- Page 1 WTI Part No. 14530 Rev. A VMR Series Outlet Metered Switched PDUs Products Covered: VMR Standard Series VMR-HD4D Series VMR-HD4D-8 Series VMR-12B Series VMR-8H20-ATS Series Hardware Guide...
-
Page 2: Installation Instructions
Warnings and Cautions: Installation Instructions Secure Racking If Secure Racked units are installed in a closed or multi-unit rack assembly, they may require further evaluation by Certification Agencies. The following items must be considered. The ambient within the rack may be greater than room ambient. Installation should be such that the amount of air flow required for safe operation is not compromised. - Page 3 VMR to power for bench testing and initial start up and are adequate for applications that only require 15 Amps. For 20-Amp power switching applications, please refer to the WTI Power Cable guide supplied with the unit, or use appropriate 20-Amp cables.
-
Page 4: Agency Approvals
Agency Approvals FCC Part 15 Regulation This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 5: Table Of Contents
VMR Standard Series - Front Panel ........ -
Page 6: Introduction
Note: For instructions regarding configuration and operation of the VMR Series Device, please refer to the WTI Firmware Guide. Model Numbers Covered This Hardware Guide discusses all WTI VMR Series products. Throughout this Hardware Guide, all of these units are referred to as the "VMR."... -
Page 7: Unit Description
B5 - B8 3 4 5 Figure 2.1: VMR Standard Series - Front Panel (Model VMR-16HD20-1 Shown) As shown in Figure 2.1, the VMR Series Front Panel includes the following components: SetUp Port: An RJ45 RS232 serial port (DCE configuration) used for connection to a local terminal or external modem, as described in Section 4.3. -
Page 8: Vmr Standard Series - Back Panel
Unit Description LINK ALARM 10/100 BaseT Figure 2.2: VMR Standard Series - Back Panel (Model VMR-16HD20-1 Shown) 2.2. VMR Standard Series - Back Panel As shown in Figure 2.2, the VMR Series Back Panel includes the following components: Power Circuit A - Power Inlet: An IEC320-C20 AC inlet which supplies power to VMR control functions and Circuit “A”... -
Page 9: Vmr-Hd4D Series - Front Panel
Unit Description A1 A2 VMR-HD www.wti.com B1 B2 100% STATUS PLUG CURRENT USAGE 4 5 6 7 Figure 2.3: VMR-HD4D Series - Front Panel (Model VMR-HD4D32 Shown) 2.3. VMR-HD4D Series - Front Panel As shown in Figure 2.3, the VMR-HD4D Series Front Panel includes the following components: Branch B Circuit Breakers: Two circuit breakers, which protect Branch B. -
Page 10: Vmr-Hd4D Series - Back Panel
Network Port: An RJ45 Ethernet port for connection to your 10/100/1000Base-T, TCP/IP network. Note that the Network Port also includes two, small LED indicators for Link and Data Activity. For more information on Network Port configuration, please refer to the WTI Firmware Guide. -
Page 11: Vmr-Hd4D-8 Series - Front Panel
10/100/1000Base-T, TCP/IP network. Note that the Network Port also includes two, small LED indicators for Link and Data Activity. For more information on Network Port configuration, please refer to the WTI Firmware Guide. SetUp Port: An RJ45 RS232 serial port (DCE configuration) used for connection to a local terminal or external modem, as described in Section 4.3. -
Page 12: Vmr-Hd4D-8 Series - Back Panel
Unit Description Figure 2.6: VMR-HD4D-8 Series - Back Panel 2.6. VMR-HD4D-8 Series - Back Panel As shown in Figure 2.6, the VMR-HD4D-8 Series Back Panel includes the following components: Power Inlets: Each inlet provides power to the two switched outlets on the corresponding branch. Notes: • VMR-HD4D30-8 units feature attached power supply cables with NEMA L6-30P Plugs. -
Page 13: Vmr-12B Series - Front Panel
TCP/IP network. Note that the Network Port also includes two, small LED indicators for Link and Data Activity. For more information on Network Port configuration, please refer to the WTI Firmware Guide. SetUp Port: An RJ45 RS232 serial port (DCE configuration) used for connection to a local terminal or external modem, as described in Section 4.3. -
Page 14: Vmr-12B Series - Back Panel
Unit Description Figure 2.8: VMR Series - Back Panel (Model VMR-HD4D32-12B Shown) 2.8. VMR-12B Series - Back Panel As shown in Figure 2.8, the VMR-12B Series Back Panel includes the following components: Power Circuit A - Power Inlet: An IEC320-C20 AC inlet which supplies power to VMR control functions and Circuit “A”... -
Page 15: Vmr-8H20-Ats Series - Front Panel
