INSTALLATION INSTRUCTIONS
PART NUMBERS:
80-HBS306, 80-HBS307, 80-HBS308, 80-HBS312, 80-HBS338
ANGLED ALUMINUM MOUNTING BRACKET
ITEM 1
ITEM 6
PRODUCT DESCRIPTION
Bed Safe Universal Fit
CONTENT
DESCRIPTION
ALUMINUM MOUNTING TABS
PLUS NUTS
5/16" Nut
5/16" x 1 1/4" HEX HEAD SCREW
5/16" FLAT WASHER
5/16" LOCK WASHER
5/16" X 2" HEX HEAD SCREW
ITEM 2
ITEM 3
1
ITEM 7
Thank You for choosing Westin products
For Additional installation assistance please call
Customer service (800) 793-7846
www.westinautomotive.com
TOOLS NEEDED
1/2" SOCKET
RATCHET
1/2" WRENCH
1/2" DRILL BIT
DRILL
ITEM 4
ITEM 8
DATE: 06/26/15
