- Page 1 INSTALLATION INSTRUCTIONS CRL JACKSON 1275 SURFACE VERTICAL ROD PANIC EXIT DEVICE Phone: (800) 421-6144 • Fax: (866) 921-0531 crlaurence.com • usalum.com • crl-arch.com crlaurence.com 11M0247...
-
Page 2: Table Of Contents
DOOR PREPARATION ..........................05 - 08 LAYOUT SELECTION ........................06 - 08 1275 EXIT DEVICE INSTALLATION ...................06 - 07 1275 EXIT DEVICE WITH LOCK CYLINDER AND EXTERIOR TRIM ..........08 DOOR HARDWARE INSTALLATION ......................09 - 15 INSTALL MORTISE CYLINDER LOCK AND EXTERIOR TRIM (OPTIONAL) .......... 09 INSTALL UPPER AND BOTTOM LATCH BRACKET ASSEMBLIES ............ -
Page 3: Parts Identification
CRL JACKSON PANIC EXIT DEVICE - 1275 SURFACE VERTICAL ROD PARTS IDENTIFICATION FASTENERS AND PARTS LIST CALL FASTENER USED WITH QTY. FASTENER PART DESCRIPTION PART NUMBER 302652 10-32 x 7/8" FHMS Base End Cap Assembly 302652 1/4"-20 x 1/2" PHMS... -
Page 4: Parts Identification
CRL JACKSON PANIC EXIT DEVICE - 1275 SURFACE VERTICAL ROD PARTS IDENTIFICATION FASTENERS AND PARTS LIST CALL FASTENER USED WITH QTY. FASTENER PART DESCRIPTION PART NUMBER 302652 8-32 x 3/8" FHMS Base End Cap Assembly Optional 7500LV02628 and 7500LVDT01628 10-32 x 2-1/8" FHMS... -
Page 5: Door Preparation
CRL JACKSON PANIC EXIT DEVICE - 1275 SURFACE VERTICAL ROD DOOR PREPARATION REMOVE DOOR AND PREPARE PER ATTACHED LAYOUT DRAWING 10-1082-1 1. Place the door horizontally on the work stands, interior side up. 2. Mark the stile centerlines 1" from the outside edge of the stile. (Fig. 1) 3. Mark the corresponding layouts on to the stile using the vertical centerlines at the specified height. (Fig. -
Page 6: Layout Selection
CRL JACKSON PANIC EXIT DEVICE - 1275 SURFACE VERTICAL ROD DOOR PREPARATION – LAYOUT SELECTION 1275 EXIT DEVICE INSTALLATION - ACTIVE STILE INTERIOR VIEW ACTIVE STILE Drill and Tap for a 10-24 Machine Screw (4) Places Templates from Box FIG. 3 NOT TO SCALE crlaurence.com | usalum.com... - Page 7 CRL JACKSON PANIC EXIT DEVICE - 1275 SURFACE VERTICAL ROD DOOR PREPARATION – LAYOUT SELECTION 1275 EXIT DEVICE INSTALLATION - INACTIVE STILE INTERIOR VIEW ACTIVE STILE Drill and Tap for a 1/4"-20 Machine Screw Templates from Box FIG. 4 NOT TO SCALE...
