarbonate Plastic
Housing. The ImproX SKA consists of the Front Cover Antenna Reader Assembly
(fully potted) and a Backing Plate. The Front Cover Antenna Reader Assembly
includes a 2 m (7 ft) shielded multi-strand 3-pair twisted open-ended connection
cable.
Four Brass Wood Screws (3.5 mm x 25 mm).
Four Wall Plugs (7 mm).
An extra Serial Number Label.
General
Remember the following when installing the Antenna Reader:
Maximum Data Communications Distance
The ideal cable distance between the ImproX SupaGate Controller and the ImproX
SKA ranges between 2 m to 16 m (7 ft to 53 ft). Achieve this by using a good quality
shielded multi-strand 3-pair twisted cable. The cross-sectional area of the cable must
not be less than 0.2 mm
MPRO
INSTALLATION MANUAL
Designed to work in an indoor or outdoor
environment similar to IP53. The ImproX SKA
is, therefore, sealed (potted) against water.
Single tone, 4 kHz.
12 Alphanumeric keys.
Bi-coloured Red or Green.
2
2
(0.0003 in
).
MODEL NUMBER: SGI913-1-0-GB-XX
X SKA

Advertisement

loading

Summary of Contents for impro IMPROX SKA

  • Page 1 Accessories Find the following when unpacking the Antenna Reader: An ImproX SKA Antenna Reader housed in a Black tinted, Polycarbonate Plastic Housing. The ImproX SKA consists of the Front Cover Antenna Reader Assembly (fully potted) and a Backing Plate. The Front Cover Antenna Reader Assembly includes a 2 m (7 ft) shielded multi-strand 3-pair twisted open-ended connection cable.
  • Page 2 Select the mounting position of the ImproX SKA, considering accessibility, routing of wires and visibility of the Status LED. Secure the ImproX SKA to the mounting surface, using four suitable screws and wall plugs (supplied), nuts and bolts, rivets or double-sided adhesive tape.
  • Page 3 Connecting the ImproX SKA Figure 1 shows a detailed connection diagram for the ImproX SKA. CAUTION: The ImproX SKA only connects to the ImproX SupaGate range of Controllers. The ImproX SKA will NOT operate with the ImproX (TT) Twin Antenna Terminal, the ImproX (MfT) Multi-function Terminal or the ImproX IXP121 Controller.
  • Page 4 This manual is applicable to the ImproX (SKA) 125kHz SupaGate Keypad Antenna Reader, SGI913-1-0-GB-00. (The last two digits of the Impro stock code indicate the issue status of the product). ImproX SKA\English Manuals\LATEST SGI304-0-0-GB-04...
