Summary of Contents for TECHFASS WREM 80 ThanGH
- Page 1 WREM 80 LithGH Standard readers with Wiegand output for Thangram and Lithos entry panels User’s guide ® © 2004 – 2012, TECH FASS s.r.o., Věštínská 1611/19, 153 00 Prague, Czech Republic, www.techfass.cz, techfass@techfass.cz (Date of release: 2012/04/24, valid for FW version 0.7)
-
Page 2: Table Of Contents
Wiring description – C2 cable................5 Indicators description ................... 5 Installation instructions ..................6 Mounting and removal the WREM 80 ThanGH reader ......... 7 Mounting and removal the WREM 80 LithGH reader ........... 8 5 Reader setting and functioning ................... 9 Operating test and control .................. -
Page 3: Product Description
(greyhound) color version of the buttons. Pic. 1a: WREM 80 ThanGH 2.2 WREM 80 LithGH The readers are designed for installation in Lithos entry panels of audio and video systems and... -
Page 4: Technical Parameters
WREM 80 LithGH Lithos 51480401 Table 1: Product version – TECHFASS factory ID media reading; – EM Marin ID media reading; – HID Proximity ID media reading 3.2 Technical features Supply voltage 8 ÷ 15 VDC Typical... -
Page 5: Installation
4 Installation 4.1 Connectors description Pic. 2: Connectors for cable connection Connector Purpose Connector for connecting configuration device Connector for C2 cable connection Table 4: Connectors description 4.2 Wiring description – C2 cable Cable C1 Cable C2 Color Purpose Color Purpose +8 ÷... -
Page 6: Installation Instructions
Nearby metal surfaces may cause a decrease in reading distance and speed. This is caused by the combined effects of parasitic capacitance and conductance. Mutual disturbance of a couple of TECHFASS devices (standard 125 kHz system reader module + Wiegand output reader) can be avoided by setting up the reading synchronization (see reader configuration chapter). -
Page 7: Mounting And Removal The Wrem 80 Thangh Reader
4.5 Mounting and removal the WREM 80 ThanGH reader 4.5.1 Reader mounting The first step is to unscrew all four screws holding the plastic lower cover for placing push buttons (thereinafter cover) of the Thangram panel (pic. 3a), then remove the cover. -
Page 8: Mounting And Removal The Wrem 80 Lithgh Reader
4.1 Mounting and removal the WREM 80 LithGH reader 4.1.1 Reader mounting When mounting the reader it is necessary to unscrew the front metal plate of the Lithos panel (pic. 4a). Then remove the bottom pushbutton (pic. 4b). Uncover the plastic strip (pic. -
Page 9: Reader Setting And Functioning
44bit (40 bits of code + 4 XOR parity bits); Yellow/green LED – selection of LED controlled by bringing 0 V signal to relevant input; Synchronization – cancels mutual disturbance of TECHFASS devices (standard 125 kHz system reader module + Wiegand output reader) 5.2 Changing reader configuration...
