Midian TDM-1 Instruction Manual

Transparent or addressable radio data modem
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
T
RANSPARENT OR
Features
•
1200 baud modem for point to point to multi-point
communications
•
Simplex or full-duplex operation
•
63 character flow control buffer processor
•
Automatic push-to-talk with front porch key-up delay
•
Carrier/CTCSS busy detect input
•
DB-25 connector houses the electronics
•
RJ-11 connector cable picks up the following:
• battery
• ground
• push-to-talk
• mic audio
• receive audio
• Carrier/CTCSS busy from radio
•
User to provide their own radio interface connector on
free end of RJ-11 cable
COPYRIGHT
MIDIAN ELECTRONICS, INC.
To Order: 1-800-MIDIAN'S
TDM-1
A
DDRESSABLE
INSTRUCTION MANUAL
American Communication Systems
Discover the Power of Communications
TO ORDER – VISIT
2000 MIDIAN ELECTRONICS INC. ALL RIGHTS RESERVED.
Software Version 1.0
2302 East 22nd Street
Telephone: (520) 884-7981
R
ADIO
http://www.ameradio.com
D
M
ATA
ODEM
™
Tucson, Arizona 85713
Fax: (520) 884-0422
5-12-00
