Luraco iFill 4 L0903A User Manual

Spa control system

MasterBox

When using electrical equipment, basic safety precautions should always be followed to reduce the risk

of fire, electric shock and injury. Safety precautions are as follows:

1. Read and follow all instructions before using the equipment

2. Keep the cord out of heavy traffic area. To avoid fire hazard NEVER put the cord under rugs or near heat

generating devices

3. Always turn off the equipment before servicing

4. Do not drop or insert any object into any openings

5. Do not operate any equipment with damaged parts

6. This system is for indoor use only

7. Do not attempt to repair or adjust any electrical or mechanical functions on this unit. Doing so will void the

warranty

8. As a condition of acceptability UL requires that this product be installed over a non-combustible surface; if

this product is installed over a combustible surface, a non-combustible layer must be installed between the

device and the surface

9. Any other use not recommended by the manufacturer may result in electrical shock or injury

After reading this owner's guide, if you have any questions or comments, please call +1-817-633-1080 or contact our technical

support department at

support@luraco.com

PLEASE READ AND SAVE THESE IMPORTANT SAFETY INSTRUCTIONS

USER'S MANUAL

iFill 4 Spa Control System

MODEL L0903A

or visit our website at

Control Keypad

www.luraco.com

for more information

Table of Contents

Need help?

Do you have a question about the iFill 4 L0903A and is the answer not in the manual?

Page 1 9. Any other use not recommended by the manufacturer may result in electrical shock or injury After reading this owner’s guide, if you have any questions or comments, please call +1-817-633-1080 or contact our technical support department at support@luraco.com or visit our website at www.luraco.com...
Page 2 FEATURES and OPERATIONS iFill 4 Features Automatic spa fill with intelligent and reliable level sensor • Can also be used even with a disposable liner • Time delay setting • Dual switched outlets • Dual continuous outlets • Single drain pump controlled outlet with 3 minute timer •...
Page 3 Fig. 2: Capacitive sensor installed on JET Housing Fig. 3: Input and Output Control Ports Follow the steps below for the water level sensor installation a) Connect the sensor cable to MasterBox port named “LEVEL SENSOR”, (Fig. 3) b) Connect the Water Valve to MasterBox port named “WATER VALVE”, .
Page 4: Warranty Information
3. Unless otherwise proscribed by law, LURACO shall not be liable for any personal injury, property or any incidental or consequential damages of any kind resulting from malfunctions, defects, misuse, improper installation or alteration of this product.
