Summary of Contents for Ubolon DAC651A
-
Page 1: User Manual
深圳市优视联科技有限公司 www.ubolon.com USER MANUAL 5.1ch Digital Audio Decoder Model No1: DAC651A（no USB） Model No2: DAC651B（with USB） REMARK Manufacturer does not make any commitment to update the information contained herein. -
Page 2: Specifications
深圳市优视联科技有限公司 www.ubolon.com FEATURES Support two Optical input,one Coaxial input,one AUX input,one USB 2.0 input（only DAC651A）. You can switch different signal sources randomy by Button. 2: Support one 5.1ch analog audio output.DAC651A output by RCA connector,DAC651B output by 3.5mm phone connector. -
Page 3: Panel Definition
DC-5V 5.1CH OPT2 OPT1 POWER 1 1 1 A 1 1 1 B 1 1 1 C 1 1 1 9 DAC651A/B Front panel view FIG.1.0 1：DC-5V Power input 2：Optical input 1 3：Optical input 2 4：Coxial input 5：AUX input 6：5.1ch/2.0ch switch button 7：Input source switch button... -
Page 4: Package Contents
1 1 1 4 U S B 2 . 0 C E N / S W S L / S R F L / F R DAC651A Rear panel view FIG.1.3 1：Front Left/Right channel(FL/FR) 2：Surrond Left/Right channel(SL/SR) 3：Center/ Subwoofer channel(CEN/SW) 4：USB 2.0 port... -
Page 5: Warranty Card
The LED of OPT1/OPT2/COX will in a state of water lights when select “USB” mode. 4、 The difference of DAC651A/DAC651B: DAC651A: No USB input mode，5.1ch output interface is RCA; DAC651B: With USB input mode，5.1ch output interface is 3.5mm Phone. Warranty card...
