ASSEMBLY INSTRUCTION
6.6 lbs.
11 lbs.
11 lbs.
11 lbs.
LOT#
THIS INSTRUCTION BOOKLET CONTAINS
INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
UPC#849392006586
4-Drawer Organizer
MS87-020-104-30
Easy Home Organization Manufacturing Co., Ltd
11 lbs.
DATE PURCHASED
Do Not Return To The Store!
NEED HELP? For help with assembly or missing
part ordering, please call our helpdesk toll-free:
1-855-968-6917 between 9 a.m and 4 p.m (Central
Time) Monday to Friday.
Or email us:
easyhome.customersupport@usa.arcoxmail.com
Please let customer service know:
1. You purchased this item from Wal-Mart
2. The item description is:
4-Drawer Organizer
3. The vendor stock number is MS87-020-104-30
4. The part number/letter and quantity needed
If you have this information ready, we will be able
to process your request promptly. Thank you
WARNING!!!
This unit is intended for use only with the products
and maximum weights indicated. MAXIMUM
SAFE LOAD:50.6 LBS (small drawer:6.6 lbs x 1,
large drawer:11 lbs x 3, MDF top:11 lbs x 1)
Use with other products or products heavier than the
maximum weights indicated may result in instability
causing possible injury. Furniture can tip over or
break if improperly moved. Have a friend help to lift
and carry the unit to it's new location.
Printed in China
IMPORTANT
SAFETY
/
/
Advertisement
Subscribe to Our Youtube Channel
Summary of Contents for Mainstays MS87-020-104-30
- Page 1 1. You purchased this item from Wal-Mart 2. The item description is: 4-Drawer Organizer 3. The vendor stock number is MS87-020-104-30 11 lbs. 4. The part number/letter and quantity needed If you have this information ready, we will be able to process your request promptly.
- Page 2 CAUTION: 1. Read this instruction manual and keep it for reference. 2. Adult supervision is required due to small parts. 3. Assembly on soft surfaces to prevent damage to the product finish. 4. Estimated ten minutes for assembly. 5. Call our toll-free customer service if needed. ASSEMBLY TOOLS REQUIRED PHILLIPS SCREWDRIVER HAMMER WITH PLASTIC HEAD...
- Page 3 Left side panel Right side panel Top rail Bottom rail Top panel Top drawer Drawer Screw...
- Page 4 STEP 1. Insert top rails “C” into side panels “A” and “B” as shown. Note:drawer slide rails to inside. Tap down gently with rubber mallet. A -1PC B -1PC C -2PCS STEP 2. Flip unit over and insert bottom rails “D” into side panels “A” and “B” as shown, tap down gently with rubber mallet.
- Page 5 STEP 3. Place assembled frame on top panel “E” and attach with screws “H” into pre-drilled holes on top panel. E -1PC H -4PCS STEP 4. Slide top drawer “F” into place on drawer slides.Slide drawers “G” into place on drawer slides. F -1PC G -3PCS...
- Page 6 Finished. CAUTION: Make sure parts and hardware are properly fixed before using the product to prevent damage or injury. Do not scratch or chip the finish. To clean the Organizer, wipe with soft, dry cloth. Do not use abrasive cleaners in order to prevent the scratching the surface. Do Not Return To The Store! The store where you made your purchase does not stock hardware for this item.
-
Page 7: Instrucciones De Montaje
ESTE MANUAL DE INSTRUCCIONES CONTIENE SEGURIDAD IMPORTANTE INFORMACIÓN. POR FAVOR, LEA Y GUARDE PARA REFERENCIA FUTURA. UPC#849392006586 Organizador de 4 cajones MS87-020-104-30 Easy Home Organización de fabricación Co., Ltd ¡No vuelva a la tienda! ¿NECESITAS AYUDA? Para obtener ayuda con el... - Page 8 PRECAUCIÓN: 1. Lea este manual de instrucciones y guárdelo como referencia. 2. Se requiere supervisión de un adulto debido a piezas pequeñas. 3. Montaje en superficies blandas para evitar daños en el acabado del producto. 4. Estimación de diez minutos para el montaje. 5.
- Page 9 PARTES Y HARDWARE ANTES DE COMENZAR, SIGA LAS INSTRUCCIONES DE MONTAJE CUIDADOSAMENTE. SÍNTULE PASO POR PASO. Nombre de la pieza Dibujo de la línea de arte Cantidad(PC) Panel lateral izquierdo Panel lateral derecho Riel superior Riel inferior Panel superior Cajón de arriba Cajón Tornillo...
- Page 10 PASO 1. Inserte los rieles superiores "C" en los paneles laterales "A" y "B" como se muestra. Nota: los rieles deslizantes del cajón al interior. Toque suavemente con el mazo de goma. A -1PC B -1PC C -2PCS PASO 2. Voltee la unidad e inserte los rieles inferiores "D"...
- Page 11 PASO 3. Coloque el bastidor montado en el panel superior "E" y coloque con los tornillos "H" en los orificios previamente perforados en el panel superior. E -1PC H -4PCS PASO 4. Deslice el cajón superior "F" en posición en las correderas del cajón. Deslice los cajones "G"...
- Page 12 Terminado. PRECAUCIÓN: Asegúrese de que las piezas y el hardware estén correctamente fijados antes de usar el producto para evitar daños o lesiones. No raspe ni aspire el acabado. Para limpiar el organizador, limpie con un paño suave y seco. No utilice limpiadores abrasivos para evitar rascar la superficie.