-
Page 8: 1275 Exit Device With Lock Cylinder And Exterior Trim
CRL JACKSON PANIC EXIT DEVICE - 1275 SURFACE VERTICAL ROD DOOR PREPARATION – LAYOUT SELECTION 1275 EXIT DEVICE INSTALLATION WITH OPTIONAL EXTERIOR TRIM AND MORTISE CYLINDER LOCK INTERIOR VIEW Drill and Countersink ACTIVE STILE for a 10-24 FHMS (2) Places... -
Page 9: Door Hardware Installation
CRL JACKSON PANIC EXIT DEVICE - 1275 SURFACE VERTICAL ROD DOOR HARDWARE INSTALLATION INSTALL OPTIONAL MORTISE CYLINDER LOCK AND EXTERIOR TRIM NOTE: Exterior trim must be installed before attaching exit device. 1. Attach the exterior trim to the active stile with (2) #10 x 2-1/8" FHMS #10 x 2-1/8"... -
Page 10: Install Upper And Bottom Latch Bracket Assemblies
CRL JACKSON PANIC EXIT DEVICE - 1275 SURFACE VERTICAL ROD DOOR HARDWARE INSTALLATION (CONTINUED) INSTALL UPPER AND BOTTOM LATCH BRACKET ASSEMBLIES 1. Attach the upper and bottom latch bracket assemblies 302408 to the prepped active door stile using (2) 1/4"-20 x 1-1/4" FHMS 2. -
Page 11: Install 1275 Exit Device
CRL JACKSON PANIC EXIT DEVICE - 1275 SURFACE VERTICAL ROD DOOR HARDWARE INSTALLATION (CONTINUED) INSTALL 1275 EXIT DEVICE 1. Attach the panic exit device to the active stile with (2) 10-32 x 7/8" FHMS and (1) 1/4"-20 x 1/2" PHMS through the end cap bracket on the inactive stile. -
Page 12: Rod Linkage Adjustments
CRL JACKSON PANIC EXIT DEVICE - 1275 SURFACE VERTICAL ROD DOOR HARDWARE INSTALLATION (CONTINUED) ROD LINKAGE ADJUSTMENTS UPPER ROD: 1. The top latch must be in the open position. (Fig. 10) 2. Turn the adjuster rod so that the end is aligned with the top line marking, just under the words "TOP LATCH"... -
Page 13: Connection Of Linkage Rods To 1275 Exit Device
CRL JACKSON PANIC EXIT DEVICE - 1275 SURFACE VERTICAL ROD DOOR HARDWARE INSTALLATION (CONTINUED) CONNECTION OF LINKAGE RODS TO THE EXIT DEVICE 1. Bring the upper latch to the closed position. (Fig. 13) The bottom latch should be in the closed position. (Fig. 14) 2. -
Page 14: Operations Check And Dogging Instructions
CRL JACKSON PANIC EXIT DEVICE - 1275 SURFACE VERTICAL ROD DOOR HARDWARE INSTALLATION (CONTINUED) OPERATIONS CHECK AND DOGGING INSTRUCTIONS OPERATIONS CHECK: Depress the push bar to assure free movement of the cruciform assembly. Both upper and bottom latches should acti- vate to the open position. The upper latch should drop into the open position, figure 10. The bottom latch should fully... -
Page 15: Install End Caps And Cover Assemblies
CRL JACKSON PANIC EXIT DEVICE - 1275 SURFACE VERTICAL ROD DOOR HARDWARE INSTALLATION (CONTINUED) INSTALL END CAPS AND COVER ASSEMBLIES 1. Slide the (2) base cover plates 302674 in place. 2. Attach both end caps with (4) 8-32 x 3/8" FHMS 3. -
Page 16: Frame Preparation And Strike Installation
CRL JACKSON PANIC EXIT DEVICE - 1275 SURFACE VERTICAL ROD FRAME PREPARATION RE-ATTACH DOOR TO FRAME 1. Make sure that the panic exit device is in the dogged position. Both the upper and bottom latches must clear the frame. Re-attach the door to the frame. - Page 17 CRL JACKSON PANIC EXIT DEVICE - 1275 SURFACE VERTICAL ROD FRAME PREPARATION ATTACH UPPER STRIKE 1. Attach upper strike, use (4) 10-16 x 3/4" FHDS (Fig. 22), centering on the mark made in Step 2 of Frame Preparation on page 16. Start with door gap at zero position (Fig.23).
-
Page 18: Packaged Parts Available
CRL JACKSON PANIC EXIT DEVICE - 1275 SURFACE VERTICAL ROD PACKAGED PARTS AVAILABLE Assem. Part No. Description Assem. Part No. Description 302652 Base End Cap Package 3028528 Top Rod Cover Assembly - 8/0 302741ASM Cruciform Activation Assembly 3028529 Top Rod Cover Assembly - 9/0...
