EcoMatters Solar Panel Installation
Applicable Product Models:
For 6'' poly series:
a) 72 cells: JYxxxM72 (xxx=330-345, in steps of 5);
b) 60 cells: JYxxxM60 (xxx=275-285, in steps of 5);
c) 54 cells: JYxxxM54 (xxx=250-255, in steps of 5);
d) 48 cells: JYxxxM48 (xxx=220-230, in steps of 5);
e) 36 cells: JYxxxM36 (xxx=165-170, in steps of 5).
For 6'' poly series:
a) 72 cells: JYxxxP72 (xxx=300-330, in steps of 5);
b) 60 cells: JYxxxP60 (xxx=255-275, in steps of 5);
c) 54 cells: JYxxxP54 (xxx=225-240, in steps of 5);
d) 48 cells: JYxxxP48 (xxx=200-215, in steps of 5);
e) 36 cells: JYxxxP36 (xxx=150-165, in steps of 5).
Guangdong Jinyuan Lighting Technology Co.,Ltd.
Tel: +86-768-2800688 Fax: +86-768-2800788
Instructions
1
Jinyuan Lighting
www.jinyuanlighting.com
Advertisement
Table of Contents
Summary of Contents for Jinyuan Lighting EcoMatters JY M72 Series
- Page 1 60 cells: JYxxxP60 (xxx=255-275, in steps of 5); c) 54 cells: JYxxxP54 (xxx=225-240, in steps of 5); d) 48 cells: JYxxxP48 (xxx=200-215, in steps of 5); e) 36 cells: JYxxxP36 (xxx=150-165, in steps of 5). Guangdong Jinyuan Lighting Technology Co.,Ltd. Tel: +86-768-2800688 Fax: +86-768-2800788 Jinyuan Lighting www.jinyuanlighting.com...
-
Page 2: Table Of Contents
1 0 、 E l e c t r i c a l P a r a m e t e r s - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2 0 Jinyuan Lighting... -
Page 3: 1、Introduction
1. Introduction Thank you very much for choosing the Photovoltaic Modules(referred as ‘Modules’) manufactured and sold by Guangdong Jinyuan Lighting Technology Co.,Ltd. This installation manual provides the modules installation and use info of Guangdong Jinyuan Lighting Technology Co.,Ltd(referred as ‘Jinyuan’). -
Page 4: 3、General Safety Rules
Special attention should be paid when handling and connecting wires. It is forbidden to gather the sun to the modules with mirror or any other amplifiers. Cover the modules completely with opaque material during the installation to avoid current generated. Jinyuan Lighting... -
Page 5: 4、Transportation,Storage And Handling
Don’t jolt or crash the modules during handling or installing. Don’t put down the modules violently. It is forbidden to pick up the modules by grabbing the junction box or the cables under any circumstance. Don’t stand or walk on the modules. Don’t drop one module onto another one. Don’t Jinyuan Lighting... -
Page 6: 5、Product Identification Info
For your safety concern, please do not disassemble or modify Jinyuan modules, which may affect the performance and security of the product and even bring some invocatable damage, and also invalidate any applicable warranty. 5. Product Identification Info Jinyuan Lighting... -
Page 7: 6、Installation Conditions
Manufacture, JY: Jinyuan 6. Installation Conditions Jinyuan Module is suitable for installation on the ground, and can not be used in space. Permitted environment should meet the requirements as below: Environment Temperature is -40 ~85 , ℃ ℃ Jinyuan Lighting... -
Page 8: 7、Mechanical Installation
The module is not allowed to be installed near any equipment or place that is liable to produce or collect flammable gases. The module is not allowed to installed somewhere with water soaking, water-drying device or water injector. 7. Mechanical Installation Jinyuan Lighting... -
Page 9: General Installation Rules
Northern Hemisphere, and northward when in the Southern Hemisphere. B. The module can be installed lengthways or sideways. Do check whether the length of the cable is enough when installing. If extra cables needed, do choose the cable with same type of Jinyuan Lighting... -
Page 10: Selection Of The Bracket
When roof installation, make sure the roof structure is suitable for installing. The system designer needs to set up the corresponding brace beam based on the roof special structure requirement. If it should be installed through the roof, make sure the perforation is sealed correctly to avoid water leaking. Jinyuan Lighting... -
Page 11: Installation Method
The contact surface of the clamp and the frame should be flat and smooth. The clamp can not cover the waterspout. The clamp can not have shelter effect on the solar cells. 7.6.1 Installation Method and Position Jinyuan Lighting... - Page 12 Install with screws through the mounting hole Mounting hole Screw installing using 8 mounting holes Clamp fixed installation Clamp installation permit range on the long side Clamp installation permit range on the short side Frame embedded installation Clamp installation permit range Jinyuan Lighting...
-
Page 13: Installation Details
The module are fastened to the bracket with metal clamps. Clamp A is used on the module square edge, clamp B is used between two modules. Clamps with below conditions are recommended: Width: ≥38mm Thickness:≥3mm Material: Aluminum Alloy Bolt dimension: M8 Torque range of screw tightening: 18N.m to 24N.m Jinyuan Lighting... - Page 14 2. Clamp A(at least 2 pcs) 3.Installation bracket 4. PV module Figure 4: Clamp Fixed Installation 1. Laminated piece 2. Bolt 3. Spacer 4.Clamp A 5. Aluminum frame 6. Spacer 7. Spring shim 8. Nut 9. Installation bracket Jinyuan Lighting...
-
Page 15: 8、Electrical Installation
The maximum quantity for module to be in series or parallel should be calculated according to the requirement of relevant regulations. The open circuit voltage under the expected local Jinyuan Lighting... - Page 16 Connector should not subjected to additional pressure. Non-professionals are prohibited to open the lock nut. The connector is only for connecting circuit without opening or closing circuit function. Figure 7. Male Connector and Female Connector Jinyuan Lighting...
-
Page 17: Grid-Connected Electrical System
In order to avoid the risk of electric shock or fire hazard, the module frame needs to do the equipotential connection before the system operation. Please refer to the local safety and electrical installation standard for the installation requirement. The correct grounding device is to connect all the metal devices which is not used for Jinyuan Lighting... - Page 18 Joint the module with field installation equipotential connection conductors and grounding conductors. The connector or junction of the module should be marked with below special identifier, any other connector or junction can not use this symbol Jinyuan Lighting...
-
Page 19: 9、Debugging And Maintenance
6) Please do not clean the modules with damaged glass or bare wire, otherwise there will be risk of electrical shock. 7)If there is any question, please arrange qualified person for checking. Jinyuan Lighting... - Page 20 37.6 8.65 JY330P72 330 ±3% 37.8 8.75 46.9 ±3% 9.14 ±5% JY255P60 255 ±3% 30.8 8.28 38 ±3% 8.92 ±5% JY260P60 260 ±3% 31.1 8.37 38.1 ±3% 8.98 ±5% 265 ±3% 38.6 ±3% 9.03 ±5% JY265P60 31.4 8.44 Jinyuan Lighting...
- Page 21 9.14 ±5% JY165P36 165 ±3% 19.1 8.64 23.4 ±3% 9.21 ±5% Operating temperature range（℃） —40 ~85 ℃ ℃ Maximum Reverse Protection Rated Current Maximum System Voltage 1000V Pmax Temperature Coefficient -0.395%/℃ Voc Temperature Coefficient -0.317%/℃ Isc Temperature Coefficient 0.0577%/℃ Jinyuan Lighting...
