Operational Notes
The ON button calls up the panel's programmed Entry Scene. The system may also be activated by a quick
press on any scene button, bringing that scene on. All luminaires directly controlled by the panel and those
linked by group but controlled by other devices will respond.
The OFF button switches off all luminaires controlled directly by the panel and those linked by zone but
controlled by other devices.
Temporary Override raises the light level of
linked by group but controlled by other devices.
Temporary Override dims the light level of
linked by group but controlled by other devices.
When the temporary Override buttons have been used the LED of the latest scene selected will flash to
indicate that the panel is no longer outputting a pre-set scene light level. The panel will remain in this state
until it receives a new command from the Keypad, the SensaLink bus or an Infrared Remote Control device,
or time-out occurs.
Setting and Recalling Scenes
To set a scene, select the required scene and adjust to the desired light level using the
of the panel itself, or those of the SENSALINK SENLRC Infrared Remote Control, or the Utility functions of
the SENSALINK SENLP. When the level is reached, it must be "learned" by the panel as the new value for
that scene. This can only be done by sending the appropriate scene select signal continuously over a period
of six seconds via the Infrared Remote Control link from a SENSALINK SENLRC or a SENSALINK SENLP.
With the device correctly aligned to the panel, press and hold the required scene select key until the luminaires
under the direct control of the panel begin to flash on and off slowly. The LED of the scene button in question
should flash during this process and be lit constantly at the end of this operation.
To recall a pre-set scene simply press the appropriate button briefly. The LED of the button in question
should be lit at the end of this operation. This operation can also be carried out remotely using the
scene select buttons of the SENSALINK SENLRC.
Scene Responses
Scene 1 The panel signals to detectors linked by group to enter Scene 1 regulating mode but will
continue to output the previously commanded level to its directly controlled luminaires.
Scenes 2-6 The panel signals to detectors linked by group and its own output to enter the relevant scene
as previoulsy programmed.
Technical Data
2
SENSALINK BUS CABLE: 1.5mm unscreened twisted pair
2
DIMMING CABLE: 1mm 2-core mains rated cable
DIMMING OUTPUT: up to 25 ballasts (either DSI or DALI - not mixed - to be configured via SENSALINK SENLP)
~
POWER SUPPLY: 230V 50Hz
POWER CONSUMPTION: < 10W
2
TERMINAL CAPACITY: 2.5mm
o
ta 0 - 40 C
DIMENSIONS: Module (including supporting frame): 82mm x 144mm
Fascia: 86mm x 146mm
Fascias must be ordered separately using the following part codes:
Polished Brass: SENSALINK SENLSS V2 BR POL COVER (96237038)
Polished Chrome: SENSALINK SENLSS V2 CHR POL COVER (96237039)
Brushed Stainless Steel: SENSALINK SENLSS V2 RS BS COVER (96237040)
White: SENSALINK SENLSS V2 WHI COVER (96237041)
Thorn Lighting Limited
www.thornlighting.com
all luminaires controlled directly by the panel and those
all luminaires controlled directly by the panel and those
At the end of their useful life
the packaging and product
should be disposed of via a
suitable recycling centre.
Do not dispose of with normal
household waste.
Do not burn.
buttons
W4370B
SENSALINK SENLSS V2 (96237037)
SensaLink Scene Switch Panel
Installation and Commissioning
Instructions
Note: SENSALINK SENLP required for commissioning
