Installation INSTRUCTIONS
Kutzner+ Weber is certified according to DIN EN ISO 9001
Advertisement
Table of Contents
Related Manuals for Kutzner + Weber RSD Series
Summary of Contents for Kutzner + Weber RSD Series
- Page 1 Hearth - Kitchen - Domestic KUTZNER +WEBER RSD Chimney Fan RSD 150 RSD 250 RSD 350 INSTALLATION INSTRUCTIONS Kutzner+ Weber is certified according to DIN EN ISO 9001...
- Page 2 Safety Instructions • The screws must ensure a stable and windproof After installation, chimney fans are an integral fastening. The chimney cover must be connected firmly part of the exhaust system and can influence the with the chimney shaft or must have enough dead appliance it is connected to.
- Page 3 RSD Chimney Fan PE=Ground A licensed professional should install the RSD following these L = Line instructions and those of the flue gas system. N = Neutral Safety Disconnect C B =Run capacitor A safety disconnect switch should be installed within reach of the RSD fan.
- Page 4 NFPA 70, National Electric Wire Capped Dry Contact Code, and/or any local codes. Connections shown are for illustration KUTZNER + WEBER purposes. Refer to appliance manufacturer documentation for interlock connections. Distributed by RM Manifold Group, Inc 120 S Sylvania...
- Page 5 Foyer - Cuisine - Domestique KUTZNER + WEBER Ventilateur de cheminée RSD RSD 150 RSD 250 RSD 350 INSTRUCTIONS DE MONTAGE Kutzner + Weber est certifié selon DIN EN ISO 9001...
- Page 6 Consignes de sécurité • Les vis doivent assurer une fixation stable et étanche au vent. Le Après l'installation, les ventilateurs de cheminée font couvercle de cheminée doit être solidement raccordé au conduit partie intégrante du système d'évacuation et peuvent de cheminée ou doit avoir suffisamment de poids mort pour influencer l’appareil auquel ils sont raccordés.
- Page 7 Ventilateur de cheminée RSD Un PE = Masse professionnel agréé doit installer le ventilateur de cheminée RSD L = Ligne en suivant ces instructions et celles du système de gaz de combustion. N = Neutre Condensateur CB = Interrupteur de sécurité de marche Un interrupteur de sécurité...
- Page 8 Wire Capped Dry Contact Code, and/or any local codes. Connections shown are for illustration purposes. Refer to appliance manufacturer KUTZNER + WEBER documentation for interlock connections. Distribué par RM Manifold Group, Inc 120 S Sylvania Ave Suite à Fort Worth, TX 76111...