TCP/IP network. Note that the Network Port also includes two, small LED indicators for Link and Data Activity. For more information on Network Port configuration, please refer to the WTI Firmware Guide. "ON" Indicator: An LED which lights when power is applied to the VMR. -
Page 16: Vmr-8H20-Ats Series - Back Panel
Unit Description PRIMARY SECONDARY Figure 2.10: VMR-8H20-ATS Series - Back Panel (Model VMR-8H20-ATS-1 Shown) 2.10. VMR-8H20-ATS Series - Back Panel As shown in Figure 2.10, the VMR-8H20-ATS Series Back Panel includes the following components: Power Inlets: Each inlet provides power to the eight switched outlets. If power to either inlet is interrupted, the VMR will automatically draw power from the remaining inlet. -
Page 17: Additional Button Functions
The Default and Reset buttons on the VMR front panel can be used to perform the functions described below: Notes: • All Front Panel Button functions can also be disabled via the System Parameters menu, as described in the WTI Firmware Guide. • When the VMR is reset to factory defaults, all user-defined configuration parameters will be cleared, and the default “super” user account will also be restored. -
Page 18: Getting Started
Although communication via Telnet, HTTP and/or HTTPS can be enabled as described in the WTI Firmware Guide, during this bench test procedure, the VMR will be controlled via the Command Line Interface (CLI) using a local PC, connected to either the Serial SetUp Port or Network Port: • Serial SetUp Port: Use the Ethernet Cable and Adapter supplied with the VMR. -
Page 19: Communicating With The Vmr
Getting Started 3.3. Communicating with the VMR Notes: • Default serial port parameters are set as follows: 9600 bps, RTS/CTS Handshaking, 8 Data Bits, One Stop Bit, No Parity. Although these parameters can be easily redefined, for this bench test procedure, it is recommended to configure your communications program to accept the default parameters. • The VMR features a default IP Address (192.168.168.168) and a default Subnet Mask (255.255.255.0.) This allows network IPv4 access to the Command Line Interface, providing that you are contacting the VMR from a node on the same subnet. Access the User Interface: Start your communications program, (e.g., Tera Term, PuTTy, etc.,) then press [Enter]. Username / Password Prompt: A message will be displayed, which prompts you to enter your username (Login) and password. -
Page 20: Hardware Installation
4. Hardware Installation This section describes the installation procedure for the VMR hardware. Note: For a detailed description of configurations options and advanced operating features, please refer to the WTI Firmware Guide. 4.1. Connecting the VMR to Your Power Supply CAUTIONS: • Before attempting to install this unit, please review the warnings and... -
Page 21: Connect The Vmr To Your Power Supply
4.3.1. Connecting a Local PC Use the DX9F-WTI Adapter supplied with the unit to connect your PC COM port to the VMR Setup Port. Make certain that the Serial Port Mode is set to “Normal” as described in the WTI Firmware Guide. -
Page 22: Connecting The Network Cable
WTI Firmware Guide for important information regarding advanced configuration options, security functions and more detailed operation instructions. If you have further questions regarding the VMR unit, please contact WTI Customer Support as described in Appendix C. -
Page 23: Specifications
Appendix A. Specifications Physical/Environmental: VMR-4HS Series: Width: 19” (48.3 cm) (Including Rack Brackets) Depth: 6.5” (16.5 cm) Height: 1.75” (4.5 cm) One Rack U VMR-8HS Series, VMR-8HD Series, VMR-HD4D Series, VMR-8H20-ATS Series: Width: 19” (48.3 cm) (Including Rack Brackets) Depth: 8.7” (22.1 cm) Height: 1.75” (4.5 cm) One Rack U VMR-HD4D-8 Series: Width: 19”... -
Page 24: Serial Interface Description
Appendix B. Serial Interface Description (Standard Pinout) Figure B.1: VMR Series RS232 Port Interface (RJ45 - Standard Pinout) B.1. Serial Port (RS232) DCD and DTR hardware lines function as follows: When connected: If either port is set for Modem Mode, the DTR output at either port reflects the DCD input at the other end. -
Page 25: Customer Service
If the unit should need to be returned for factory repair it must be accompanied by a Return Authorization number from Customer Service. WTI Customer Service 5 Sterling Irvine, California 92618 Local Phone: (949) 586-9950... - Page 26 Appendices Trademark and Copyright Information WTI and Western Telematic are trademarks of Western Telematic Inc.. All other product names mentioned in this publication are trademarks or registered trademarks of their respective companies. Information and descriptions contained herein are the property of Western Telematic Inc..
