Eldi c.LOGiC lite cC1-C20 Manual

For navigation systems mersedes bens command 2.0
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
c.LOGiC lite-Interface
C1-C20
For navigation systems
Mercedes Benz
Comand 2.0
Comand APS CD
Product features
• full plug and play multimedia interface
• 1 AV-input with separate IR-control channel
• control of after-market devices, e.g. DVB-T tuner, DVD-player, DVD-changer, ...
• after-market rear-view camera input activation
• automatic switching to rear-view camera input (only from c.LOGiC-mode)
• rear-view camera power (+12V max. 1A)
• power on remote out trigger signal (+12V max. 1A) to switch on connected devices
• video-in-motion
Version 23.05.2013
C1-C20

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the c.LOGiC lite cC1-C20 and is the answer not in the manual?

Questions and answers

Summary of Contents for Eldi c.LOGiC lite cC1-C20

  • Page 1 c.LOGiC lite-Interface C1-C20 For navigation systems Mercedes Benz Comand 2.0 Comand APS CD Product features • full plug and play multimedia interface • 1 AV-input with separate IR-control channel • control of after-market devices, e.g. DVB-T tuner, DVD-player, DVD-changer, … •...

  • Page 2: Table Of Contents

    Contents 1. Prior to Installation 1.1. Delivery contents 1.2. Check compatibility of vehicle and accessories 2. Connection schema 3. Installation 3.1. Connections to the Comand 3.2. Interconnecting Interface-box and harnesses 3.3. Connecting peripheral devices 3.3.1. AV-source 3.3.2. Installing AV-source’s IR-sensor additionally 3.3.3.

  • Page 3: Prior To Installation

    Legal Information By law, watching moving pictures while driving is prohibited, the driver must not be distracted. We do not accept any liability for material damage or personal injury resulting, directly or indirectly, from installation or operation of this product. This product should only be used while standing or to display fixed menus or rear-view-camera video when the vehicle is moving, for example the MP3 menu for DVD upgrades.

  • Page 4: Check Compatibility Of Vehicle And Accessories

    1.2. Check compatibility of vehicle and accessories Requirements Vehicle Mercedes Benz C-Class (W203) til 04/2004, CL-Class (C215) from 09/2002 til 09/2003, CLK-Class (C208 W208) all years, CLK-Class (C209 W209) til 05/2004 , E-Class (W210) all years , G-Modell (W463) til 03/2007, ML-Class (W163) all jears, S-Class (W220) from 09/2002 til 09/2003, SL-Class (R230) til 06/2004 Navigation Comand 2.0, Comand APS CD...

  • Page 5: Connection Schema

    2. Connection schema 3. Installation Switch off ignition and disconnect the vehicle’s battery! If according to factory rules disconnecting the battery has to be avoided, it is usually sufficient to put the vehicle in sleep-mode. In case the sleep-mode does not show success, disconnect the battery with a resistor lead.

  • Page 6: Connections To The Comand

    3.1. Connections to the Comand Place of installation is behind the Comand. Remove the head-unit from the dash-board. Remove shell from female 18pin AMP connector of C1C-MB20. Transfer pins 2 (red), 11 (white), 3 and 12 (black) from female 18pin AMP connector of C1C-MB20 to corresponding slots of female 18pin AMP connector of factory harness.

  • Page 7: Interconnecting Interface-Box And Harnesses

    3.2. Interconnecting Interface-box and harnesses Plug harness C1C-MB20 into 12pin Molex of Interface-box C1C-M01. 3.3. Connecting peripheral devices It is possible to connect one after-market AV-source and an after-market rear-view camera to the c.LOGiC Interface. Before final installation of the peripheral devices, we recommend to test-run the c.LOGiC functions to detect incompatibility of vehicle, navigation, factory accessories or peripheral devices as soon as possible.

  • Page 8: Av-Source

    3.3.1. AV-source The c.LOGiC interface has the possibility to connect and remotely control by navigation buttons one pre-programmed device. The device list in the device control table (Appendix A) shows the pre-programmed remote channels and the related IR-remote cables STA-xxx which must be ordered separately for the control of the device.

  • Page 9: After-Market Rear-View Camera

    3.3.3. After-market rear-view camera Connect the video RCA of the after-market rear-view camera to female RCA connector R-CAM IN of Interface-box C1C-M01. Connect the green wire of the 4pin cable to the camera power supply (+12V max. 1A) of the after-market rear-view camera and the grey wire to ground of the vehicle. The green wire is high (+12V max.

  • Page 10: Assigning Device Control

    4.3. Assigning device control After selecting the c.LOGiC as current AV source, longpress the number “1”-button or shortpress the “RET”-button. The display in the instruments will show “TV 1” and “RC01”. Turn right knob until the device-related IR-code as described in device control table (appendix A) is reached. Push right knob to confirm the assignment.

  • Page 11: Picture Settings

    Button assignment table c.LOGiC Comand 2.0/APS CD/APS 220 COMAND DVB-T USB-LiNK DVD-player DVD- iPod®-control Analog-tuner button changer SCAN POWER PLAY PLAY PLAY/PAUSE SCAN ↑ ↑ ↑ ↑ ↑ VOL + EXIT STOP STOP POWER ← ← ← ← ← CH - 4 long DISPLAY VOL-...

  • Page 12: Audio Settings

    4.6. Audio settings To enter the Comand’s audio settings menu press button 12. 5. Specifications Operation voltage 10.5 – 14.8V DC Stand-by power drain <1mA Operation power drain 240mA Power consumption Temperature range -30°C to +80°C Weight Measurements (box only) B x H x T 106 x 30 x 71 mm 6.
