- Page 1 2000W Elektrikli Testere 2000W Chain Saw 2040...
- Page 11 GENEL GARANTİ ŞARTLARI : 1- Garanti süresi, malın teslim tarihinden itibaren başlar ve 2 (iki) yıldır. Malın kullanım ömrü 5 (beş) yıldır. 2- Malın bütün parçaları dahil olmak üzere tamamı firmamızın garanti kapsamındadır. 3- Malın garanti süresi içerisinde arızalanması durumunda, tamirde geçen süre garanti süresine eklenir.
- Page 12 The following symbols are used throughout this manual. Denotes risk of personal injury, loss of life, or damage to the tool in case of non- observance Use eye protection Use ear protection Wear sturdy, non-slip footwear Read the user manual Use protective gloves Do not expose to rain Disconnect from mains power immediately if the power cord becomes damaged...
- Page 13 General Power Tool Safety Warnings WARNING Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term "power tool" in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.
- Page 14 g) If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used. Use of dust collection can reduce dust- related hazards. 4) Power tool use and care a) Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed.
- Page 15 chain saw out of control. ● Use extreme caution when cutting brush and saplings. The slender material may catch the saw chain and be whipped toward you or pull you off balance. ● Carry the chain saw by the front handle with the chain saw switched off and away from your body.
-
Page 16: Lubrication System
LUBRICATION SYSTEM ● The chain is automatically lubricated. ● Use only new chain oil specifically formulated for chainsaws. Never use wasted oil, low quality oil, or insufficient oil. This could damage the pump; the bar and the chain may result in serious personal injury ●... -
Page 17: Bar And Chain Assembly
Fig.1 10 12 Fig.2 BAR AND CHAIN ASSEMBLY Check that the box contains: ● The main handle assembly ● Guide bar ● Guide bar sheath ● Chain ● Spanner ● Hex wrench If any of the above items are missing contact the store for replacements To assemble the chain and bar ●... -
Page 18: Switch On And Off
● Wearing thick protective gloves, drape the chain (6) over the guide bar (5) ensuring the direction of travel is as marked on the chain cover and it is fully engaged in the guide bar sprocket. ● Offer the bar/chain assembly up to the locking pin and tensioning screw ensuring it is fully engaged on the drive sprocket (13) ●... - Page 19 Make the felling cut (D) from the other side of the tree and 1.5 - 2.0 inches above the edge of notch (C) (Fig.4) Fig.4 Never saw completely through the trunk. Always leave a hinge (F). The hinge guides the tree.
- Page 20 BUCKING Bucking is cutting a fallen log into lengths. Make sure that you have a good footing and stand uphill of the log when cutting on sloping ground. If possible, the log should be supported so that the end to be cut off is not resting on the ground. If the log is supported at both ends and you must cut in the middle, make downward cut halfway through the log and then make the undercut.
-
Page 21: Technical Data
TECHNICAL DATA Power input 2000W Voltage 230V Power frequency 50Hz No load speed 8100min Guide bar length 405mm Weight 4.4Kg Calculated LwA 106dB(A) Vibration level 5.092m/s Oil tank capacity 90ml Notice: - the declared vibration total value has been measured in accordance with a standard test method and may be used for comparing one tool with another;... -
Page 22: Troubleshooting
● Disconnect from the mains supply ● Don protective gloves. ● Ensure the chain is correctly tensioned. ● Engage the chain brake to lock the chain on the bar. ● Use a round file whose diameter is 1.1 times the cutting tooth depth. ●... -
Page 24: Ec Declaration Of Conformity
Semak Makina San ve Tic. A.Ş We hereby Certify that , Palmera Brand and model no PAT2040 is exactly the same model of our model no YT 4390 Electric Chainsaw machine. This electric Chainsaw is produced for cutting trees and logs. - Page 25 MALIN GARANTİ SÜRESİ 24 AY’DIR. MALIN KULLANIM ÖMRÜ YIL’DIR. İthalatçı SEMAK MAKİNA TİC. VE SAN. yedek parçalar bulunabilirligini mal kullanı süresi olan yıl süresince sağlama garantisi vermistir. Makinanın kullanım kılavuzunda belirtilen uyarı ve önemlere uygun kullanım gereklidir. Tamir ve/veya bakım için yetkili servislere basvurunuz. ÜRETİCİ...
